The ECOXTALK EXG50 twin pack is a simple, low-cost pair of 500mW UHF CB handhelds in a camouflage finish, sized for kids and adults alike. With all 80 Australian UHF CB channels, 50 CTCSS and 104 DCS codes, up to 3km of talk range* and 20-plus hours from a set of AAA batteries, they are an easy way to keep the family in touch around the campsite, on a walking track or at the park. Each radio has a large backlit channel display, a built-in LED torch, hands-free VOX and a micro-USB port that recharges NiMH AAA cells in the radio (batteries not included).

Key Features

• 500mW output, 80 UHF CB channels: full coverage of the Australian 476.4250–477.4125 MHz UHF CB band, including duplex on the repeater channels
• Up to 3km talk range*: suited to campsites, parks, beaches and short walks
• 20+ hours of operation: runs on 3 × AAA alkaline or NiMH rechargeable batteries per radio (not included)
• Micro-USB charging: recharges NiMH AAA cells inside the radio via the included cables
• Compact and light: 143mm tall and 124g with batteries – easy for small hands and pockets
• Large backlit channel LCD: with simple channel and volume controls and key lock
• 50 CTCSS and 104 DCS codes: plus dual watch, channel scan, auto squelch and 5 call tones
• Hands-free VOX: voice-activated transmit with three sensitivity levels
• Emergency call: hold the torch/lock key for five seconds to switch to channel 5 and send a call tone
• Built-in LED torch, low-battery alert and belt clip with large strap ring

Specifications

• Model: EXG50-2PKC (camouflage)
• RF output power: 500mW
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 3km*
• Squelch codes: 50 CTCSS, 104 DCS
• Battery: 3 × AAA alkaline or NiMH rechargeable per radio (not included)
• Operation time: 20+ hours
• Charging: micro-USB (charges NiMH cells in the radio)
• Dimensions: 143 × 49 × 39mm per radio (with belt clip)
• Weight: 124g per radio (with batteries)
• Colour: camouflage

What’s in the Box

• 2 × EXG50 UHF CB handheld radios (camouflage)
• 2 × belt clips
• 2 × micro-USB charging cables
• 1 × user guide

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 3 years with free online product registration.

*Talk range varies with terrain, obstructions and conditions.

IQBOARD Optional Expansion Mics for S330 Speakerphone/Mic

The ECOXTALK EXG510S in blaze orange is a 5-watt, long-range UHF CB handheld for 4WD touring, remote worksites, boating and emergency kits, with a high-visibility colour that is easy to find in a glovebox, tool bag or on the ground. It is IP67 waterproof and dustproof, runs for up to 25 hours on its 2500mAh lithium-ion battery and charges by USB-C either directly or in the included desktop cradle. A one-touch REPLAY key plays back received transmissions so nothing is missed, a live RSSI display shows signal strength and squelch level, and an on-screen UHF channel use guide shows which channels are set aside for emergency, highway, off-road, caravan, repeater and general use. Switchable 5W/3W/1W output, hands-free VOX and a removable antenna that accepts the ECOXGEAR ATPA230 external antenna round it out, with an earpiece microphone in the box.

Key Features

• 5W / 3W / 1W switchable output, 80 UHF CB channels: up to 17km talk range* at full power; drop to 3W or 1W to save battery
• IP67 waterproof and dustproof: rugged housing for rain, dust and wash-downs
• One-touch REPLAY: dedicated key plays back received transmissions
• Live RSSI active display: received signal strength and squelch level at a glance
• Up to 25 hours of operation: 2500mAh lithium-ion battery pack, included
• USB-C charging: direct to the radio or via the included single charging cradle; AC/USB adapter and cable supplied
• On-screen UHF channel use guide: shows the emergency, highway, off-road, caravan, repeater and general-use channels
• 7-colour dot matrix LCD: adjustable display and keypad brightness; rotary on/off and volume control
• Removable flexible antenna: swap for an ECOXGEAR ATPA230 external antenna; 2-pin K-type accessory socket with earpiece microphone included
• Hands-free VOX: plus 50 CTCSS and 104 DCS codes, channel scan with four scan modes, dual channel watch, one-touch priority channel, call tone, roger beep, key lock, auto battery save and low-battery alert

