The upgraded solar panel generates electricity from both sides. The solar cell on the back side absorbs reflective and diffused sunlight, boosting 25% of conversion rate. IP68 waterproof and dustproof certified against harsh weather conditions.

Features/Specifications:
Peak Power: 80W
Connections: DC Output x 1
Power Voltage: 22.2V
Power Current: 3.55A
Open Circuit Voltage: 27.2V
Short Circuit Voltage: 3.65A
Dimensions: 906 x 528 x 27mm
Weight: 5.1kg
Warranty: 3 Years

IP68 waterproof and dustproof certified
Dual-Sided Panels Enhanced Solar Efficiency
Extra-white glass (92% transmittance rate)
Compatible with all Jackery power stations
2.8mm low iron full toughened glass
Certified by TÃœV SÃœD
Super Durable Design
Simple & Speedy Setup
Unique Rubberized Corners for extra protection
Reflective lined carrying bag included (designed to reflect extra solar energy)
2 Metre extension cable is included for extra charging distance
What's in the box?
1 x Jackery SolarSaga 80W Solar Panel
1 x High Reflective Storage Bag
1 x 2 Metre Extension Cable
1 x User Manual

With its compact and wireless design, Explorer 1000 is one of the best investments for your outdoor party. It could run most of your essential outdoor gear. It can also be your reliable backup power supply for fridges, CPAP/BiPAP, computers etc.

Features/Specifications:
Capacity: 1002Wh (43.2V 23.2Ah)
Connections: DC Input x 1 | AC Input x 1 | AC Output x 2 | CarPort (12V) x 1 | USB-C x 2 | USB-A x 2
Cell Chemistry: Lithium-ion Battery
Lifecycle: 1000 cycles to 80%+ capacity
Recharge Time (AC Adapter): 1.8 Hours
Recharge Time (12V Car Adaptor): 12 Hours
Recharge Time (SolarSaga 100W Solar Panel): 7.2 Hours
AC Input: 230V-50Hz / 10A Max
AC Output: 230V / 50Hz / 1000W (2000W Peak)
USB-A Output: Quick Charge 3.0 / 18W Max
USB-C Output: 12V / 3A
Car Output: 12V / 10A
DC Input: 12V-17.5V / 8A Max / Double to 16A Max
DC Output: 12V / 7A (6.5mm*1.4mm)
Weight: 11.5kg
Dimensions: 34 x 26.2 x 25.5cm
Certifications: CEC / DOE / FCC / UL / ROHS / CA Prop 65
Warranty: 3 Years

Full Charge in 1.8 Hours with an AC input
Lighter, smaller, always enjoyable
Pure sine wave inverter delivers stable power
1000 Watt output
Super Quiet mode (46dB)
Dual 100W PD Fast Charge
1002Wh (23.2Ah) Lithium Battery
Supports up to 8 Devices at once
Foldable Handle for portability ; Storage
Advanced Smart Screen shows input power, output power, and much more.
built-in MPPT controller for maximum eco-friendly solar recharging efficiency
Solar Charging with SolarSaga 80W ; 200W solar panels (sold separately)
What's in the box?
1 x Jackery Explorer 1000 Pro Portable Power Station
1 x Car Charger Cable
1 x AC Charge Cable
1 x DC7909 to DC8020 Adapter
1 x User Manual

Single Outlet, Surge Protection, LED Indicator, Directly plug into your wall outlet, 175 Joules

Features/Specifications:
Single Outlet
Surge Protection
Directly plug into your wall outlet
175 Jules

AC Input: 230-240 VAC - 50Hz 10A
Max Loading: 10A or 2400 Watt (max)
Dimension: 73x43x53.7mm
Weight: 47.5g+10g
Surge Protection: 175 joules with LED indicator
Warranty: 2 Year

Cat6A U/FTP Cable 23AWG with PVC Jacket, Blue, 305m in Reelex packaging

Features/Specifications:
Accessory Type: Network Cables
Warranty: Limited Lifetime

Cat 6A Network Cable suitable for up to 10 Gigabit networking speeds
23AWG Solid Bare Copper
U/FTP ? Unshielded Foiled Twisted Pair
Long Distance PoE and PoE+ Support
High Purity Oxygen-Free Copper
RoHS Compliant PVC Jacket
305m in licenced REELEX Packaging System ? No tangles, No twists, No overruns, No pigtails. Less waste, Less environmental impact
Fluke Tested
Conforms to ANSI/TIA-568-C.2, ISO/IEC 11801, EN 50288
FCC, CPR, ISO, CE, ROHS, TLC certified
Australian RCM Certified

Datasheet 1

25G SFP28 to SFP28 Direct Attach Cable 1 Metre

Features/Specifications:
Speed: 25 Gbps Ethernet
Cable Length: 1m
Accessory Type: Stacking / DAC Cables
Warranty: Limited Lifetime

SFP28
25 Gbps Gigabit Ethernet
Fully Compliant with the following standards: SFF-8402, SFF-8432, EIA-364, EIA-364-1000.01, UL 94

datasheet

CyberPower VP700ELCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes and brownouts. Designed with GreenPower UPS Technology.

Features/Specifications:
Phase: Single Phase
Form Factor: Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Generator Compatibility: Yes
Nominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 167 ~ 295
Input Frequency ( Hz ): 50 ± 5 | 60 ± 5
Rated Input Current ( A ): 3.04
Input Connector Type: IEC C14
Power Cord Length (m.): 1.5
Output Capacity (Watts): 390
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
Overload Protection: Circuit Breaker
Outlet(s) - Total: 3
Outlet(s) - Battery ; Surge Protected: 3
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 10
Runtime at Full Load ( min ): 1
Typical Recharge Time ( Hours ): 8
Start On Battery: Yes
User-replaceable: No
Battery Type: Sealed Lead-acid
Surge Suppression ( Joules ): 450
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault ; Warning, Other Information
LCD Setting ; Control: Mode Setting, Alarm Setting, Input ; Output, Battery Setting, Fault ; Warning
HID Compliant USB Port(s): 1
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): USB Cable x1
Ethernet Data Transmission Speed: Up to 1Gbps
Power Management Software: PowerPanel Personal (Recommended)
Enclosure Construction: Plastic
Dimensions: 100 x 227 x 260mm
Weight: 5.14kg
Certifications: CE, RCM

Line-interactive UPS Topology
Generator Compatible
Automatic Voltage Regulation (AVR)
High-speed Ethernet Data Transmission
Surge and Spike Protection
PowerPanel Management Software
Energy Saving Technology
Simulated Sine Wave Output
LCD Status Display
USB Connectivity Port
Serial Connectivity Port

Form Factor: Tower

CyberPower VP1600ELCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes and brownouts. Designed with GreenPower UPS Technology.

