Simplecom SE502C SATA M.2 SSD to USB-C Enclosure USB 3.2 Gen1 5Gbps

SE502C is a compact and portable enclosure for SATA protocol based M.2 SSD. This enclosure features USB-C interface and complies with USB 3.2 Gen1 standard, which supports data transfer speeds of up to 5Gbps.

The design of this enclosure is lightweight and portable, and it can be easily slipped into your pocket or bag. The durable aluminium casing provides heat dissipation to ensure your drive doesn't get overheated while you're using. The tool-free design of the enclosure allows for quick and easy installation of SSDs without the need for any tools. It's USB powered, plug and play, allowing it to connect to a computer without the need for extra power or driver software, simplifies the user experience.

Features:

Designed for SATA protocol based M.2 SSD

Convert SATA M.2 SSD to a USB portable drive

USB-C interface and complies with USB 3.2 Gen1 standard

Support SuperSpeed USB data transfer speeds up to 5Gbps

Ultra-slim aluminium case, durable and portable

Tool-free design, quick and easy installation without any tools

USB-C and USB-A combo cable, convenient for use on different devices

Support USAP for added data transfer performance

USB bus powered, no external power required

Plug and play, no additional drivers required

Specifications

Model: SE502C

Interface: USB-C (USB 3.2 Gen 1)

Housing Material: Aluminium

Transfer Rate: up to 5Gbps

Compatible M.2 Protocol: SATA M.2

Compatible M.2 Size: 2242 / 2260 / 2280

Dimension: 94x40x10mm (LxWxH)

Operating System Support: Windows 7 and above, macOS 10.10 and above

Package Contents

1x SE502C SATA M.2 SSD Enclosure

1x USB-C + USB-A combo cable

Important Note

For SATA M.2 SSD Only, NOT compatible with NVMe M.2 SSD. SATA protocol based M.2 is B Key or B+M Key, will not fit M Key only NVMe M.2 module.

Warranty: 12 months

Simplecom SE109 Tool-free 2.5' SATA HDD SSD to USB-C Enclosure USB 3.2 Gen 1

Quick Overview

Compatible with 7mm and 9.5mm laptop 2.5' SATA HDD/SSD

USB-C interface compliant with USB 3.2 Gen 1 standard

Supports SuperSpeed USB data transfer rates up to 5Gbps

Tool-free installation allows to mount SATA drive in seconds

USB-C and USB-A combo cable, convenient for use on different devices

Supports USAP for faster data transfer speed and maximum performance

Supports TRIM command for optimized data writing to extend SSD life

Hot-swapping, plug and play, no additional driver needed

LED indicator for power and activity status

USB powered, no external power required

Description

Simplecom SE109 Tool-free 2.5' SATA HDD SSD to USB-C Enclosure USB 3.2 Gen 1

SE109 is a USB-C enclosure designed for 2.5' SATA HDDs and SSDs, compatible with both 7mm and 9.5mm SATA drives. It supports SuperSpeed data transfer rates of up to 5Gbps, ensuring fast and efficient file transfers.

With a tool-free design, installation takes just seconds, making it easy to swap drives whenever needed. The included USB-C and USB-A combo cable provides flexibility for use across various devices. With support for UASP and the TRIM command, it optimizes SSD performance, enhances data transfer speeds, and extends drive lifespan.

The enclosure is plug-and-play with hot-swapping capability, requiring no additional drivers or external power. An LED indicator provides real-time status updates for power and activity.

Features

Compatible with 7mm and 9.5mm laptop 2.5' SATA HDD/SSD

USB-C interface compliant with USB 3.2 Gen 1 standard

Supports SuperSpeed USB data transfer rates up to 5Gbps

Tool-free installation allows to mount SATA drive in seconds

USB-C and USB-A combo cable, convenient for use on different devices

Supports USAP for faster data transfer speed and maximum performance

Supports TRIM command for optimized data writing to extend SSD life

Hot-swapping, plug and play, no additional driver needed

LED indicator for power and activity status

USB powered, no external power required

Specifications

Model: SE109

Interface: USB-C (USB 3.2 Gen 1)

Date Transfer Rate: up to 5Gbps

Housing Material: ABS Plastic

Dimensions: 125x79x15mm (LxWxH)

Weight: 56g

Drive Support: 2.5' SATA HDD or SSD (7mm or 9.5mm thickness)

Operating System Support: Windows 7 and later, macOS 10.8 and later, Linux

Package Contents

1x SE109 USB-C Enclosure

1x USB-C + USB-A combo cable

1x User Manual

Warranty: 12 months

Simplecom SD562 Dual-Bay NVMe/SATA M.2 SSD RAID Enclosure with Offline Clone

SD562 is a high-performance dual-bay M.2 SSD enclosure designed for flexible storage expansion and efficient data management. Supporting both NVMe and SATA M.2 SSDs, it allows users to install two M.2 drives and operate them in multiple modes, including RAID 0, RAID 1, normal partition mode, and clone mode for quick duplication.

