Oxhorn Wireless Bluetooth 2D Desktop Barcode Scanner Commercial Grade USB Plug&Play 5V 1A Sensor Pixel Supported most of System Black

Oxhorn Wireless Bluetooth 2D Desktop Barcode Scanner Commercial Grade USB Plug&Play 5V 1A Sensor Pixel Supported most of System Black

Specification

Interface: USB(Drive free), serial port

Power Input: DC 5V 1A

Supported System: Windows，Mac OS，IOS, Linux，Unix，Android

Fast and reliable scanning helps improve productivity

Scanner parameters

Sensor: 640*480 CMOS

Pixel: 300,000 (640*480), High quality 1000000（1280*800）

Reading Precision: ≥5mil/0.127mm（PCS90%,CODE 39）

Scan rate: 30 Fps

Scan Pattern: Automatic induction continuous scan

Scanning angle: Horizontal : ±70° Vertical：±60° Rotated: ±360° (Test Conditions：CODE39,10mil/0.25mm,PCS90%)

Decoding Capability：

2D: QR Code, Micro QR Code, Data Matrix，PDF417,，etc…

1D: EAN-8、EAN-13、EAN-13 2 add-on、 EAN-13 5 add-on、ISSN、ISBN、UPC-A、UPC-E、Code11、Code 32、Code 39、Code 93、Code 128、Codabar、Industrial 2 of 5、Interleaved 2 of 5、Matrix 2 of 5、GS1-128、GS1 DataBar（RSS14）、GS1 DataBar Limited、GS1 DataBar Expanded， etc…

Interface：USB, serial port

Working Temperature: -20℃ to 55℃

Working Humidity: 5-95% Non-Condensed

Environment Light: 0-70000LUX

Environmental Sealing: IP54

Product Weight: 280g

Depth of Filed

Barcode Type Barcode Density Minimum Maximum

Code 39 20mil 10mm 150mm

Code 128 13mil 10mm 330mm

UPC/EAN 0.33mm(13mil) 10mm 290mm

QR Code 20.0mil 10mm 180mm

Data Matrix 10mil 10mm 110mm

PDF 417 6.67mil 15mm 120mm

*Testing Conditions: Environment Temperature = 24℃, Ambient Light Illumination = 300LUX

What’s in the Box:

1 x Desktop 2D Barcode Scanner

1 x USB cable

1 x User Manual

Warranty: 12 months

Part No.: UB-D202