Specifications

• Model: EXG510SORG (blaze orange)
• RF output power: 5W / 3W / 1W switchable
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 17km*
• Ingress rating: IP67
• Display: 7-colour dot matrix LCD with live RSSI; adjustable display and keypad brightness
• Squelch codes: 50 CTCSS, 104 DCS
• Battery: 2500mAh lithium-ion pack (included)
• Operation time: up to 25 hours
• Charging: 5V USB-C, direct or via single charging cradle
• Antenna: removable flexible (ATPA230 compatible)
• Accessory port: 2-pin K-type socket (microphone/earpiece)
• Dimensions: 270 × 60 × 53mm
• Weight: 300g
• Colour: blaze orange

What’s in the Box

• 1 × EXG510SORG UHF CB handheld radio
• 1 × lithium-ion battery pack
• 1 × removable antenna
• 1 × belt clip
• 1 × single charging cradle
• 1 × earpiece microphone
• 1 × AC/USB adapter
• 1 × USB charging cable
• 1 × user guide

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 3 years with free online product registration.

*Talk range varies with terrain, obstructions and conditions.

The ECOXTALK EXG1000 is a 5-watt, 80-channel UHF CB radio in a super-compact 109 × 27 × 123mm chassis that fits where a full-size unit will not – ideal for 4WDs, campervans and motorhomes. An extra-wide, high-contrast VA LCD with seven backlight colours and a dimmer stays readable day or night, noise-reduction circuitry keeps audio clear through the speakers in both the lightweight microphone and the base, and a USB-C port (5V/9V) on the radio charges your phone or other devices on the go. Open and group scan with priority watch, one-touch emergency and priority channel recall and duplex repeater channels are all on board, for up to 17km of talk range* with a suitable antenna (sold separately).

Key Features

• 5W output, 80 UHF CB channels: 476.4250–477.4125 MHz band with duplex (repeater) channels and up to 17km talk range* with a suitable antenna
• Super-compact chassis: 109mm W × 27mm H × 123mm D on the included quick-release mounting bracket
• 7-colour high-contrast VA LCD: extra-wide display with backlight dimmer and 5-step brightness, readable day or night
• USB-C charging port: 5V/9V output to charge phones and other devices on the go
• Noise-reduction circuit: clear audio through the speakers in both the lightweight microphone and the base
• Scanning: open scan and group scan with priority watch, dual watch, busy channel lockout and monitor mode
• One-touch emergency channel (05/35) and priority channel recall
• 9 squelch levels, 50 CTCSS and 104 DCS codes
• 5 call tones, roger beep, key beep and hi/lo voltage alert
• Antenna not included: sold separately – see the EXG1000 Value Pack for a radio-and-antenna bundle

Specifications

• Model: EXG1000
• Radio type: fixed mount UHF CB
• RF output power: 5.0W
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 17km*
• Display: extra-wide 7-colour high-contrast VA LCD, 5-step brightness with dimmer
• Squelch: 9 levels; 50 CTCSS and 104 DCS codes
• Power: 12V DC, fused power lead included
• USB-C port: 5V / 9V charging output
• Antenna connection: external antenna socket (SO-239, for PL-259 plug)
• Accessory port: 3.5mm audio jack
• Chassis dimensions: 109mm W × 27mm H × 123mm D
• Weight: 394g (with bracket)
• Microphone: 94 × 64 × 37mm (with hook), 192g

What’s in the Box

• 1 × EXG1000 UHF CB radio
• 1 × quick-release mounting bracket
• 1 × microphone hanger
• 1 × 12V DC power lead with fuse
• Mounting hardware
• 1 × user guide

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 5 years with free online product registration.

*Talk range varies with antenna, terrain, obstructions and conditions.

The EXG3000 Touring Pack bundles the ECOXTALK EXG3000 5-watt fixed mount UHF CB radio with the ECOXGEAR ATEBR660-2PK on-road antenna kit and a black Z-bracket mount, so a touring 4WD, caravan tow vehicle or motorhome is on air straight out of the box. The antenna kit’s elevated-feed barrel spring base takes two interchangeable whips: a short 2.3dBi whip (440mm overall) with a rounded pattern for towns and built-up areas, and a 6.6dBi whip (980mm overall) with a longer, flatter pattern for the open highway. The radio itself tucks a super-compact base behind the dash and puts an extra-large 2.17" 7-colour display, live RSSI and dedicated channel and volume keys on the remote speaker mic, for up to 17km of talk range* across all 80 channels.