It helps manage and protect your data, making it a convenient solution for expanding storage capacity, enhancing data security, or configuring drives to suit different needs.

• Convenient and Fast

Featuring a USB 3.2 Gen 2 interface, this enclosure delivers data transfer speeds of up to 10Gbps, making it ideal for handling large files, backups, and system upgrades. The built-in offline cloning mode enables direct drive duplication without the need for a computer, providing a convenient solution for data migration.

• Durability and Reliability

Built with a durable aluminium enclosure, it ensures excellent heat dissipation, while the integrated cooling fan helps maintain stable performance during intensive operations. The tool-free design with a magnetic top cover allows for quick and hassle-free installation.

• Four Operating and RAID Modes

This enclosure offers various operating modes, including RAID 0, RAID 1, clone and normal partition modes. It provides flexibility in terms of storage configuration or data redundancy needs.

PM (Partition Mode): The enclosure operates as a standard external drive enclosure with no RAID configuration, treating each SSD as an independent drive. Two SSDs will appear as separate drive letters on the computer.

RAID 0: Disk striping mode that divides data into blocks and distributes them across two SSDs. This increases read and write performance, but it is not recommended for storing important data, as failure of one drive will result in total data loss.

RAID 1: Disk mirroring mode that provides data redundancy and fault tolerance by replicating data across two SSDs. This ensures files can be recovered if one drive fails.

CLONE: In this mode, the device operates as a standalone duplicator dock without being connected to a computer, allowing easy cloning of NVMe M.2 SSDs. It is ideal for data backup and migration.

Features

•Dual-bay NVMe/SATA M.2 SSD enclosure with 4 operating modes

•Supports RAID 0, RAID 1, clone and normal partition modes

•Allows simultaneous access to two M.2 SSDs in normal partition mode

•USB 3.2 Gen 2 interface with data transfer speeds up to 10Gbps

•Supports offline clone mode for standalone duplication without a host computer

•Built-in cooling fan effectively reduces operating temperatures

•Durable aluminium enclosure with excellent heat dissipation

•Tool-free installation with magnetic top cover

•Plug and play, no additional driver software required

•LED indicators for RAID mode, clone mode and drive activity status

Specifications

Model: SD562

Interface: USB-C (USB 3.2 Gen 2)

Transfer Rate: Up to 10Gbps

SSD Support: 2x NVMe M.2 or 2x SATA M.2 SSDs (NVMe and SATA M.2 cannot be used simultaneously)

SSD Size Support: 2230 / 2242 / 2260 (Source Slot only) / 2280

Operating Modes: RAID 0, RAID 1, Clone, normal Partition Mode

Cooling Fan: 20mm radial fan

Main material: Aluminium

Power Input: DC 5V/3A

Dimensions: 120x 68 x 22mm (LxWxH)

Weight: 208g (without SSD)

Supported Operating Systems: Windows 7 or later, macOS 10.8 or later

Package Contents

1x SD562 Dual-Bay M.2 SSD Enclosure

1x USB-C and USB-A Combo Cable

1x Power Adapter

2x Silicone thermal pads

2x Aluminium thermal pads

1x User Manual

Important Notes

•Only supports reading or cloning two SSDs with the same protocol (two M.2 NVMe SSDs or two M.2 SATA SSDs). NVMe and SATA M.2 SSDs cannot be used simultaneously in any of the four modes.

•Switching modes will format both SSDs. Please back up important data before switching modes to avoid data loss.

Warranty: 12 months

Simplecom SD511 M.2 SSD Docking Station NVMe and SATA Dual Protocol USB 3.2 Gen 2 10Gbps

Quick Overview

Dual Protocol support for both NVMe and SATA M.2 SSD

Compatible with M Key or B+M Key M.2 SSD

USB-C interface compliant with USB 3.2 Gen 2 standard

Supports data transfer rates up to 10Gbps

USB-C and USB-A combo cable, convenient for use on different devices

Supports USAP for faster data transfer speed and maximum performance

Supports TRIM command for improved data writing to extend SSD life

Plug and play, no driver required

LED indicator for power and activity status

USB powered, no external power required

Description

Simplecom SD511 M.2 SSD Docking Station NVMe and SATA Dual Protocol USB 3.2 Gen 2 10Gbps

SD511 is a high-speed, dual-protocol M.2 SSD Docking Station designed for both NVMe and SATA M.2 SSDs. Compatible with M Key and B+M Key M.2 SSDs, it provides a quick and hassle-free way to access M.2 SSD drives instantly through the USB port.