Features/Specifications:
Phase: Single Phase
Form Factor: Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Generator Compatibility: Yes
Nominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 167 ~ 295
Input Frequency ( Hz ): 50 ± 5 | 60 ± 5
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 6.96
Input Connector Type: IEC C14
Power Cord Length (m.): 1.5
Output Capacity (Watts): 960
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
Overload Protection: Circuit Breaker
Outlet(s) - Total: 4
Outlet(s) - Battery ; Surge Protected: 3
Outlet(s) - Surge-Only Protected: 1
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 11
Runtime at Full Load ( min ): 2
Typical Recharge Time ( Hours ): 8
Start On Battery: Yes
User-replaceable: No
Battery Type: Sealed Lead-acid
Surge Suppression ( Joules ): 450
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault ; Warning, Other Information
LCD Setting ; Control: Mode Setting, Alarm Setting, Input ; Output, Battery Setting, Fault ; Warning
HID Compliant USB Port(s): 1
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): USB Cable x1
Ethernet Data Transmission Speed: Up to 1Gbps
Power Management Software: PowerPanel Personal (Recommended)
Enclosure Construction: Plastic
Dimensions: 100 x 281 x 355mm
Weight: 10.42kg
Certifications: CE, RCM

Line-interactive UPS Topology
Generator Compatible
Automatic Voltage Regulation (AVR)
High-speed Ethernet Data Transmission
Surge and Spike Protection
PowerPanel Management Software
Energy Saving Technology
Simulated Sine Wave Output
LCD Status Display
USB Connectivity Port
Serial Connectivity Port

Form Factor: Tower

CyberPower CPSURGE08USB-ANZ is ideal for expensive home theatre system and audio/video devices protection. MOV technology guards the surge suppressor and connected electronics such as phone, network, and communication equipment against surge/spikes.

Features/Specifications:
Input Voltage Range ( Vac ): 240
Input Frequency ( Hz ): 50
Maximum Input Current ( A ): 10
Power Cord Length (m.): 2
Overload Protection: Circuit Breaker
Over Current Protection ( A ): 10
Outlet(s) - Total: 8
USB Charging Port(s): USB-A x 2
USB-A Charging Output: 5 V/ 2.4 A
Surge Suppression ( Joules ): 2750
Maximum Surge Voltage ( V ): 6000
Maximum Surge Current ( A ): 67500
Maximum Surge Current (L-N, L-G, N-G) ( A ): Line to Neutral (L-N): 37500 | Line to Ground (L-G): 15000 | Neutral to Ground (N-G): 15000
Response Time ( ns ): < 1
EMI/RFI Filtration ( Hz ): 150KHz ~ 100MHz
Attenuation ( dB ): Up to 32 dB
Form Factor: Strip
Keyhole Mounting Slots: Yes
Dimensions: 276 x 130 x 32mm
Weight: 612g
Certifications: RCM

Fire Resistant
Surge Protection
Overload Protection
Computer-grade Protection
Keyhole Mounting Slots
EMI and RFI Filtration
USB Charging Port(s)
Best-in-class Dustproof Design

Form Factor: Powerboard
AC Outlets: 8
Output Port: USB-A

CP Smart App Tower 750VA UPS

Features/Specifications:
Phase: Single Phase
Form Factor: Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 151 - 301
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: AU x 1 | IEC C14 x 1
Power Cord Length: 1.83m
Capacity (VA): 750
Capacity (Watts): 675
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 5 %
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Power Factor: 0.9
Automatic Voltage Regulation (AVR): Double Boost | Single Buck
Overload Protection: Internal Current Limiting
Outlet(s) - Total: 6
Outlet Type: IEC C13 x 6
Outlet(s) - Battery & Surge Protected: 6
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 10.5
Runtime at Full Load ( min ): 2.5
Typical Recharge Time ( Hours ): 8
Quick Recharge Time ( Hours ): 3
Start On Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Cartridge (RBP): RBP0014
Battery Cartridge (RBP) Quantity ( pcs ): 1
Surge Suppression ( Joules ): 405
EMI/RFI Filtration: Yes
LCD Type: Detachable LCD Panel
LCD Information Display: Operation Type | Power Status | Battery Status | Load Status | Fault & Warning | Other Information | Event & Log
LCD Setting & Control: Mode Setting | Alarm Setting | Input & Output | Battery Setting | Fault & Warning | Event & Log
LED Indicators: Power On | Line Mode | Battery Mode | UPS Fault | Replace Battery
HID Compliant USB Port(s): 1
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode | Low Battery | Overload | UPS Fault
Management Cable ( pcs ): Power Cord x2 | USB Cable x1 | EPO Cable x1
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Dimensions: 136 x 162 x 349mm
Weight: 12.3kg
Certifications: CE | EAC | RCM | RoHS
Warranty: 3 Years

Line-interactive UPS Topology
Active PFC Compatible
Automatic Voltage Regulation (AVR)
Hot-swappable Batteries
EMI and RFI Filtration
Detachable LCD Panel
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Pure Sine Wave Output
Overload Protection
Surge and Spike Protection
LCD Status Display
USB Connectivity Port
PowerPanel Management Software
Tower Form Factor
What's in the box?
1 x PR750ELCD UPS
1 x Power Cord
1 x USB Cable
1 x EPO Cable
1 x User Manual

CyberPower Systems PRO series 2200VA / 1980W Tower UPS with LCD - 10A - 4* 12V/9AH - 8x IEC - 3 Yrs Adv. Replacement WTY 2 Yrs on internal Batteries

Features/Specifications:
Form Factor: Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 151 - 296
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14 ?
Detachable Power Cord Plug Type: AU x 1 | IEC C14 x 1
Power Cord Length: 3.05m
Output Capacity (VA): 2200
Output Capacity (Watts): 1980
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Double Boost, Single Buck
Overload Protection: Internal Current Limiting, Circuit Breaker
Outlet(s) - Total: 8
Outlet Type: IEC C13 x 8
Outlet(s) - Battery & Surge Protected: 8
Typical Transfer Time ( ms ): 4
BATTERYRuntime at Half Load ( min ): 12
Runtime at Full Load ( min ): 3
Typical Recharge Time ( Hours ): 8
Start On Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Type: Sealed Lead-acid
Battery Cartridge (RBP): RBP0116
Battery Cartridge (RBP) Quantity ( pcs ): 1
Surge Suppression ( Joules ): 405
EMI/RFI Filtration: Yes
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Event & Log
LED Indicators: Power On
HID Compliant USB Port(s): 1
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): Power Cord x5, USB Cable x1, EPO Cable x1
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Dimensions: 170 x 221 x 432
Weight: 25.5kg
Online Thermal Dissipation ( BTU/hr ): 155
Certifications: CE | RCM
RoHS: Yes
Product Warranty: 3 Years
Battery Warranty: 2 Years

Line-interactive UPS Topology
Active PFC Compatible
Automatic Voltage Regulation (AVR)
Hot-swappable Batteries
EMI and RFI Filtration
USB Connectivity Port
PowerPanel Management Software
Tower Form Factor
Energy Saving Technology
Pure Sine Wave Output
Overload Protection
Surge and Spike Protection
LCD Status Display
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability

User Manual

CyberPower PR2000ERTXL2U guarantees power backup protection for home theatre, multimedia, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, and surveillance systems. UPS adopts line-interactive topology.