Key Features

• Radio, antenna kit and mount in one pack: EXG3000 radio, LCD speaker mic and mounting kit with the ATEBR660-2PK antenna, two whips, 4.5m coax, PL-259 adapter and a black Z bracket
• ATEBR660-2PK on-road antenna: elevated-feed barrel spring base (Ø45mm) with interchangeable 2.3dBi and 6.6dBi whips; UHF CB 477MHz, ground independent
• Two whips for two conditions: 2.3dBi short whip (140mm, 440mm overall) for towns and built-up areas; 6.6dBi long whip (680mm, 980mm overall) for long, flat highway runs
• 5W output, 80 UHF CB channels: 476.4250–477.4125 MHz band with duplex (repeater) channels and up to 17km talk range*
• Super-compact base: 106.5mm W × 29.5mm H × 120mm D chassis mounts out of sight on the included quick-release bracket
• Remote LCD speaker microphone: extra-large 2.17" 7-colour dot matrix display, backlit keypad, dedicated channel and volume keys and a heavy-duty cord; magnetic mic hanger and 2m extension cable included
• Live RSSI active display: shows received signal strength and squelch level; 9 squelch levels to suit conditions
• Noise-reduction circuit: clear audio through the speakers in both the microphone and the base
• Scanning and recall: open and group scan with priority watch, dual watch, busy channel lockout, monitor mode, one-touch emergency (05/35) and priority channel recall
• 50 CTCSS and 104 DCS codes: plus 5 call tones, roger beep, key beep, display dimmer with 5-step brightness and hi/lo voltage alert

Specifications

• Model: EXG3000-TPK
• Radio: EXG3000 fixed mount UHF CB with remote LCD speaker microphone
• RF output power: 5.0W
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 17km*
• Display: 2.17" 7-colour dot matrix LCD on the microphone, live RSSI, 5-step brightness with dimmer
• Squelch: 9 levels; 50 CTCSS and 104 DCS codes
• Power: 12V DC (10A input rating), fused power lead included
• Antenna: ATEBR660-2PK elevated-feed barrel spring base with twin whips, UHF CB 477MHz ground independent
• Whips: 2.3dBi – 140mm whip, 440mm overall; 6.6dBi – 680mm whip, 980mm overall
• Spring barrel: Ø45mm
• Antenna cable: 4.5m low-loss coax, FME female with PL-259 adapter
• Mount: black Z bracket
• Antenna connection: external antenna socket (SO-239, for PL-259 plug)
• Accessory port: 3.5mm audio jack
• Base dimensions: 106.5mm W × 29.5mm H × 120mm D
• Base weight: 364g (with bracket)
• Microphone: 107 × 64 × 37mm (with hook), 254g

What’s in the Box

• 1 × EXG3000 UHF CB radio with LCD speaker microphone
• 1 × quick-release mounting bracket
• 1 × magnetic microphone hanger
• 1 × 12V DC power lead with fuse
• 1 × 2m microphone extension cable
• 1 × extension cable adapter
• Mounting hardware
• 1 × ATEBR660 antenna base with 4.5m coax and PL-259 adapter
• 1 × 2.3dBi whip
• 1 × 6.6dBi whip
• 1 × black Z bracket
• 1 × user guide

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 5 years with free online product registration.

*Talk range varies with antenna, terrain, obstructions and conditions.

The ECOXGEAR ATRDM660ST is a medium-duty 6.6dBi UHF CB antenna for overlanding and 4WD touring across flat, open country, where its longer, flatter radiation pattern gives the extra reach that a short whip cannot. It is a slimmer alternative to the heavy-duty ATRD series, with a smaller Ø45mm spring and a shorter whip: the 880mm fibreglass radome whip sits on an interchangeable medium barrel-style stainless steel spring for a total length of 994mm. A 4.5m low-loss coax lead with a flexible, UV-resistant TPE jacket and a pre-terminated FME connector with PL259 adapter make fitting straightforward, while the stealth matte finish keeps glare down when driving at night.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 6.6dBi gain for open country: higher gain with a longer, flatter radiation pattern for extra reach across flat, open terrain
• Medium-duty radome construction: fibreglass radome whip with an aluminium ferrule protects the antenna element from scrub, stone strikes and weather, in a slimmer package than the heavy-duty ATRD series
• Interchangeable medium barrel spring: matte-coated stainless steel spring, Ø45mm at its widest, absorbs knocks and lets the whip flex through scrub
• Stealth matte finish: low sheen for diffused reflectivity under night lighting, so there is less glare from headlights and campsite lights
• 4.5m low-loss coax cable: TPE jacket for flexibility, UV resistance and abrasion protection on the run through the engine bay or A-pillar
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• 30mm mount thread: longer thread for a more secure fit in most bull bar and bonnet mounting brackets
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Swappable whip: the whip unscrews from the spring (Allen key included), so you can fit the shorter 2.3dBi WPRDM230ST whip for hilly country or replace a damaged whip with a WPRDM660ST