Featuring a USB 3.2 Gen 2 interface, it supports fast data transfer speeds of up to 10Gbps, ensuring efficient file transfers and optimal performance. With UASP and TRIM support, it enhances data transfer speeds, improves efficiency. For added convenience, the included USB-C and USB-A combo cable allows flexible connectivity across different devices. With a plug-and-play design, no drivers are needed for quick and hassle-free setup.

Compact, efficient, and easy to use, this M.2 SSD Docking Station is the perfect solution for high-speed data access and management.

Features

Dual Protocol support for both NVMe and SATA M.2 SSD

Compatible with M Key or B+M Key M.2 SSD

USB-C interface compliant with USB 3.2 Gen 2 standard

Supports data transfer rates up to 10Gbps*

USB-C and USB-A combo cable, convenient for use on different devices

Supports USAP for faster data transfer speed and maximum performance

Supports TRIM command for improved data writing to extend SSD life

Plug and play, no driver required

LED indicator for power and activity status

USB powered, no external power required

Specifications

Model: SD511

Material: ABS Plastic

Interface: USB-C (USB 3.2 Gen 2)

Transfer Rate: NVMe M.2 up to 10Gbps, SATA M.2 up to 6Gbps

Compatible M.2 Type: NVMe M.2, SATA M.2

Compatible M.2 Size: 2230 / 2242 / 2260 / 2280 / 22100

Dimension: 66 x 51 x13mm (LxWxH)

Weight: 40g

Operating System Support: Windows 7 and later, macOS 10.8 and later, Linux

Package Contents

1x SD511 M.2 SSD Docking Station

1x USB-C + USB-A combo cable

1x User Manual

Important Note

* SD511 supports both NVMe and SATA based M.2 SSD (M Key or B+M Key), bandwidth will be limited to 6Gbps when using SATA M.2 SSD, as maximum transfer rate of SATA M.2 SSD is 6Gbps

Warranty: 12 months

Simplecom SE101 Compact Tool-Free 2.5'' SATA to USB 3.0 HDD/SSD Enclosure

Simplecom SE101 USB 3.0 Enclosure it a lightweight and simple 2.5'' SATA to USB 3.0 HDD/SSD Enclosure, supports 2.5' SATA laptop internal HDD/SSD. SE101 is a bus-powered portable hard drive enclosure that provides fast USB 3.0 transfer speeds, supports hot-swap, plug and play. LED light indicates Power and Activity status.

SE101 features stylish and ultra compact design, compatible with 7mm and 9.5mm SATA 2.5' drives. Stylish matt surface prevents noticeable fingerprint and light scratches. Available in 4 colors choices: black, white, blue and transparent clear.

Features

Stylish matt surface prevents noticeable fingerprint and light scratches

Compatible with 7mm and 9.5mm laptop 2.5' SATA HDD/SSD

SuperSpeed USB 3.0 Interface, backwards compatible with USB 2.0/1.1

Easy installation allow to mount Hard Drive in seconds

Hot-swapping, plug and play, no additional driver needed

UASP mode boost speed up to 70% compared to regular USB 3.0

LED light indicates power and activity status

Specifications

Model: SE101

Name: USB 3.0 to 2.5'' SATA Enclosure

Interface: USB 3.0

UASP Mode Support: Yes

Dimensions: 118x76x13mm(LxWxH)

Weight: 47g

HDD Support: 2.5' SATA HDD or SSD (7mm or 9.5mm height)

Compatible with Windows XP and above, Linux, Mac OS 10.4 and above

Package Contents

1x SE101 Enclosure

1x USB 3.0 Cable

1x Foam Pad

1x User Manual

Warranty: 12 months

Simplecom SA110 M.2 SSD Aluminum Heatsink with Thermal Silicone Pads for PC and PS5

This M.2 SSD heatsink is specially designed for M.2 2280 SSD and suitable for desktop computer or PS5 console. It has good cooling effects which temperature can be reduced by 10 to 20 Celsius depending on environment.

This heatsink helps to cool your M.2 SSD to a safe temperature to avoid overheating and throttling, so the SSD can run at full speed and improving the performance of your computer.

It comes with two silicon thermal pads, provide good thermal conductivity and improve heat dissipation. Low profile design with 11mm thickness, compatible with desktop computer or PlayStation5 console.