Features/Specifications:
Phase: Single Phase
Form Factor: Rackmount, Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
Nominal Input Voltage ( Vac ): 220 | 230 | 240
Input Voltage Range ( Vac ): 159 - 288
Adjustable Voltage Range ( Vac ): 151 - 302 Vac
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14
Power Cord Length (m.): 3
Output Capacity (Watts): 2000
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 220 ± 5% | 230 ± 5% | 240 ± 5%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Power Factor: 1
Automatic Voltage Regulation (AVR): Double Boost, Single Buck
Overload Protection: Internal Current Limiting, Circuit Breaker
Outlet(s) - Total: 10
Outlet Type: IEC C13 x 10
Outlet(s) - Battery & Surge Protected: 10
Outlet(s) - Critical Load (CL): 5
Outlet(s) - Non-Critical Load (NCL): 5
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 12.8
Runtime at Full Load ( min ): 4
Typical Recharge Time ( Hours ): 3
Start On Battery: Yes
Built-in Battery Management Module: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Type: Sealed Lead-acid
Battery Cartridge: RBP0129
RBP Quantity ( pcs ): 1
Battery Quantity (Each RBP) ( pcs ): 4
Compatible Extended Battery Module (EBM): BP48VP2U02 (Built-in Charger)
Max. EBM Quantity ( pcs ): Unlimited
Surge Suppression ( Joules ): 2430
EMI/RFI Filtration: Yes
Network Protection RJ45: 1-in, 1-out
LCD Orientation: Rotatable LCD Manual
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log
LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Communication
HID Compliant USB Port(s): 1
Dry Contact (with Relay): Yes
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault
Management Cable ( pcs ): Power Cord x3, USB Cable x1, Serial Cable x1, EPO Cable x1, Phone Line x1
Ethernet Data Transmission Speed: Up to 1Gbps
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
PowerPanel Cloud Service: Yes - 90 Days Free Trial
Enclosure Construction: Metal
Rackmount Rail: Yes
Rackmount Ears: Yes
Dimensions: 433 x 86.5 x 500mm
Weight: 34.4kg
Certifications: CE, FCC Class B, UL, cUL, RCM, VCCI, UKCA

Line-interactive UPS Topology
Active PFC Compatible
Toolless Battery Replacement
High Output Power Factor
Overload Protection
Quick Charging Technology
Extended Battery Module (EBM)
EMI and RFI Filtration
USB Connectivity Port
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Pure Sine Wave Output
Battery Management Technology
Automatic Voltage Regulation (AVR)
Critical/Non-critical Load Outlets
Hot-swappable Batteries
Surge and Spike Protection
LCD Status Display
Serial Connectivity Port
PowerPanel Management Software
Rack/Tower Convertible Configurations

Form Factor: Rackmount / Tower

CyberPower PR1000ERTXL2U guarantees power backup protection for home theatre, multimedia, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, and surveillance systems. UPS uses line-interactive topology.

Features/Specifications:
Phase: Single Phase
Form Factor: Rackmount, Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Energy Star Qualified: Yes
Active PFC Compatibility: Yes
Nominal Input Voltage ( Vac ): 220 | 230 | 240
Input Voltage Range ( Vac ): 159 - 288
Adjustable Voltage Range ( Vac ): 151 - 302 Vac
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14
Power Cord Length (m.): 3
Output Capacity (Watts): 1500
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 220 ± 5% | 230 ± 5% | 240 ± 5%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Power Factor: 1
Automatic Voltage Regulation (AVR): Double Boost, Single Buck
Overload Protection: Internal Current Limiting, Circuit Breaker
Outlet(s) - Total: 10
Outlet Type: IEC C13 x 10
Outlet(s) - Battery & Surge Protected: 10
Outlet(s) - Critical Load (CL): 5
Outlet(s) - Non-Critical Load (NCL): 5
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 19.3
Runtime at Full Load ( min ): 6.5
Typical Recharge Time ( Hours ): 3
Start On Battery: Yes
Built-in Battery Management Module: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Type: Sealed Lead-acid
Battery Cartridge: RBP0129
RBP Quantity ( pcs ): 1
Battery Quantity (Each RBP) ( pcs ): 4
Compatible Extended Battery Module (EBM): BP48VP2U02 (Built-in Charger)
Max. EBM Quantity ( pcs ): Unlimited
Surge Suppression ( Joules ): 2430
EMI/RFI Filtration: Yes
Network Protection RJ45: 1-in, 1-out
LCD Orientation: Rotatable LCD Manual
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log
LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Communication
HID Compliant USB Port(s): 1
Dry Contact (with Relay): Yes
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault
Management Cable ( pcs ): Power Cord x3, USB Cable x1, Serial Cable x1, EPO Cable x1, Phone Line x1
Ethernet Data Transmission Speed: Up to 1Gbps
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
PowerPanel Cloud Service: Yes - 90 Days Free Trial
Enclosure Construction: Metal
Rackmount Rail: Yes
Rackmount Ears: Yes
Dimensions: 433 x 86.5 x 500mm
Weight: 32kg
Certifications: CE, FCC Class B, UL, cUL, RCM, VCCI, UKCA

Line-interactive UPS Topology
Active PFC Compatible
Toolless Battery Replacement
High Output Power Factor
Overload Protection
Quick Charging Technology
Extended Battery Module (EBM)
EMI and RFI Filtration
USB Connectivity Port
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Pure Sine Wave Output
Battery Management Technology
Automatic Voltage Regulation (AVR)
Critical/Non-critical Load Outlets
Hot-swappable Batteries
Surge and Spike Protection
LCD Status Display
Serial Connectivity Port
PowerPanel Management Software
Rack/Tower Convertible Configurations

Form Factor: Rackmount / Tower

CP Pro 1000VA Rack UPS

Features/Specifications:
Phase: Single Phase
Form Factor: Rackmount | Tower
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Active PFC Compatibility: Yes
Nominal Input Voltage ( Vac ): 220 ± 5% | 230 ± 5% | 240 ± 5%
Input Voltage Range ( Vac ): 160 - 286
Adjustable Voltage Range ( Vac ): 150 - 300 Vac
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: AU x 1
Power Cord Length: 3m
Capacity (VA): 1000
Capacity (Watts): 800
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 220 ± 5 % | 230 ± 5 % | 240 ± 5 %
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Power Factor: 0.8
Automatic Voltage Regulation (AVR): Double Boost | Single Buck
Overload Protection: Internal Current Limiting
Outlet(s) - Total: 6
Outlet Type: IEC C13 x 6
Outlet(s) - Battery & Surge Protected: 6
Outlet(s) - Critical Load (CL): 2
Outlet(s) - Non-Critical Load (NCL): 4
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 12
Runtime at Full Load ( min ): 3.1
Typical Recharge Time ( Hours ): 6
Start On Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Battery Cartridge (RBP): RBP0027
Battery Cartridge (RBP) Quantity ( pcs ): 1
Surge Suppression ( Joules ): 810
EMI/RFI Filtration: Yes
LCD Information Display: Operation Type | Power Status | Battery Status | Load Status | Fault & Warning
LCD Setting & Control: Alarm Setting | Input & Output | Battery Setting
LED Indicators: Power On
HID Compliant USB Port(s): 1
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode | Low Battery | Overload | Overcharge | Overheat
Management Cable ( pcs ): Power Cord x2 | USB Cable x1 | Serial Cable x1 | EPO Cable x1
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
PowerPanel Cloud Service: Yes - 90 Days Free Trial
Enclosure Construction: Metal
Rackmount Ears: Yes
Dimensions: 430 x 44 x 490mm
Weight: 18kg
Installed Rack Height ( U ): 1
Online Thermal Dissipation ( BTU/hr ): 72
Certifications: CE | C-Tick | EAC | RoHS
Warranty: 3 Years