Specifications

• Model: ATRDM660ST
• Antenna type: medium-duty fibreglass radome, overlanding and off-road
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 6.6dBi
• Total length (including spring): 994mm
• Whip length: 880mm
• Spring: interchangeable medium barrel-style stainless steel, matte coated, Ø45mm at widest point
• Ferrule: aluminium
• Cable: 4.5m low-loss coax, TPE jacket
• Connector: FME female (pre-terminated), PL259 adapter included
• Mount thread length: 30mm
• Finish: stealth matte black

What’s in the Box

• 1 × ATRDM660ST antenna (whip, spring and 4.5m coax lead)
• 1 × Allen key
• 1 × PL259 adapter
• 1 × embossed weather cap

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATRDM230ST is a medium-duty 2.3dBi UHF CB antenna for overlanding and 4WD touring – a slimmer alternative to the heavy-duty ATRD series, with a smaller Ø45mm spring and a shorter whip. Its 500mm fibreglass radome whip sits on an interchangeable medium barrel-style stainless steel spring for a total length of 613mm, and the lower 2.3dBi gain gives a rounder radiation pattern that holds signal on hilly and mountainous tracks. A 4.5m low-loss coax lead with a flexible, UV-resistant TPE jacket and a pre-terminated FME connector with PL259 adapter make fitting straightforward, while the stealth matte finish keeps glare down when driving at night.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 2.3dBi gain for hilly terrain: lower gain with a rounder radiation pattern, so the signal holds up on undulating, hilly and mountainous off-road tracks
• Medium-duty radome construction: fibreglass radome whip with an aluminium ferrule protects the antenna element from scrub, stone strikes and weather, in a slimmer package than the heavy-duty ATRD series
• Interchangeable medium barrel spring: matte-coated stainless steel spring, Ø45mm at its widest, absorbs knocks and lets the whip flex through scrub
• Stealth matte finish: low sheen for diffused reflectivity under night lighting, so there is less glare from headlights and campsite lights
• 4.5m low-loss coax cable: TPE jacket for flexibility, UV resistance and abrasion protection on the run through the engine bay or A-pillar
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• 30mm mount thread: longer thread for a more secure fit in most bull bar and bonnet mounting brackets
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Swappable whip: the whip unscrews from the spring (Allen key included), so you can fit the 6.6dBi WPRDM660ST whip for open country or replace a damaged whip with a WPRDM230ST

Specifications

• Model: ATRDM230ST
• Antenna type: medium-duty fibreglass radome, overlanding and off-road
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi
• Total length (including spring): 613mm
• Whip length: 500mm
• Spring: interchangeable medium barrel-style stainless steel, matte coated, Ø45mm at widest point
• Ferrule: aluminium
• Cable: 4.5m low-loss coax, TPE jacket
• Connector: FME female (pre-terminated), PL259 adapter included
• Mount thread length: 30mm
• Finish: stealth matte black

What’s in the Box

• 1 × ATRDM230ST antenna (whip, spring and 4.5m coax lead)
• 1 × Allen key
• 1 × PL259 adapter
• 1 × embossed weather cap

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATRD660ST is a heavy-duty 6.6dBi UHF CB antenna for 4WD touring across flat, open country, where its longer, flatter radiation pattern gives the extra reach that a short whip cannot. The 1048mm fibreglass radome whip sits on an interchangeable large barrel-style stainless steel spring for a total length of 1180mm. A 4.5m low-loss coax lead with a flexible, UV-resistant TPE jacket and a pre-terminated FME connector with PL259 adapter make fitting straightforward, while the stealth matte finish keeps glare down when driving at night.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 6.6dBi gain for open country: higher gain with a longer, flatter radiation pattern for extra reach across flat, open terrain
• Heavy-duty radome construction: fibreglass radome whip with an aluminium ferrule protects the antenna element from scrub, stone strikes and weather
• Interchangeable large barrel spring: matte-coated stainless steel spring, Ø55mm at its widest, absorbs knocks and lets the whip flex through scrub
• Stealth matte finish: low sheen for diffused reflectivity under night lighting, so there is less glare from headlights and campsite lights
• 4.5m low-loss coax cable: TPE jacket for flexibility, UV resistance and abrasion protection on the run through the engine bay or A-pillar
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• 30mm mount thread: longer thread for a more secure fit in most bull bar and bonnet mounting brackets
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Swappable whip: the whip unscrews from the spring (Allen key included), so you can fit the shorter 2.3dBi WPRD230ST whip for hilly country or replace a damaged whip with a WPRD660ST