Features

Designed for single sided M.2 2280 SSD

Cooling down M.2 SSD to a safe temperature

Low profile design and works with desktop computers and PS5

Aluminium groove design provides more heat dissipation area

Provides 10° C - 20° C all around cooling (Varies depending on environment)

Helps prevent overheating and throttling, improving the SSD performance

Silicone thermal pads provide good thermal conductivity

Specifications

Model: SA110

Material: Aluminum

SSD Compatibility: M.2 2280 SSD (single sided)

System Compatibility: Desktop Computer, PS5

Working Temperature: 0 - 70° C

Working Humidity: 20% RH to 90% RH

Weight: 26g (Heatsink only)

Dimensions: 75(L)×24(W)×11(H)mm

Package Contents

Heat sink x1

Thermal pad x2

Screw for heatsink x4

Mounting Screw for PS5 x1

Mounting Screw for desktop PC x1

Screwdriver x1

User manual x1

Warranty: 12 months

Simplecom EC318v2 PCI-e x4 to USB 3.2 Gen2x2 20Gbps USB-C Expansion Card

Quick Overview

- PCIe x4 expansion card, also compatible with PCIe x8 or x16 slots

- USB 3.2 Gen 2x2 interface supports data transfer rates of up to 20Gbps

- Adds 1x USB-C 20Gbps port to your desktop PC

- Backward compatible with USB 3.2 Gen 1, Gen 2, and earlier devices

- Built-in overcurrent protection

- Powered by PCIe, no external power required

- Integrated PCIe 12V to 5V module provides power to USB ports

- Plug and play, automatic installation on Windows

Simplecom EC318v2 PCI-e x4 to USB 3.2 Gen2x2 20Gbps USB-C Expansion Card

This PCIe x4 expansion card is an ideal solution for upgrading your desktop PC with high-speed USB connectivity. Featuring a USB 3.2 Gen 2x2 interface, this card delivers lightning-fast data transfer speeds of up to 20Gbps through a single USB-C port, ideal for modern devices requiring maximum performance.

This PCIe expansion card is compatible with PCIe x4, x8, and x16 slots, making it easy to integrate into various system configurations. Powered directly by the PCIe slot, it requires no external power supply, making installation simple and hassle-free. An integrated PCIe 12V to 5V module provides stable power to the USB ports for reliable performance.

This card is plug-and-play, with automatic installation on Windows operating systems for a hassle-free setup. Whether you are upgrading your desktop PC or building a new system, this expansion card is a reliable and high-performance addition to your PC.

Features

- PCIe x4 expansion card, also compatible with PCIe x8 or x16 slots

- USB 3.2 Gen 2x2 interface supports data transfer rates of up to 20Gbps

- Adds 1x USB-C 20Gbps port to your desktop PC

- Backward compatible with USB 3.2 Gen 1, Gen 2, and earlier devices

- Built-in overcurrent protection

- Powered by PCIe, no external power required

- Integrated PCIe 12V to 5V module provides power to USB ports

- Plug and play, automatic installation on Windows

Specifications

- PCIe Interface: PCIe 3.0 x4 (compatible with PCIe x8 or x16 slot)

- USB Standard: USB 3.2 Gen 2x2 20Gbps

- Connectors: 1x USB-C

- USB Speed Support: 20Gbps, 10Gbps, 5Gbps, 480Mbps

- USB Power Source: Integrated PCIe 12V to 5V module, SATA 15Pin (backup power only)

- Operating System Support: Windows 8 and above

Package Contents

- 1x USB 3.2 Gen 2x2 1-Port PCIe x4 Card

- 1x low profile bracket

Important Note

- The EC318v2 does not support DP Alt Mode or USB-C Power Delivery.

- The EC318v2 is designed for PCIe 3.0 interfaces. To achieve the full speed of USB 3.2 Gen 2x2, use a PCIe slot based on PCI Express 3.0 or a newer version on your motherboard.

- Actual data transfer speeds may be limited by the connected USB device. Please check your USB device's maximum supported speed.

- Thunderbolt 3 devices are supported but are only compatible with a 10 Gbps data transfer rate.

- Windows 7 is not supported.

Warranty: 24 months

Simplecom EC365 PCIe x4 to 2-Port USB 3.2 Gen II 10Gbps Type-C with Mini DisplayPort Input for USB-C DP Alt Mode Expansion Card

Upgrade your desktop PC with this 2-Port USB-C PCIe Expansion Card, designed to deliver high-speed data transfer and video integration through a single USB-C port. Featuring a mini DisplayPort input for video passthrough, it allows you to transmit video signals directly through the USB-C port, perfect for connecting to USB-C docking stations or USB-C monitors with display output capabilities.

With DP Alt Mode support on one USB-C port, it enables simultaneous data transfer and video output at resolutions up to 4K@60Hz. The USB 3.2 Gen 2 interface also provides fast 10Gbps data transfer speeds, ensuring efficient performance for external drives, peripherals, and displays.

The expansion card connects via a PCIe x4 interface, and is also compatible with x8 or x16 slots. Installation is straightforward and easy, the integrated 12V to 5V power module supplies stable power directly from the PCIe slot, no external power adapter required.

With plug-and-play compatibility for Windows 10 and later, this expansion card offers a simple solution to enhance your desktop’s connectivity for modern USB-C peripherals, monitors, and docking stations.