Line-interactive UPS Topology
Active PFC Compatible
Automatic Voltage Regulation (AVR)
Critical/Non-critical Load Outlets
Surge and Spike Protection
LCD Status Display
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Pure Sine Wave Output
Overload Protection
Hot-swappable Batteries
EMI and RFI Filtration
USB Connectivity Port
PowerPanel Management Software
Rack/Tower Convertible Configurations
What's in the box?
1 x PR1000ELCDRT1U UPS
1 x Rackmount Ears
1 x Screw Kit
1 x Power Cord
1 x USB Cable
1 x Serial Cable
1 x EPO Cable
1 x User Manual

CP Switched ATS 32Amp

Features/Specifications:
Phase: Single Phase
Dual Power Inputs: Yes
Nominal Input Voltage ( Vac ): 200 - 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ): 32
Input Connector Type: IEC 60309 32A x 2
Power Cord Length: 3.05m
Output Voltage ( V ): Depends on Input
Overload Protection: Circuit Breaker
Over Current Protection (Each Bank) ( A ): 20
Outlets - # of Bank(s): 2
Outlet(s) - Total: 18
Outlet(s) - Rear: 18
Outlet Type: IEC C19 x 2 | IEC C13 x 16
Remote Individual Outlet Control: Yes
LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Network Information | Serial Number | Environment Status | Hardware Version | Firmware Version
Hot-swappable LCD Module: Yes
LCD Setting & Control: Preferred Source | Source Configuration | Load Configuration | Outlet Control | LCD Settings | Reset / Reboot
LED Indicators: PDU Status | Source Status | Load | Tx/Rx | Link | Outlet
A-type USB Port: Yes
Connectivity Port: RJ45 | RJ45 (for Serial) | RJ45 (for ENVIROSENSOR/ Daisy Chain (In)) | RJ45 (for Daisy Chain (Out))
Environmental Sensor Supported: Yes
User-upgradeable Firmware: Yes
Power Management Software: PowerPanel Business (Recommended for small-medium scale management) | PowerPanel Enterprise (Recommended for large scale management)
Supported Protocols: IPv4/v6 | SNMPv1/v3 | HTTP/HTTPs | TCP/IP | UDP | DHCP | NTP | DNS | SMTP | SSH | SSL | TLS | Telnet | FTP | and Syslog
Authentication: RADIUS | LDAP | LDAPS | Windows AD
Installed Rack Height (U): 2
Form Factor: 2U Horizontal Rackmount
Enclosure Construction: Steel
Cord Retention Tray: Yes
IEC Receptacle Locking: Yes
External Site Ground Pin: Yes
Adjustable Mounting Brackets: 1 Set
Dimensions: 433 x 88 x 215mm
Weight: 7.8kg
Certifications: CE | FCC Class A | UL62368 | EN 55032 Class A | IEC 62368 | RoHS

User Manual
Product Brochure

CP Switched ePDU 32Amp

Features/Specifications:
Phase: Single Phase
Nominal Input Voltage ( Vac ): 200 - 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ): 32 (CE)
Input Connector Type: IEC 60309 32A x 1 ?
Power Cord Length: 3.05m
Output Voltage ( V ): Depends on Input
Overload Protection: Circuit Breaker
Over Current Protection (Each Bank) ( A ): 20
Idle Power Consumption ( W ): < 5
Outlets - # of Bank(s): 2
Outlet(s) - Total: 24
Outlet(s) - Front: 24
Outlet Type: IEC C13 x 21 | IEC C19 x 3
Remote Individual Outlet Control: Yes
LCD Information Display: Input Voltage (Volts) | Input Frequency (Hz) | Current Level (Amps) | Power Consumption (Kilowatts) | Network Information | Serial Number | Environment Status | Hardware Version | Firmware Version
Hot-swappable LCD Module: Yes
Auto LCD Orientation: Yes
LCD Setting & Control: Outlet Control | LCD Settings | Reset / Reboot
LED Indicators: PDU Status | Tx/Rx | Link | Outlet
A-type USB Port: Yes
Connectivity Port: RJ45 | RJ45 (for Serial) | RJ45 (for ENVIROSENSOR/ Daisy Chain (In)) | RJ45 (for Daisy Chain (Out))
Environmental Sensor Supported: Yes
User-upgradeable Firmware: Yes
Power Management Software: PowerPanel Business (Recommended for small-medium scale management) | PowerPanel Enterprise (Recommended for large scale management)
Supported Protocols: IPv4/v6 | SNMPv1/v3 | HTTP/HTTPs | TCP/IP | UDP | DHCP | NTP | DNS | SMTP | SSH | SSL | TLS | Telnet | FTP | and Syslog
Authentication: RADIUS | LDAP | LDAPS | Windows AD
Enclosure Construction: Steel
Cord Retention Tray: Yes
IEC Receptacle Locking: Yes
Adjustable Mounting Brackets: 1 Set
Dimensions: 56 x 1665 x 48mm
Weight: 8.0kg
Certifications: CE | EN 55032 Class A | RoHS
Warranty: 2 Years

Real-time Local/Remote Monitoring and Switching
Overload Protection
Ultra Low Power Consumption
Digital Real-time Load Display
Hot-swappable LCD Design
LED Status Indicator
Support ENVIROSENSOR
PowerPanel Management Software
Cord Retention Tray
Controllable Receptacles with Power Sequencing
Work under High Temperature
Industrial-grade Metal Housing
User Configurable Color LCD
Rotatable LCD for Proper Display Orientation
Firmware Upgrade via USB
User-upgradeable Firmware
Adjustable Mounting Brackets
IEC Receptacle Locking
What's in the box?
1 x PDU41405
1 x User Manual
1 x Product Registration Card
1 x Cord Retention Tray
1 x Mounting Brackets
1 x Cable Ties
1 x Screw Kit

User Manual
Product Brochure

CyberPower Systems Basic PDU 0RU vertical 10Amp IEC-320 C14 input - 20 IEC-320 (4-C19 & 16-C13) Out - 2 Yrs Adv. Replacement WTY

Features/Specifications:
Nominal Input Voltage ( Vac ): 200 - 240
Input Frequency ( Hz ): 50 / 60
Maximum Input Current ( A ): 10
Input Connector Type: IEC C14 x 1 ?
Power Cord Length: 3.05m
Output Voltage ( V ): Depends on Input
Overload Protection: Circuit Breaker
Over Current Protection (Each Bank) ( A ): 10
Outlets - # of Bank(s): 1
Outlet(s) - Total: 20
Outlet Type: IEC C19 x 4 | IEC C13 x 16 ?
Installed Rack Height (U): 0
Form Factor: 0U Vertical Rackmount
Enclosure Construction: Steel
Cord Retention Tray: Yes
External Site Ground Pin: Yes
Adjustable Mounting Brackets: 3 Set
Dimensions: 44.5 x 914.4 x 38.1mm
Weight: 2kg
Certifications: CE | UL60950
RoHS: Yes
Product Warranty: 2 Years