Specifications

• Model: ATRD660ST
• Antenna type: heavy-duty fibreglass radome, off-road
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 6.6dBi
• Total length (including spring): 1180mm
• Whip length: 1048mm
• Spring: interchangeable large barrel-style stainless steel, matte coated, Ø55mm at widest point
• Ferrule: aluminium
• Cable: 4.5m low-loss coax, TPE jacket
• Connector: FME female (pre-terminated), PL259 adapter included
• Mount thread length: 30mm
• Finish: stealth matte black

What’s in the Box

• 1 × ATRD660ST antenna (whip, spring and 4.5m coax lead)
• 1 × Allen key
• 1 × PL259 adapter
• 1 × embossed weather cap

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATRD230ST is a heavy-duty 2.3dBi UHF CB antenna built for 4WD touring and off-road work. Its 530mm fibreglass radome whip sits on an interchangeable large barrel-style stainless steel spring for a total length of 660mm, and the lower 2.3dBi gain gives a rounder radiation pattern that holds signal on hilly and mountainous tracks. A 4.5m low-loss coax lead with a flexible, UV-resistant TPE jacket and a pre-terminated FME connector with PL259 adapter make fitting straightforward, while the stealth matte finish keeps glare down when driving at night.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 2.3dBi gain for hilly terrain: lower gain with a rounder radiation pattern, so the signal holds up on undulating, hilly and mountainous off-road tracks
• Heavy-duty radome construction: fibreglass radome whip with an aluminium ferrule protects the antenna element from scrub, stone strikes and weather
• Interchangeable large barrel spring: matte-coated stainless steel spring, Ø55mm at its widest, absorbs knocks and lets the whip flex through scrub
• Stealth matte finish: low sheen for diffused reflectivity under night lighting, so there is less glare from headlights and campsite lights
• 4.5m low-loss coax cable: TPE jacket for flexibility, UV resistance and abrasion protection on the run through the engine bay or A-pillar
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• 30mm mount thread: longer thread for a more secure fit in most bull bar and bonnet mounting brackets
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Swappable whip: the whip unscrews from the spring (Allen key included), so you can fit the 6.6dBi WPRD660ST whip for open country or replace a damaged whip with a WPRD230ST

Specifications

• Model: ATRD230ST
• Antenna type: heavy-duty fibreglass radome, off-road
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi
• Total length (including spring): 660mm
• Whip length: 530mm
• Spring: interchangeable large barrel-style stainless steel, matte coated, Ø55mm at widest point
• Ferrule: aluminium
• Cable: 4.5m low-loss coax, TPE jacket
• Connector: FME female (pre-terminated), PL259 adapter included
• Mount thread length: 30mm
• Finish: stealth matte black

What’s in the Box

• 1 × ATRD230ST antenna (whip, spring and 4.5m coax lead)
• 1 × Allen key
• 1 × PL259 adapter
• 1 × embossed weather cap

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATRD230 is a heavy-duty 2.3dBi UHF CB antenna built for 4WD touring and off-road work, in a standard black finish (the ATRD230ST is the stealth matte version). Its 530mm fibreglass radome whip sits on an interchangeable large barrel-style stainless steel spring for a total length of 660mm, and the lower 2.3dBi gain gives a rounder radiation pattern that holds signal on hilly and mountainous tracks. A 4.5m low-loss coax lead with a pre-terminated FME connector and PL259 adapter make fitting to a fixed-mount radio straightforward.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 2.3dBi gain for hilly terrain: lower gain with a rounder radiation pattern, so the signal holds up on undulating, hilly and mountainous off-road tracks
• Heavy-duty radome construction: fibreglass radome whip with an aluminium ferrule protects the antenna element from scrub, stone strikes and weather
• Interchangeable large barrel spring: elevated stainless steel barrel spring absorbs knocks and lets the whip flex through scrub
• 4.5m low-loss coax cable: enough length to run from a bull bar or bonnet mount to a dash-mounted radio
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Swappable whip: the whip unscrews from the spring (Allen key included), so a damaged whip can be replaced without rewiring
• Black heat-shrink fibreglass finish: plain black wrap over the radome
• Weather cap and Allen key included