Features

•2-Port USB-C expansion card with miniDP input for video passthrough to USB-C

•One USB-C port supports DP Alt Mode with simultaneous data and video output

•miniDP input support video input resolutions up to 4K@60Hz

•Compatible with USB-C docking stations with video output capability

•Supports direct connection to USB-C monitors

•USB-C video output supports resolutions up to 4K@60Hz

•PCIe x4 interface, also compatible with PCIe x8 or x16 slot

•USB 3.2 Gen 2 interface supports data transfer rates of up to 10Gbps

•Built-in over current protection on each USB port

•Powered by PCIe, no external power required

•Built-in PCIe 12V to 5V modules provide power to USB ports

•Plug and play for Windows 10 and later operating system

Specifications

PCIe Interface: PCIe 3.0 x4, compatible PCIe x8 or x16 slot

USB Standard: USB 3.2 Gen 2, up to 10Gbps

Ports: 1× USB-C (Data only), 1× USB-C (Data + Video), 1× miniDP (Input)

USB Power Output: 5V/2A

Video Input Resolution: Up to 4K@60Hz (via miniDP)

Video Output Resolution: Up to 4K@60Hz (via USB-C with DP Alt Mode)

Power Source: Integrated PCIe 12V to 5V module

OS Support: Windows 10 and later

Package Contents

•1x PCIe Expansion Card

•1x Low Profile Bracket

•1x miniDP to DP Cable

Important Notes

•The miniDP port functions as a video input only.

•The miniDP port must be connected to the DisplayPort output on your motherboard or graphics card, the video signal will then pass through to the USB-C 2 port.

•Please note that this expansion card does not include a graphics processor, the USB-C video output is passed through from the miniDP input port.

•The USB-C 1 port supports data transfer only and does not support video output.

•If you plan to connect the mini DP port to the DisplayPort on your motherboard, please ensure your CPU has integrated graphics.

Warranty: 24 months

Simplecom EC315 PCIe x4 to 4-Port USB 3.2 Gen II 10Gbps Type-C and Type-A with Front Panel USB 3.0 and USB-C Key-A Expansion Card

Quick Overview

- PCIe x4 expansion card, also compatible PCIe x8 or x16 slot

- USB 3.2 Gen 2 interface supports data transfer rates of up to 10Gbps

- Integrated PCIe to USB 3.2 Gen 2 controller and USB 3.2 Gen 2 hub controller

- The USB ports on the rear panel and front panel can operate simultaneously

- Two rear panel connectors, 1x USB-C and 1x USB-A port

- Two internal connectors for front panel, USB 3.0 19/20-Pin and Key-A (Type-E) connectors

- Backwards compatible with USB 2.0 and USB 1.1 devices

- Built-in over current protection on each USB port

- Powered by PCIe, no external power required

- Built-in PCIe 12V to 5V modules provide power to USB ports

- Plug and play, automatic installation on Windows

Specifications

PCIe Interface: PCIe 3.0 x4, compatible PCIe x8 or x16 slot

USB Standard: USB 3.2 Gen 2 10Gbps

Rear Panel Connectors: 1x USB-A, 1x USB-C

Internal Connectors for Front Panel: 1x USB 3.0 19/20Pin socket (Front USB-A), 1x Key-A (Type-E) connector (Front USB-C)

USB Speed Support: SuperSpeed+ (10Gpbs), SuperSpeed (5Gpbs), HiSpeed (480Mbps), Full Speed (12Mbps)

USB Power Source: Integrated PCIe 12V to 5V module

Operating System Support: Windows 7 and above

Package Contents

1x USB 3.2 Gen 2 Expansion Card

1x Low Profile Bracket

System Requirement

1x available PCle 3.0 or higher x4/x8/x16 slot on motherboard, please note PCIe 1.0 or 2.0 x4 slot bandwidth is lower than 10Gbps

Plug and play for Windows 8 and above operating system, Windows 7 system need to install driver

Warranty: 24 months

SANDISK Optimus™ GX PRO 850X PCIe® 4.0 NVMe™ SSD with Heatsink, 2TB, Read 7,300MB/s Write 6,600MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX PRO 850X PCIe® 4.0 NVMe™ SSD with Heatsink, 1TB, Read 7,300MB/s Write 6,600MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX 7100 PCIe® 4.0 NVMe™ SSD, 500GB, Read 6,800MB/s Write 5,800MB/s, 5 Yr Warranty

Specifications

Capacity

500GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ 5100 PCIe® 4.0 NVMe™ SSD, 2TB, Read 7,100MB/s Write 6,700MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX PRO 850X PCIe® 4.0 NVMe™ SSD, 2TB, Read 7,300MB/s Write 6,600MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ 5100 PCIe® 4.0 NVMe™ SSD, 1TB, Read 7,100MB/s Write 6,700MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX 7100 PCIe® 4.0 NVMe™ SSD, 2TB, Read 7,250MB/s Write 6,900MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX PRO 850X PCIe® 4.0 NVMe™ SSD, 1TB, Read 7,300MB/s Write 6,600MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ 5100 PCIe® 4.0 NVMe™ SSD, 500GB, Read 6,600MB/s Write 5,600MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