Overload Protection
Adjustable Mounting Brackets
Industrial-grade Metal Housing
Cord Retention Tray

User Manual
Product Datasheet

CP Smart App Rack 1000VA UPS

Features/Specifications:
Phase: Single Phase
Form Factor: Rackmount
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 165 - 271
Adjustable Voltage Range ( Vac ): 253 - 271 Vac | 189 - 207 Vac
Input Frequency ( Hz ): 50 ± 3 | 60 ± 3
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 10
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: IEC C14 x 1
Power Cord Length: 1.83m
Capacity (VA): 1000
Capacity (Watts): 600
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10 %
On Battery Frequency ( Hz ): 50 ± 10% | 60 ± 10%
Power Factor: 0.6
Automatic Voltage Regulation (AVR): Single Boost
Overload Protection: Internal Current Limiting | Circuit Breaker
Outlet(s) - Total: 6
Outlet Type: IEC C13 x 6
Outlet(s) - Battery & Surge Protected: 4
Outlet(s) - Surge-Only Protected: 2
Typical Transfer Time ( ms ): 4
Runtime at Half Load ( min ): 14
Runtime at Full Load ( min ): 3.5
Typical Recharge Time ( Hours ): 8
Start On Battery: Yes
User-replaceable: Yes
Hot-swappable: Yes
Replacement Battery Pack (RBP): RBP0025
Replacement Battery Pack (RBP) Quantity ( pcs ): 1
Surge Suppression ( Joules ): 810
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in | 1-out
LCD Information Display: Operation Type | Power Status | Battery Status | Load Status | Other Information
LCD Setting & Control: Mode Setting | Alarm Setting | Input & Output
LED Indicators: Power On
HID Compliant USB Port(s): 1
Serial Port: Dry Contact
Audible Alarms: Battery Mode | Low Battery | Overload | UPS Fault
Management Cable ( pcs ): Power Cord x4 | USB Cable x1
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Rackmount Ears: Yes
Dimensions: 433 x 44 x 389mm
Weight: 13.7kg
Installed Rack Height ( U ): 1
Online Thermal Dissipation ( BTU/hr ): 24
Certifications: CE | EAC | RCM | RoHS
Warranty: 2 Years

Line-interactive UPS Topology
Simulated Sine Wave Output
Overload Protection
Surge and Spike Protection
Phone/Fax/Modem/DSL/Network Protection
USB Connectivity Port
SNMP/HTTP Remote Management Capability (Optional)
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Hot-swappable Batteries
EMI and RFI Filtration
LCD Status Display
PowerPanel Management Software
What's in the box?
1 x OR1000ERM1U UPS
1 x Rackmount Ears
1 x Power Cord
1 x USB Cable
1 x User Manual

CyberPower OLS3000E is a high-performance UPS featuring online double-conversion topology, providing seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance, transportation, and emergency systems. Features/Specifications: Phase: Single Phase Form Factor: Tower 95% Active PFC Compatibility: Yes Generator Compatibility: Yes Nominal Input Voltage ( Vac ): 230 ± 10% Input Voltage Range ( Vac ): 190 - 300 Adjustable Voltage Range ( Vac ): 0-50% Load for 110 - 300 Vac | 0-60% Load for 140 - 300 Vac | 0-80% Load for 160 - 300 Vac | 0-100% Load for 190 - 300 Vac Input Frequency ( Hz ): 50 ± 10 | 60 ± 10 120% Load Immediately Overload Protection (Battery Mode): 110-120% Load for 10 sec, >120% Load Immediately Overload Protection (Bypass Mode): >130% Load Immediately Crest Factor: 3 : 1 Harmonic Distortion (Linear Load): THD?3% Harmonic Distortion (Non-linear Load): THD?5% Internal Bypass: Automatic Bypass, Manual Bypass Outlet(s) - Total: 6 Outlet Type: IEC C19 x 1 | Hardwire Terminal Block x 1 | IEC C13 x 4 Outlet(s) - Battery ; Surge Protected: 5 Typical Transfer Time ( ms ): 0 Runtime at Half Load ( min ): 14 Runtime at Full Load ( min ): 4 Typical Recharge Time ( Hours ): 5 Maximum Charging Current ( A ): 1 Start On Battery: Yes Smart Battery Management (SBM): Yes User-replaceable: No Battery Type: Sealed Lead-acid Compatible Extended Battery Module (EBM): BPSE72V45A Max. EBM Quantity ( pcs ): 3 Surge Suppression ( Joules ): 440 EMI/RFI Filtration: Yes Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault ; Warning, Other Information, Event ; Log LCD Setting ; Control: Mode Setting, Alarm Setting, Input ; Output, Battery Setting HID Compliant USB Port(s): 1 Emergency Power Off (EPO) Port: Yes Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery Management Cable ( pcs ): Power Cord x2, USB Cable x1, Phone Line x1 Power Management Software: PowerPanel Business (Recommended) SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205 Enclosure Construction: Metal Dimensions: 196 x 337 x 416mm Weight: 28.2kg Online (Double Conversion) UPS Topology Generator Compatible Zero Transfer Time Extended Battery Module (EBM) EMI and RFI Filtration LCD Status Display PowerPanel Management Software ECO Mode Overload Protection Smart Battery Management (SBM) Surge and Spike Protection Phone/Fax/Modem/DSL/Network Protection Emergency Power Off (EPO) Port SNMP/HTTP Remote Management Capability (Optional) Form Factor: Tower

