Warranty: 24 months

Warranty: 24 months

Deploy 5G where size and cost matter. The RUTM20 is an ultra-compact global 5G router engineered for IoT and IIoT solutions. Leverage worldwide connectivity with a global Telit 5G modem. Streamline deployments with PoE, enabling single-cable power delivery. With integrated eSIM, you can manage carrier switching at scale, eliminating costly site visits. RUTM20 is perfect for space-constrained solutions like POS, surveillance, and transport.

Standard package*

RUTM20 Router

18 W PSU

4 x 5G Straight compact mobile antennas (SMA male)

2 x Straight compact Wi-Fi RP-SMA antenna (RP-SMA male)

Ethernet cable (1.5 m)

SIM Adapter kit

1 x hex key

QSG (Quick Start Guide)

Packaging box

Warranty: 24 months

Teltonika EBD070 5G Redcap Modem

Warranty: 24 months

Technical Data

Mounting type

M6 Screw or Adhesive

Enclosure material

PC/PC+ABS

UV resistant

✓

Cable length

3000 mm

Weight

450 g

Operating temperature

-40 °C ~ +80 °C

Operating humidity

≤ 90 %

Ingress Protection Rating

IP67

RoHS compliant

✓

5G MOBILE MIMO ANTENNA

Frequency range

600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz

Polarisation

Linear

Radiation pattern type

Omni-directional

Gain

≤ 4 dBi

V.S.W.R

≤ 2.5

Impedance

50 Ω

Connector type and count

4 x SMA Male

Cable type

4 x LMR100

GNSS ANTENNA

Frequency range

1559 ~ 1610, 1164 ~ 1189 MHz

Polarisation

RHCP

Radiation pattern type

Directional

Gain

≤ 2 dBi

LNA Gain

17 ± 2 dB

LNA noise figure

≤ 2 dB

V.S.W.R

≤ 2

Impedance

50 Ω

Supply voltage

3 ~ 5 VDC

Current consumption

15 mA

Connector type and count

1 x SMA Male

Cable type

1 x LMR100

Warranty: 24 months

Technical Data

Mounting type

M6 Screw or Adhesive

Enclosure material

PC/PC+ABS

RoHS compliant

✓

Cable length

3000 mm

Weight

400 g

Operating temperature

-40 °C ~ +80 °C

Operating humidity

≤ 90 %

Ingress Protection Rating

IP67

UV resistant

✓

5G MOBILE MIMO ANTENNA

Frequency range

600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz

Polarisation

Linear

Radiation pattern type

Omni-directional

Gain

≤ 4 dBi

V.S.W.R

≤ 2.5

Impedance

50 Ω

Connector type and count

4 x SMA Male

Cable type

4 x LMR100

Warranty: 24 months

Teltonika 5G COMBO MIMO MOBILE/GNSS ROOF SMA ANTENNA

Warranty: 24 months

Improved GNSS tracking accuracy

Fast installation

Robust casing

Improved GNSS tracking accuracy

Standalone L1 and L5 dual-band GNSS receiver ensures better track quality and quick time to first fix

Fast installation

With the U-type cable, virtually anyone can mount the device in 5 minutes or less directly on a car battery

Robust casing

IP65-rated casing is designed to withstand poor weather conditions

Extended product usage scenarios

Bluetooth® LE-based wireless connection of external devices, including Low Energy beacons and sensors, to monitor temperature, humidity, magnet detection, and movement

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months

Experience robust on-site computing for industrial environments with the RUTC40 edge router. This compact yet powerful and flexible device offers global 4G Cat 4 connectivity powered by a Telit modem, paired with strong processing capabilities and dual-band Wi-Fi 6. With integrated Docker support, you can run containerized applications directly on the router. Featuring 1 GB of RAM, a dual-core 1.3 GHz CPU, and industrial-grade RutOS features, the RUTC40 delivers real-time data logger, seamless cloud integration, and compatibility with Remote Management System (RMS).

Standard package*

RUTC40 Router

24 W PSU

2 x 5G Mobile antennas (swivel, SMA male)

3 x Wi-Fi antennas (magnetic mount, RP-SMA male, 1.5 m cable)

1 x GNSS antenna (adhesive, SMA male, 3 m cable)

Ethernet cable (1.5 m)

SIM Adapter kit

QSG (Quick Start Guide)

Packaging box

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months

Standard package*

TRB501 Gateway

9 W PSU

4x Mobile antennas (swivel, SMA male)

Micro-USB cable (0.8 m)

Ethernet cable

SIM Adapter kit

QSG (Quick Start Guide)

Packaging box

*Standard package contents may differ based on standard order codes.

Warranty: 24 months

Warranty: 24 months

Teltonika ADAS ADVANCED GPS TRACKER WITH ADVANCED DRIVER ASSISTANCE SYSTEM

Warranty: 24 months

Warranty: 24 months

The RUT981 global 4G router pairs a trusted Telit Cat 4 modem with a proven hardware platform, ensuring dependable long-term availability and performance worldwide. Integrate equipment via Wi-Fi and 4 x Ethernet ports for flexible network connections. Ensure always-on connectivity with SIM and eSIM, and use eSIM bootstrap for convenient initial profile download. Maintain uptime with WAN failover and load balancing, ensuring continuous communication in mission-critical deployments.

Standard package*

Router RUT981

9 W PSU

2x Mobile antennas (swivel, SMA male)

2x Wi-Fi antennas (swivel, RP-SMA male)

Ethernet cable (1.5 m)

SIM Adapter kit

QSG (Quick Start Guide)

Packaging box

*Standard package contents may differ based on standard order codes.

Warranty: 24 months

Warranty: 24 months

The RUTM16 is a versatile LTE router engineered for worldwide deployments. Ensure reliable global operation with its Telit modem, which provides Cat 6 speeds and coverage across multiple markets. For maximum versatility, connect IoT and industrial setups via robust 5x Gigabit Ethernet and USB ports, and enjoy stable wireless access with Dual-band Wi-Fi 5 featuring Mesh and Fast Roaming. Use the integrated eSIM to eliminate site visits by managing carrier profiles at scale. The RUTM16 is the ideal 4G router for large-scale applications like robotics, transport, roadside infrastructure, and POS terminals.

Standard package*

RUTM16 Router

18 W PSU

2 x 5 G Mobile antennas (swivel, SMA male)

2 x Wi-Fi antennas (magnetic mount, RP-SMA male, 1.5 m cable)

1 x GNSS antenna (adhesive, SMA male, 3 m cable)

Ethernet cable (1.5 m)

SIM Adapter kit

QSG (Quick Start Guide)

Packaging box

Warranty: 24 months

Bring powerful on-site computing to your industrial deployments with the RUTC41 edge router. This high-performance yet compact and versatile device combines 4G Cat 4 connectivity with advanced processing power and dual-band Wi-Fi 6. Built-in Docker support allows you to run containerized applications directly on the router. Equipped with 1 GB RAM, a dual-core 1.3 GHz CPU, and industrial-grade RutOS features, the RUTC41 delivers secure networking, cloud integration, and real-time data logger in one rugged device.

Standard package*

RUTC41 Router

24 W PSU

2 x Mobile antennas (swivel, SMA male)

3 x Wi-Fi antennas (magnetic mount, RP-SMA male)

Ethernet cable (1.5 m)

SIM Adapter kit

QSG (Quick Start Guide)

Packaging box

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months

Warranty: 24 months