SANDISK Optimus™ GX 7100 PCIe® 4.0 NVMe™ SSD, 1TB, Read 7,250MB/s Write 6,900MB/s, 5 Yr Warranty

Specifications

Capacity

256GB

Form Factor

M.2 2280

Sequential Read Performance

2400MB/s

Sequential Write Performance

900MB/s

Random Read

160K IOPS

Random Write

85K IOPS

Interface

PCIe Gen3 x4, NVMe v1.4

Warranty

5-Year Limited Warranty

Endurance (TBW)

650

Dimensions (L x W x H)

80mm x 22mm x 2.38mm

Weight

7.5gms

Operating Temperature

-40°C to 85°C

Non-Operating Temperature

-40°C to 95°C

Warranty: 60 months

4-Bay desktop NAS, Intel® Celeron® N4505 dual-core, 4 GB DDR4 onboard not expandable, 4 x 3.5'/2.5' SATA 6Gb/s drive bays, 2 x M.2 2280 PCIe Gen 3 x1 slots, 1 x 2.5GbE, 1 x PCIe Gen3 x2 slot, 1 x HDMI 2.0, 2 x USB 3.2 Gen 2 Type-A + 2 x USB 2.0

Warranty: 24 months

Oxhorn USB C 3.2 Gen 2 M.2 NVMe NGFF Enclosure 10 Gbps B+M Key M.2 NVMe SSD up to 4TB 2280/2260/2242/2230 Aluminum Macs Windows USB-A Black 2 YR WTY

Features:

For NVMe M.2 SSD

Supports M key , B+M key.

Supports M.2 NVMe SSD up to 4TB.

USB 3.2 Gen2 interface, up to 10Gbps transfer rate.

Quick and Easy Installation, tool-free installation

Supports Macs, Windows, Android, Linux, HarmonyOS

Aluminum case for better heat dissipation.

Plug and play

Two-year warranty

Specifications:

Performance:

Type and speed: USB 3. 2 Gen 2 – 10 Gbp/s

UASP Support: Yes

TRIM: Yes

Maximum drive capacity: Up to 4 TB SSD M.2

Environmental:

Operating temperature: 0 °C to 60 °C (32 °F to 140 °F)

Storage temperature: -20°C to 70°C (-4°F to 158°F)

Humidity: 10% ~ 90% R H

Hardware:

Interface: USB3. 2 Type C

Number of drives: 1

F a n ( s ) : No

What’s in the box

1 x USB 3.2 C M.2 SSD Enclosure

1 x USB C to C Cable

1 x USB A to C Cable

1 x Thermal Pad

Warranty: 24 months

Oxhorn USB 3.0 USAP 2.5″ SATA HDD SSD Enclosure Blue USB3.0 Cable (included) 2YR WTY

Features:

The UH-321 2.5 inch Super Speed USB 3. 0 SATA Hard Drive Enclosure turns a normal 2.5-inch SATA hard drive (HDD) or solid state drive(SSD) into a portable external hard drive.

Connecting to a host computer through USB3.0 with no external power required, this enclosure supports full Super Speed up to 5Gbps – 10 x faster than the USB 2.0 standard, and is back ward compatible with older USB connections (USB2.0) .

Large capacity drives (tested with up to 4TB) can be used to greatly enhance your computer’s storage / backup capabilities.

Featuring a light weight, portable design this USB 3.0 SATA HDD enclosure is constructed of aluminum, which offers maximum durability and operating heat dissipation.

Backed by a 2 – year warranty.

S p e c i f i c a t i o n s

P e r f o r ma n c e

T y p e a n d R a t e : U S B 3 . 0, 5 Gbps

UASP Support : Y e s

SATA I I I ( 6 Gb p s )

Ma x D r i v e C a p a c i t y : u p t o 4 T B h a r d d r i v e

E n v i r o n me n t a l

Op e r a t i n g T e mp e r a t u r e : 0 ° C t o 6 0 ° C ( 3 2 ° F t o 1 4 0 ° F )

S t o r a g e T e mp e r a t u r e : – 2 0 ° C t o 7 0 ° C ( – 4 ° F t o 1 5 8 ° F )

H u mi d i t y : 1 0 % ~ 9 0 % R H

H a r d w a r e

I n t e r f a c e : USB 3 . 0

N u mb e r o f D r i v e : 1

D r i v e S i z e : 2 . 5 i n

C o mp a t i b l e D r i v e T y p e s : S A T A

F a n ( s ) : N o

Wh a t ‘ s i n t h e B o x

1 x U S B t o S A T A E n c l o s u r e (UH-321)

1 x U S B 3 . 0 C a b l e

1 x U s e r Ma n u a l

Warranty: 24 months

Oxhorn USB C 3.2 Gen 2 M.2 NVMe NGFF Enclosure 10 Gbps B+M Key M.2 NVMe SSD up to 4TB 2280/2260/2242/2230 Aluminum Macs Windows USB-A Silver 2 YR WTY

Features:

For NVMe M.2 SSD

Supports M key , B+M key.