CyberPower Systems Online S (A) 2000VA/1800W Rack UPS - 12V/9AHx4 - 8x IEC C13 - USB & Serial Port & SNMP Slot (optional RMCARD205) - 2 Yrs Adv. Replacement WTY - Incl Rail kit Features/Specifications: Phase: Single Phase Form Factor: Rackmount, Tower UPS Topology: Online Double Conversion Energy Saving Technology: Online ECO Mode Efficiency > 95% Active PFC Compatibility: Yes Generator Compatibility: Yes Nominal Input Voltage ( Vac ): 230 ± 10% Input Voltage Range ( Vac ): 190 - 300 Adjustable Voltage Range ( Vac ): 0-30% Load for 80 - 300 Vac | 0-50% Load for 120 - 300 Vac | 0-75% Load for 160 - 300 Vac | 0-90% Load for 190 - 300 Vac | 0-100% Load for 200 - 300 Vac Input Frequency ( Hz ): 50 ± 10 | 60 ± 10 Input Frequency Detection: Auto-sensing Rated Input Current ( A ): 9 Input Power Factor: 0.99 Input Connector Type: IEC C14 Power Cord Length (m.): 1.5 Output Capacity (Watts): 1800 On Battery Waveform: Pure Sine Wave On Battery Voltage(s) ( Vac ): 208 ± 1% | 220 ± 1% | 230 ± 1% | 240 ± 1% Output Voltage Setting: Configurable On Battery Frequency ( Hz ): 50 ± 0.5% | 60 ± 0.5% Output Frequency Setting: Configurable Power Factor: 0.9 ECO Mode Voltage Tolerance: ± 15 % Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse Overload Protection (Line Mode): 110-120% Load for 1 min, >120% Load Immediately Overload Protection (Battery Mode): 110-120% Load for 10 sec, >120% Load Immediately Overload Protection (Bypass Mode): >130% Load Immediately Crest Factor: 3 : 1 Harmonic Distortion (Linear Load): THD?3% Harmonic Distortion (Non-linear Load): THD?5% Internal Bypass: Automatic Bypass, Manual Bypass Outlet(s) - Total: 8 Outlet Type: IEC C13 x 8 Outlet(s) - Battery ; Surge Protected: 8 Outlet(s) - Critical Load (CL): 4 Outlet(s) - Non-Critical Load (NCL): 4 Typical Transfer Time ( ms ): 0 Runtime at Half Load ( min ): 11.9 Runtime at Full Load ( min ): 4 Typical Recharge Time ( Hours ): 4 Maximum Charging Current ( A ): 1.5 Start On Battery: Yes Smart Battery Management (SBM): Yes User-replaceable: Yes - Qualified Personnel Only Battery Type: Sealed Lead-acid Battery Cartridge: RBP0157 RBP Quantity ( pcs ): 1 Battery Quantity (Each RBP) ( pcs ): 4 Battery Voltage (Each RBP) ( V ): 48 Compatible Extended Battery Module (EBM): BPSE48V40ART2U Extended Battery Module Auto-detection: Yes Max. EBM Quantity ( pcs ): 3 Surge Suppression ( Joules ): 363 EMI/RFI Filtration: Yes Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault ; Warning, Other Information, Event ; Log LCD Setting ; Control: Mode Setting, Alarm Setting, Input ; Output, Battery Setting HID Compliant USB Port(s): 1 Dry Contact (with Relay): Yes Emergency Power Off (EPO) Port: Yes Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery Management Cable ( pcs ): Power Cord x2, USB Cable x1 Power Management Software: PowerPanel Business (Recommended) SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205 Enclosure Construction: Metal Rackmount Rail: Yes Rackmount Ears: Yes Dimensions: 438 x 88 x 430 Weight: 19.2kg Certifications: CE, RCM Online (Double Conversion) UPS Topology Generator Compatible Zero Transfer Time Extended Battery Module Auto-detection Critical/Non-critical Load Outlets Phone/Fax/Modem/DSL/Network Protection Variable Speed Fans PowerPanel Management Software Rack/Tower Convertible Configurations ECO Mode Overload Protection Smart Battery Management (SBM) Surge and Spike Protection EMI and RFI Filtration Color LCD Panel Emergency Power Off (EPO) Port SNMP/HTTP Remote Management Capability (Optional) Form Factor: Rackmount / Tower

CyberPower OLS2000E is a high-performance UPS featuring online double-conversion topology, providing seamless Pure Sine Wave power for mission-critical devices such as NAS and servers, DVRs/surveillance, transportation and emergency systems. Features/Specifications: Phase: Single Phase Form Factor: Tower 95% Active PFC Compatibility: Yes Generator Compatibility: Yes Nominal Input Voltage ( Vac ): 230 ± 10% Input Voltage Range ( Vac ): 160 ~ 300 Adjustable Voltage Range ( Vac ): 0~50% Load for 110 ~ 300 Vac | 0~60% Load for 120 ~ 300 Vac | 0~80% Load for 140 ~ 300 Vac | 0~100% Load for 160 ~ 300 Vac Input Frequency ( Hz ): 50 ± 10 | 60 ± 10 120% Load Immediately Overload Protection (Battery Mode): 110~120% Load for 10 sec, >120% Load Immediately Overload Protection (Bypass Mode): >130% Load Immediately Crest Factor: 3 : 1 Harmonic Distortion (Linear Load): THD?3% Harmonic Distortion (Non-linear Load): THD?5% Internal Bypass: Automatic Bypass, Manual Bypass Outlet(s) - Total: 5 Outlet Type: Hardwire Terminal Block x 1 | IEC C13 x 4 Outlet(s) - Battery ; Surge Protected: 4 Typical Transfer Time ( ms ): 0 Runtime at Half Load ( min ): 15 Runtime at Full Load ( min ): 5 Typical Recharge Time ( Hours ): 5 Maximum Charging Current ( A ): 1 Start On Battery: Yes Smart Battery Management (SBM): Yes User-replaceable: No Battery Type: Sealed Lead-acid Compatible Extended Battery Module (EBM): BPSE72V45A Max. EBM Quantity ( pcs ): 3 Surge Suppression ( Joules ): 440 EMI/RFI Filtration: Yes Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault ; Warning, Other Information, Event ; Log LCD Setting ; Control: Mode Setting, Alarm Setting, Input ; Output, Battery Setting HID Compliant USB Port(s): 1 Emergency Power Off (EPO) Port: Yes Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery Management Cable ( pcs ): Power Cord x2, USB Cable x1, Phone Line x1 Power Management Software: PowerPanel Business (Recommended) SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205 Enclosure Construction: Metal Dimensions: 196 x 337 x 416mm Weight: 23.8kg Certifications: CE, RCM Online (Double Conversion) UPS Topology Generator Compatible Zero Transfer Time Extended Battery Module (EBM) EMI and RFI Filtration LCD Status Display PowerPanel Management Software ECO Mode Overload Protection Smart Battery Management (SBM) Surge and Spike Protection Phone/Fax/Modem/DSL/Network Protection Emergency Power Off (EPO) Port SNMP/HTTP Remote Management Capability (Optional) Form Factor: Tower

CP 1500VA/1350W Tower UPS

Features/Specifications:
Phase: Single Phase
Form Factor: Tower
UPS Topology: Online Double Conversion
Energy Saving Technology: Online ECO Mode Efficiency > 95%
Active PFC Compatibility: Yes
Generator Compatibility: Yes
Nominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 160 - 300
Adjustable Voltage Range ( Vac ): 0-50% Load for 110 - 300 Vac | 0-60% Load for 120 - 300 Vac | 0-80% Load for 140 - 300 Vac | 0-100% Load for 160 - 300 Vac
Input Frequency ( Hz ): 50 ± 10 | 60 ± 10
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 6.5
Input Power Factor: 0.98
Input Connector Type: IEC C14
Detachable Power Cord Plug Type: AU x 1
Power Cord Length: 1.8m
Capacity (VA): 1500
Capacity (Watts): 1350
On Battery Waveform: Pure Sine Wave
On Battery Frequency ( Hz ): 50 ± 0.5% | 60 ± 0.5%
Power Factor: 0.9
ECO Mode Voltage Tolerance: ± 15 %
Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse
Overload Protection (Line Mode): 110-120% Load for 1 min, >120% Load Immediately
Overload Protection (Battery Mode): 110-120% Load for 10 sec, >120% Load Immediately
Overload Protection (Bypass Mode): >130% Load Immediately
Harmonic Distortion (Linear Load): THD?3%
Harmonic Distortion (Non-linear Load): THD?5%
Outlet(s) - Total: 4
Outlet Type: IEC C13 x 4
Outlet(s) - Battery & Surge Protected: 4
Typical Transfer Time ( ms ): 0
Runtime at Half Load ( min ): 14
Runtime at Full Load ( min ): 4
Typical Recharge Time ( Hours ): 5
Maximum Charging Current ( A ): 1
Start On Battery: Yes
Smart Battery Management (SBM): Yes
User-replaceable: No
Compatible Extended Battery Module (EBM): BPSE36V45A
Max. EBM Quantity ( pcs ): 3
Surge Suppression ( Joules ): 440
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
HID Compliant USB Port(s): 1
Emergency Power Off (EPO) Port: Yes
Management Cable ( pcs ): Power Cord x2, USB Cable x1, Phone Line x1
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Dimensions: 151 x 225 x 394mm
Weight: 15.3kg
Online Thermal Dissipation ( BTU/hr ): 420
Audible Noise at 1.5M from Surface of Unit: 45 dBA
Certifications: CE / RCM / RoHS
Warranty: 2 Years