Specifications

• Model: ATRD230
• Antenna type: heavy-duty fibreglass radome, off-road
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi
• Total length (including spring): 660mm
• Whip length: 530mm
• Spring: interchangeable large barrel-style stainless steel, elevated base
• Ferrule: aluminium
• Cable: 4.5m low-loss coax
• Connector: FME female (pre-terminated), PL259 adapter included
• Finish: black heat-shrink fibreglass wrap

What’s in the Box

• 1 × ATRD230 antenna (whip, spring and 4.5m coax lead)
• 1 × Allen key
• 1 × PL259 adapter
• 1 × weather cap

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATPA230 is a compact 2.3dBi UHF CB antenna on a strong magnetic base, so it can be put on any steel panel of a sedan, ute, 4WD or farm vehicle in seconds – no drilling, no brackets – and moved between vehicles just as easily. It stands 176mm tall, and the lower 2.3dBi gain gives a rounder radiation pattern that holds signal on hilly and mountainous ground. The 3.3m low-loss coax lead is pre-terminated with an FME female connector, and both a PL259 adapter for fixed-mount radios and an FME/SMA adapter for the EXG500 handheld are included. For best performance, mount it on the roof.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter) and the EXG500 handheld (FME/SMA adapter); both adapters included, radio sold separately.

Key Features

• Strong magnetic base: holds to any steel surface on the vehicle; the rooftop is recommended for the best signal
• 2.3dBi gain for hilly terrain: lower gain with a rounder radiation pattern, so the signal holds up on undulating, hilly and mountainous off-road tracks
• Compact 176mm antenna: low enough for car parks and garages, and easy to stow when not in use
• 3.3m low-loss coax cable: enough length to route from the roof through a door seal to the radio
• Two adapters included: pre-terminated FME female connector with a PL259 adapter for fixed-mount radios and an FME/SMA adapter for the EXG500 handheld
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Portable: sets up almost anywhere, so it suits work utes, farm vehicles and any car you would rather not drill

Specifications

• Model: ATPA230
• Antenna type: portable, magnetic base
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi
• Total length: 176mm
• Base: strong magnetic, for steel surfaces
• Cable: 3.3m low-loss coax
• Connector: FME female (pre-terminated); PL259 adapter and FME/SMA adapter included
• Finish: black heat-shrink fibreglass wrap

What’s in the Box

• 1 × ATPA230 magnetic-base antenna with 3.3m coax lead
• 1 × PL259 adapter
• 1 × FME/SMA adapter

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATEPL660-2PK is an on-road UHF CB antenna kit for cars, utes and 4WDs that spend most of their time on sealed roads, built around a slim elevated-feed parallel spring base – at Ø30mm it is the lower-profile of the two ECOXGEAR on-road kits (the ATEBR660-2PK uses a Ø45mm barrel spring). It comes with two interchangeable whips: a short 140mm 2.3dBi whip (390mm overall) whose rounder radiation pattern suits cities and built-up areas, and a 680mm 6.6dBi whip (930mm overall) with a longer, flatter pattern for long, flat highway runs. The 4.5m low-loss coax lead is pre-terminated with an FME female connector and a PL259 adapter is included, so it connects straight to a fixed-mount radio.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 2.3dBi short whip (140mm): lower gain with a rounder radiation pattern, the better choice in cities and built-up areas
• 6.6dBi long whip (680mm): higher gain with a longer, flatter radiation pattern for long, flat stretches of open road
• Easy whip changes: both whips share the one base, so you can swap to suit the trip instead of buying a second antenna
• Elevated-feed parallel spring base: slim Ø30mm stainless steel parallel spring lifts the feed point and lets the whip flex under car-park and carport clearances
• 4.5m low-loss coax cable: enough length to run from a bull bar, bonnet or gutter mount to a dash-mounted radio
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Black heat-shrink fibreglass whips: plain black wrap with a slim, low-key look

Specifications

• Model: ATEPL660-2PK
• Antenna type: on-road, elevated-feed parallel spring base with two whips
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi (short whip) or 6.6dBi (long whip)
• Whip lengths: 140mm (2.3dBi), 680mm (6.6dBi)
• Total length (including spring): 390mm with the 2.3dBi whip, 930mm with the 6.6dBi whip
• Spring: elevated stainless steel parallel spring, Ø30mm at widest point
• Cable: 4.5m low-loss coax
• Connector: FME female (pre-terminated), PL259 adapter included
• Finish: black heat-shrink fibreglass wrap

What’s in the Box

• 1 × ATEPL660 antenna base (elevated parallel spring with 4.5m coax lead)
• 1 × 2.3dBi whip (140mm)
• 1 × 6.6dBi whip (680mm)
• 1 × PL259 adapter

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXGEAR ATEBR660-2PK is an on-road UHF CB antenna kit for cars, utes and 4WDs that spend most of their time on sealed roads. One elevated-feed barrel spring base comes with two interchangeable whips: a short 140mm 2.3dBi whip (440mm overall) whose rounder radiation pattern suits cities and built-up areas, and a 680mm 6.6dBi whip (980mm overall) with a longer, flatter pattern for long, flat highway runs. The 4.5m low-loss coax lead is pre-terminated with an FME female connector and a PL259 adapter is included, so it connects straight to a fixed-mount radio.