Supports M.2 NVMe SSD up to 4TB.

USB 3.2 Gen2 interface, up to 10Gbps transfer rate.

Quick and Easy Installation, tool-free installation

Supports Macs, Windows, Android, Linux, HarmonyOS

Aluminum case for better heat dissipation.

Plug and play

Two-year warranty

Specifications:

Performance:

Type and speed: USB 3. 2 Gen 2 – 10 Gbp/s

UASP Support: Yes

TRIM: Yes

Maximum drive capacity: Up to 4 TB SSD M.2

Environmental:

Operating temperature: 0 °C to 60 °C (32 °F to 140 °F)

Storage temperature: -20°C to 70°C (-4°F to 158°F)

Humidity: 10% ~ 90% R H

Hardware:

Interface: USB3. 2 Type C

Number of drives: 1

F a n ( s ) : No

What’s in the box

1 x USB 3.2 C M.2 SSD Enclosure

1 x USB C to C Cable

1 x USB A to C Cable

1 x Thermal Pad

Warranty: 24 months

Oxhorn USB 3.0 USAP 2.5″ SATA HDD SSD Enclosure Silver USB3.0 Cable (included) 2YR WTY

Features:

The UH-321 2.5 inch Super Speed USB 3. 0 SATA Hard Drive Enclosure turns a normal 2.5-inch SATA hard drive (HDD) or solid state drive(SSD) into a portable external hard drive.

Connecting to a host computer through USB3.0 with no external power required, this enclosure supports full Super Speed up to 5Gbps – 10 x faster than the USB 2.0 standard, and is back ward compatible with older USB connections (USB2.0) .

Large capacity drives (tested with up to 4TB) can be used to greatly enhance your computer’s storage / backup capabilities.

Featuring a light weight, portable design this USB 3.0 SATA HDD enclosure is constructed of aluminum, which offers maximum durability and operating heat dissipation.

Backed by a 2 – year warranty.

S p e c i f i c a t i o n s

P e r f o r ma n c e

T y p e a n d R a t e : U S B 3 . 0, 5 Gbps

UASP Support : Y e s

SATA I I I ( 6 Gb p s )

Ma x D r i v e C a p a c i t y : u p t o 4 T B h a r d d r i v e

E n v i r o n me n t a l

Op e r a t i n g T e mp e r a t u r e : 0 ° C t o 6 0 ° C ( 3 2 ° F t o 1 4 0 ° F )

S t o r a g e T e mp e r a t u r e : – 2 0 ° C t o 7 0 ° C ( – 4 ° F t o 1 5 8 ° F )

H u mi d i t y : 1 0 % ~ 9 0 % R H

H a r d w a r e

I n t e r f a c e : USB 3 . 0

N u mb e r o f D r i v e : 1

D r i v e S i z e : 2 . 5 i n

C o mp a t i b l e D r i v e T y p e s : S A T A

F a n ( s ) : N o

Wh a t ‘ s i n t h e B o x

1 x U S B t o S A T A E n c l o s u r e (UH-321)

1 x U S B 3 . 0 C a b l e

1 x U s e r Ma n u a l

Warranty: 24 months

OEM 512GB Gen4 NVMe SSD 3500/1625MB/s R/W 200TBW 220K/300K IOPS 1.5M hrs MTTF M.2 2280 PCIe 4 1yr wty

Warranty: 12 months

OEM 256GB Gen3 NVMe SSD 3100/1300 MB/s R/W 200TBW 220K/300K IOPS 1.5M hrs MTTF M.2 2280 PCIe 3 1yr wty

Warranty: 12 months

MSI SPATIUM S270 SATA 2.5' 960GB, PHISON S11, 3D NAND, SATA III 6Gbps, Sequential Read up to 500MB/s, Sequential Write up to 450MB/s, 250 TBW, 5Y WTY

SPECIFICATION

Capacity

960GB

Controller

PHISON S11

Flash Memory

3D NAND

Form Factor

SATA 2.5'

Interface

SATA III 6Gbps

Compatibility

SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps)

Dimensions

100.20mm (L) x 69.85mm (W) x 7.00mm (H)

Sequential Read up to (MB/s)

500

Sequential Write up to (MB/s)

450

Random Read 4KB up to (IOPS)

55K

Random Write 4KB up to (IOPS)

80K

Maximum Operating Power (W)

2.0

Idle Power PS3 (mW)