Online (Double Conversion) UPS Topology
Generator Compatible
Zero Transfer Time
Extended Battery Module (EBM)
EMI and RFI Filtration
LCD Status Display
PowerPanel Management Software
ECO Mode
Overload Protection
Smart Battery Management (SBM)
Surge and Spike Protection
Phone/Fax/Modem/DSL/Network Protection
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability (Optional)
What's in the box?
1 x OLS1500E UPS
1 x Power Cord
1 x USB Cable
1 x Phone Line
1 x User Manual

Combination Door Lock, 2 per pack

Features/Specifications:
Installation: Hardware Included
Material: Plastic and Cold Rolled Steel
Handles per Package: 2
Dimensions: 3.6 x 16.0 x 4.5cm
Weight: 0.42kg
Certifications: RoHS

2 Handles per Set
Key Override
Reversible Handle Direction for Different Door Orientations
Installation Hardware Included

19Inch 6U 600mm depth Wall Mount Enclosure, hex perforated metal door, 60KG loading capacity

Features/Specifications:
Rack Height: 6 Units
Rack Door Type: Perforated Metal Door
Equipment Mounting Hole Type: Dual Mounting Hole (Square and #12-24)
Weight Capacity: 60kg
Maximum Mounting Depth: 56.2cm
Dimensions: 60 x 37.2 x 60cm
Weight: 16.9kg
Certifications: CE / DIN41491 / DIN41494 / EIA/ECA-310-E / IEC 60297-3-100 / RoHS

Square and #12-24 Threaded Mounting Holes
Hexagonal Perforated to Enhance Ventilation Capability
Easy Cable Access Top and Bottom
Reversible Front Door
Flexible Enclosure Configuration
Optional Caster Kit for Mobility
PCI DSS Compliant
Adjustable Mounting Depth
Doors and Side Panels with Keyed-alike Locks
Removable Doors and Side Panels
Rack U Numbering
Integrated Grounding Points
Optional Fan Kit for Increasing Ventilation

19inch 48U Rack Enclosure, Width: 600mm, Depth: 1200mm

Features/Specifications:
Product Category: Rack Enclosure
Rack Height (U): 48
Rack Door Type: Perforated Metal Door
Equipment Mounting Hole Type: Square Mounting Holes
Colour: Black
Dimensions: 60 x 120 cm
Leveling Feet: Preinstalled
Rolling Casters: Preinstalled
Stabilization Brackets: Yes
Joining Brackets: Yes
Removable Roof: Yes
Removable Door(s) and Side Panels: Yes
Reversible Front Door: Yes
Split Rear Door: Yes
Lockable Doors and Side Panels: Yes, Keyed-alike
Rack U Numbering: Yes
Ventilation: Perforated Door and Ventilated Roof
Heat Dissipation: Optional Fan Kit
Cable Management: Pre-installed Rails with Toolless Mounting Slots
Cable Access: Roof
Integrated Grounding: Yes
Certifications: CE | DIN41491 | DIN41494 | EIA/ECA-310-E | IEC 297-2 | RoHS
Warranty: 1-year

Industry Standard Depth Rack Enclosure
Hexagonal Perforated to Enhance Ventilation Capability
Removable Door(s) and Side Panels
Rear Accessory Channels with Toolless Mounting Slots
Reversible Front Door
Pre-installed Heavy Duty Leveling Feet
Shipping Brackets Included
Rack Row Bolt Hardware Included
Optional Fan Kit for Increasing Ventilation
Adjustable Mounting Depth
Doors and Side Panels with Keyed-alike Locks
Pre-installed Casters
Split Rear Door
Removable Enclosure Roof
Rack U Numbering
Easy Roof Cable Access
Integrated Grounding Points
PCI DSS Compliant
What's in the box:
Mini PC PN63
AC Adapter
Driver DVD (non-OS SKU only)
Power Cord
Screw Pack
User Manual
Warranty Card
Keyboard & Mouse (optional)
VESA Mount (optional)

19inch 48U Rack Enclosure, Width: 600mm, Depth: 1070mm

Features/Specifications:
Product Category: Rack Enclosure
Rack Height (U): 48
Rack Door Type: Perforated Metal Door
Equipment Mounting Hole Type: Square Mounting Holes
Colour: Black
Dimensions: 60 x 107 cm
Leveling Feet: Preinstalled
Rolling Casters: Preinstalled
Stabilization Brackets: Yes
Joining Brackets: Yes
Removable Roof: Yes
Removable Door(s) and Side Panels: Yes
Reversible Front Door: Yes
Split Rear Door: Yes
Lockable Doors and Side Panels: Yes, Keyed-alike
Rack U Numbering: Yes
Ventilation: Perforated Door and Ventilated Roof
Heat Dissipation: Optional Fan Kit
Cable Management: Pre-installed Rails with Toolless Mounting Slots
Cable Access: Roof
Integrated Grounding: Yes
Certifications: CE | DIN41491 | DIN41494 | EIA/ECA-310-E | IEC 297-2 | RoHS
Warranty: 1-year

Industry Standard Depth Rack Enclosure
Hexagonal Perforated to Enhance Ventilation Capability
Removable Door(s) and Side Panels
Rear Accessory Channels with Toolless Mounting Slots
Reversible Front Door
Pre-installed Heavy Duty Leveling Feet
Shipping Brackets Included
Rack Row Bolt Hardware Included
Optional Fan Kit for Increasing Ventilation
Adjustable Mounting Depth
Doors and Side Panels with Keyed-alike Locks
Pre-installed Casters
Split Rear Door
Removable Enclosure Roof
Rack U Numbering
Easy Roof Cable Access
Integrated Grounding Points
PCI DSS Compliant
What's in the box:
Mini PC PN63
AC Adapter
Driver DVD (non-OS SKU only)
Power Cord
Screw Pack
User Manual
Warranty Card
Keyboard & Mouse (optional)
VESA Mount (optional)