Suits: ECOXGEAR ECOXTALK EXG1000 and EXG3000 fixed-mount UHF CB radios (PL259 adapter included; radio sold separately).

Key Features

• 2.3dBi short whip (140mm): lower gain with a rounder radiation pattern, the better choice in cities and built-up areas
• 6.6dBi long whip (680mm): higher gain with a longer, flatter radiation pattern for long, flat stretches of open road
• Easy whip changes: both whips share the one base, so you can swap to suit the trip instead of buying a second antenna
• Elevated-feed barrel spring base: stainless steel barrel spring, Ø45mm at its widest, lifts the feed point and lets the whip flex under car-park and carport clearances
• 4.5m low-loss coax cable: enough length to run from a bull bar, bonnet or gutter mount to a dash-mounted radio
• Pre-terminated FME female connector with PL259 adapter: connects to a fixed-mount UHF CB radio without cutting or crimping the cable
• UHF CB 477MHz, ground-independent design: does not rely on the vehicle body as a ground plane, so mounting position is flexible
• Black heat-shrink fibreglass whips: plain black wrap with a slim, low-key look

Specifications

• Model: ATEBR660-2PK
• Antenna type: on-road, elevated-feed barrel spring base with two whips
• Frequency: UHF CB 477MHz, ground-independent design
• Gain: 2.3dBi (short whip) or 6.6dBi (long whip)
• Whip lengths: 140mm (2.3dBi), 680mm (6.6dBi)
• Total length (including spring): 440mm with the 2.3dBi whip, 980mm with the 6.6dBi whip
• Spring: elevated stainless steel barrel spring, Ø45mm at widest point
• Cable: 4.5m low-loss coax
• Connector: FME female (pre-terminated), PL259 adapter included
• Finish: black heat-shrink fibreglass wrap

What’s in the Box

• 1 × ATEBR660 antenna base (elevated barrel spring with 4.5m coax lead)
• 1 × 2.3dBi whip (140mm)
• 1 × 6.6dBi whip (680mm)
• 1 × PL259 adapter

Warranty: 12-month ECOXGEAR Australia warranty.

The ECOXTALK EXG200 twin pack gives you two rugged 2-watt UHF CB handhelds that are IP67 waterproof and dustproof – and they float, with the LED torch switching on automatically so a dropped radio is easy to spot in the water. With all 80 Australian UHF CB channels, up to 13km of talk range* and 16 hours of operation from the included rechargeable AA batteries, they are ready for camping, 4WD convoys, fishing, hiking, kayaking and the worksite. Hands-free VOX, a built-in LED torch, a one-touch emergency channel and USB-C charging round out a pack that also includes a twin charging dock, earpiece microphones and a soft carry case.

Key Features

• 2W output, 80 UHF CB channels: full coverage of the Australian 476.4250–477.4125 MHz UHF CB band
• IP67 waterproof, dustproof and floats: the LED torch lights up automatically when the radio lands in water
• Up to 13km talk range*: line-of-sight range for convoys, campsites and open water
• 16 hours of operation: runs on 3 × AA batteries per radio, with NiMH rechargeables included
• USB-C charging with twin dock: charge both radios at once from the mains adapter, or from the included cigarette-lead adapter in the car
• Hands-free VOX: voice-activated transmit keeps your hands on the wheel, paddle or rod
• Built-in LED torch and one-touch emergency channel
• Large backlit LCD: easy-to-read display with simple channel and volume controls
• 50 CTCSS and 104 DCS codes: plus dual watch, channel scan, auto squelch, key lock and low-battery alert
• 2.5mm accessory jack: earpiece microphones included; belt clips with large strap ring

Specifications

• Model: EXG200-2PK (black)
• RF output power: 2.0W
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 13km*
• Ingress rating: IP67 (floats)
• Battery: 3 × AA NiMH rechargeable per radio (included)
• Operation time: up to 16 hours
• Charging: USB-C, twin charging dock included
• Accessory port: 2.5mm jack (earpiece/microphone)
• Dimensions: 203 × 61 × 48mm per radio
• Weight: 260g per radio

What’s in the Box

• 2 × EXG200 UHF CB handheld radios
• 2 × belt clips
• 6 × AA NiMH rechargeable batteries
• 1 × twin charging dock
• 1 × USB-C charging cable
• 1 × USB AC adapter
• 1 × USB cigarette-lead adapter
• 2 × earpiece microphones (2.5mm)
• 1 × soft carry case
• 1 × user guide

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 3 years with free online product registration.