335

Low Power L1.2 (mW)

4.9

Operating Temperatures

0°C – 70°C

Storage Temperatures

-40°C – 85°C

Terabytes Written (TBW)

250

Mean Time Between Failure (MTBF)

Up to 2,000,000 Hours

Limited Warranty

5 Years, or the coverage for the maximum TBW as stated, whichever comes first.

Warranty: 60 months

MSI SPATIUM S270 SATA 2.5' 480GB, PHISON S11, 3D NAND, SATA III 6Gbps, Sequential Read up to 500MB/s, Sequential Write up to 450MB/s, 250 TBW, 5Y WTY

SPECIFICATION

Capacity

480GB

Controller

PHISON S11

Flash Memory

3D NAND

Form Factor

SATA 2.5'

Interface

SATA III 6Gbps

Compatibility

SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps)

Dimensions

100.20mm (L) x 69.85mm (W) x 7.00mm (H)

Sequential Read up to (MB/s)

500

Sequential Write up to (MB/s)

450

Random Read 4KB up to (IOPS)

55K

Random Write 4KB up to (IOPS)

80K

Maximum Operating Power (W)

2.0

Idle Power PS3 (mW)

335

Low Power L1.2 (mW)

4.9

Operating Temperatures

0°C – 70°C

Storage Temperatures

-40°C – 85°C

Terabytes Written (TBW)

250

Mean Time Between Failure (MTBF)

Up to 2,000,000 Hours

Limited Warranty

5 Years, or the coverage for the maximum TBW as stated, whichever comes first.

Warranty: 60 months

mbeat H3 USB 3.2 Gen2x2 20Gbps Dual M.2 NVMe SSD Dock with Clone Duplicator (Black)

Features

Dual SSD Dock & Clone Duplicator: Seamlessly connect two M.2 SSDs for instant data transfer and duplication tasks.

Versatile Data Transfer: Effortlessly supports various transfer modes including NVMe to NVMe or AHCI to NVMe, with offline clone capability for enhanced flexibility.

Wide Compatibility: Compatible with AHCI SSDs and B+M & M Key NVMe SSDs, accommodating sizes ranging from 2230, 2240, 2260, 2280 and 22110 for comprehensive compatibility.

High-Speed Transfers: Utilises USB 3.2 Gen2 technology to ensure lightning-fast data transfers at speeds of up to 20Gbps, while built-in LED indicators provide quick status checks during clone operations.

Cross-Platform Compatibility: Designed to seamlessly work with both Windows and Mac OS systems, ensuring versatility and ease of use across different platforms.

Specifications

USB Port: USB-C 3.2 Gen2 × 2

Data Speed: Max. 20Gbps for one SSD, 10Gbps per SSD for two

USB Compatibility: Backward compatible with USB 3.1/3.0/2.0 standard

Controller IC: JMS586U

SSD Interface: Supports B+M & M Key NVMe SSD

Clone Speed: Up to 15Gbps maximum (SSD requires minimum 2000MB/s read and1600MB/s write)

Supports SSD Size: M.2 SSD 2230/2242/2260/2280/22110

Supports OS: Windows 2000/2003/XP/Vista/7/8/8.1/10/11 and MAC OS

DC Power: Include +5V/3A Power supply

Cable Length: Built-in 25cm cable

Product Dimension (with Cable): 332mm × 76mm × 16.3mm

Product Weight (with Cable): 96g

Package Contents: Dual M.2 SSD Dock, DC Power Supply, User Manual

Warranty: 12 months

mbeat C1 Tool-Free USB 3.0 3.5' & 2.5' SATA HDD Enclosure - Black

Features

Effortless Installation: Simplify setup with our tool-free, screw-less design and handy slide cover.

Universal Compatibility: Accommodates 3.5' and 2.5' SATA HDDs/SSDs up to 20TB, compatible with Windows and MAC OS.

Rapid Connectivity: Experience lightning-fast USB 3.0 speeds up to 5Gbps and hot plug-and-play functionality.

Smart Monitoring: Stay informed with LED indicators for instant updates on power and data access.

Reliable Performance: Includes a power adapter for stable HDD operation, ensuring data integrity and longevity.

Specifications

USB Port: USB 3.0

Data Speed: Maximum up to 5Gbps

USB Compatibility: Backward compatible with USB 2.0/480Mbps

HDD Interface: 3.5'/2.5' SATA HDD/SSD

HDD Capacity: Maximum up to 20TB

DC Power: +12V/2A Power Supply Included

Supports UASP and hot plug and play

Supports OS: Windows 2000/2003/XP/Vista/7/8/8.1/10/11/MAC OS

Product Dimension: 188mm × 111mm × 32mm

Product Weight: 121g

Package Contents: 3.5' HDD Enclosure, USB Data Cable, Power Supply, User Manual

Warranty: 12 months