Datasheet 1
Datasheet 2

19Inch 45U 22-40Inch depth 4-POST Open Frame Rack, DEPTH ADJUSTABLE, 800KG loading capacity

Features/Specifications:
Rack Height: 45 Units
Equipment Mounting Hole Type: Square
Weight Capacity: 800kg
Maximum Mounting Depth: 101.6
Minimum Mounting Depth: 55.88
Dimensions: 60 x 210.4 x 104.9cm
Adjustable Depth: 59.2 - 104.9cm
Weight: 36.1kg
Certifications: DIN41491 / DIN41494 / EIA/ECA-310-E / IEC 60297-3-100 / RoHS
Warranty: 2 Years

Adjustable Depth Open Frame Rack
Rack U Numbering
Integrated Grounding Points
Toolless Mounting Slots and Included Cable Rings for Cable Management
Heavy Duty Leveling Feet Included

CyberPower Systems PFC Sinewave Series 1600VA / 1000W Tower UPS - 2U -6x IEC C13 (2x Surge Protection only) 12V/9Ah*2 2 Yrs Adv. Replacement WTY Incl. internal Batteries

User Manual
Product Brochure
Datasheet 1

CyberPower BR700ELCD offers home and office users a reliable battery backup and safeguards office PCs, network comms equipment, and other electronic devices from surges, spikes, and brownouts. Designed with GreenPower UPS Technology

Features/Specifications:
Phase: Single Phase
Form Factor: Desktop
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Nominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 170 - 290
Input Frequency ( Hz ): 50 ± 5 | 60 ± 5
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 3.18
Power Cord Length (ft.): 5
Power Cord Length (m.): 1.5
Output Capacity (Watts): 420
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
Overload Protection: Circuit Breaker
Outlet(s) - Total: 8
Outlet(s) - Battery & Surge Protected: 4
Outlet(s) - Surge-Only Protected: 4
Typical Transfer Time ( ms ): 4
USB Charging Port(s): USB-A x 1
USB Charging Current: 5 V/ 1 A
Runtime at Half Load ( min ): 9
Runtime at Full Load ( min ): 1.5
Typical Recharge Time ( Hours ): 8
Battery Type: Sealed Lead-acid
Battery Cartridge: RBP0083
RBP Quantity ( pcs ): 1
Surge Suppression ( Joules ): 125
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
LCD Panel: Yes
LCD Information Display: Power Status, Battery Status, Load Status, Other Information
LCD Setting & Control: Alarm Setting
HID Compliant USB Port(s): 1
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): USB Cable x1, Phone Line x1
Power Management Software: PowerPanel Personal (Recommended)
Enclosure Construction: Plastic
Dimensions: 166 x 118 x 288mm
Weight: 5.3kg
Certifications: CE, RCM

Line-interactive UPS Topology
Simulated Sine Wave Output
USB Charging Port(s)
Phone/Fax/Modem/DSL/Network Protection
PowerPanel Management Software
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Surge and Spike Protection
LCD Status Display
Wall Mount Installation

Form Factor: Powerboard

CyberPower BR1200ELCD offers home and office users a reliable battery backup and safeguards office PCs, network communication equipment, and other electronic devices from surges, spikes and brownouts. Designed with GreenPower UPS Technology.

Features/Specifications:
Phase: Single Phase
Form Factor: Desktop
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
INPUTNominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 170 - 290
Input Frequency ( Hz ): 50 ± 5 | 60 ± 5
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 5.45
Power Cord Length (m.): 1.5
Output Capacity (Watts): 720
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
Overload Protection: Circuit Breaker
Outlet(s) - Total: 8
Outlet(s) - Battery & Surge Protected: 4
Outlet(s) - Surge-Only Protected: 4
Typical Transfer Time ( ms ): 4
USB Charging Port(s): USB-A x 1
USB Charging Current: 5 V/ 1 A
Runtime at Half Load ( min ): 9
Runtime at Full Load ( min ): 2
Runtime at 60W ( min ): 80
Runtime at 90W ( min ): 51
Typical Recharge Time ( Hours ): 8
Battery Type: Sealed Lead-acid
Battery Cartridge: RBP0063
RBP Quantity ( pcs ): 2
Surge Suppression ( Joules ): 150
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
LCD Information Display: Power Status, Battery Status, Load Status, Other Information
LCD Setting & Control: Alarm Setting
HID Compliant USB Port(s): 1
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): USB Cable x1, Phone Line x1
Power Management Software: PowerPanel Personal (Recommended)
Enclosure Construction: Plastic
Dimensions: 166 x 118 x 288mm
Weight: 8.2kg

Line-interactive UPS Topology
Simulated Sine Wave Output
USB Charging Port(s)
Phone/Fax/Modem/DSL/Network Protection
PowerPanel Management Software
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Surge and Spike Protection
LCD Status Display
Wall Mount Installation

Form Factor: Powerboard

CyberPower BR1000ELCD offers home and office users a reliable battery backup and safeguards office PCs, network comms equipment, and other electronic devices from surges, spikes and brownouts. Designed with GreenPower UPS Technology.

Features/Specifications:
Phase: Single Phase
Form Factor: Desktop
UPS Topology: Line-interactive
Energy Saving Technology: GreenPower UPS Bypass Technology
Nominal Input Voltage ( Vac ): 230 ± 10%
Input Voltage Range ( Vac ): 170 - 290
Input Frequency ( Hz ): 50 ± 5 | 60 ± 5
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 4.55
Power Cord Length (m.): 1.5
Output Capacity (Watts): 600
On Battery Waveform: Simulated Sine Wave
On Battery Voltage(s) ( Vac ): 230 ± 10%
On Battery Frequency ( Hz ): 50 ± 1% | 60 ± 1%
Automatic Voltage Regulation (AVR): Single Boost, Single Buck
Overload Protection: Circuit Breaker
Outlet(s) - Total: 8
Outlet(s) - Battery & Surge Protected: 4
Outlet(s) - Surge-Only Protected: 4
Typical Transfer Time ( ms ): 4
USB Charging Port(s): USB-A x 1
USB Charging Current: 5 V/ 1 A
Runtime at Half Load ( min ): 6
Runtime at Full Load ( min ): 1
Runtime at 60W ( min ): 60
Runtime at 90W ( min ): 42
Typical Recharge Time ( Hours ): 8
Battery Type: Sealed Lead-acid
Battery Cartridge: RBP0117
RBP Quantity ( pcs ): 1
Surge Suppression ( Joules ): 150
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
LCD Panel: Yes
LCD Information Display: Power Status, Battery Status, Load Status, Other Information
HID Compliant USB Port(s): 1
Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ): USB Cable x 1, Phone Line x 1
Power Management Software: PowerPanel Personal (Recommended)
Enclosure Construction: Plastic
Dimensions: 166 x 118 x 288mm
Weight: 6.5kg

Line-interactive UPS Topology
Simulated Sine Wave Output
USB Charging Port(s)
Phone/Fax/Modem/DSL/Network Protection
PowerPanel Management Software
Energy Saving Technology
Automatic Voltage Regulation (AVR)
Surge and Spike Protection
LCD Status Display
Wall Mount Installation

Form Factor: Powerboard

Product Brochure