*Talk range varies with terrain, obstructions and conditions.

The ECOXTALK EXG50 3-pack gives you three compact 500mW UHF CB handhelds – one each in black, orange and yellow, so everyone knows whose radio is whose. With all 80 Australian UHF CB channels, 50 CTCSS and 104 DCS codes, up to 3km of talk range* and 20-plus hours from a set of AAA batteries, they are an easy way to keep the whole family in touch around the campsite, on a walking track or at the park. Each radio has a large backlit channel display, a built-in LED torch, hands-free VOX and a micro-USB port that recharges NiMH AAA cells in the radio (batteries not included).

Key Features

• 500mW output, 80 UHF CB channels: full coverage of the Australian 476.4250–477.4125 MHz UHF CB band, including duplex on the repeater channels
• Up to 3km talk range*: suited to campsites, parks, beaches and short walks
• 20+ hours of operation: runs on 3 × AAA alkaline or NiMH rechargeable batteries per radio (not included)
• Micro-USB charging: recharges NiMH AAA cells inside the radio via the included cables
• Compact and light: 143mm tall and 124g with batteries – easy for small hands and pockets
• Large backlit channel LCD: with simple channel and volume controls and key lock
• 50 CTCSS and 104 DCS codes: plus dual watch, channel scan, auto squelch and 5 call tones
• Hands-free VOX: voice-activated transmit with three sensitivity levels
• Emergency call: hold the torch/lock key for five seconds to switch to channel 5 and send a call tone
• Built-in LED torch, low-battery alert and belt clip with large strap ring

Specifications

• Model: EXG50-3PK (black, orange and yellow)
• RF output power: 500mW
• Channels: 80 UHF CB
• Frequency range: 476.4250–477.4125 MHz
• Talk range: up to 3km*
• Squelch codes: 50 CTCSS, 104 DCS
• Battery: 3 × AAA alkaline or NiMH rechargeable per radio (not included)
• Operation time: 20+ hours
• Charging: micro-USB (charges NiMH cells in the radio)
• Dimensions: 143 × 49 × 39mm per radio (with belt clip)
• Weight: 124g per radio (with batteries)
• Colour: 1 × black, 1 × orange, 1 × yellow

What’s in the Box

• 3 × EXG50 UHF CB handheld radios (1 × black, 1 × orange, 1 × yellow)
• 3 × belt clips
• 3 × micro-USB charging cables

Warranty: 12-month ECOXGEAR Australia warranty, extendable to 3 years with free online product registration.

*Talk range varies with terrain, obstructions and conditions.

The ECOXGEAR Wired Dynamic Microphone plugs into the ¼" (6.35mm) microphone input on ECOXGEAR’s larger party speakers, turning them into a PA or karaoke system for backyard parties, school and sporting events, auctions and street performance. It is a 20cm handheld dynamic microphone on a 3m lead, so you can move around while the speaker does the work.

Suits: ECOXGEAR speakers with a ¼" (6.35mm) microphone input – the EcoBoulder Max, EcoBoulder+, EcoTrek and EcoXplorer, as well as the Defender, Defender 12V and EcoBoulder Ultra.

Key Features

• Genuine ECOXGEAR accessory: made for the ¼" microphone input on ECOXGEAR party speakers
• PA and karaoke: announcements, karaoke and speeches through your speaker
• 3m cable: room to move away from the speaker
• ¼" (6.35mm) jack: the standard microphone connector on ECOXGEAR party speakers
• Handheld dynamic microphone: 20cm long, 220g

Specifications

• Model: Wired Dynamic Microphone (GDI-EXDYMCR01)
• Type: wired dynamic, handheld
• Connector: ¼" (6.35mm) jack
• Cable length: 3.0m
• Microphone size: 200mm long × 50mm
• Weight: 220g

Warranty: Backed by ECOXGEAR Australia's manufacturer warranty.
