HP Dock - Thunderbolt 4 Ultra 280W G6 Dock

Features/Specifications:
Ports:

1 x Thunderbolt 4 (TBT4) – 40Gbps
2 x USB-C – 10Gbps (1 with DP Alt. Mode)
2 x DisplayPort 1.4
1 x HDMI 2.1
5 x USB-A – 10Gbps
1 x RJ-45 Ethernet – 2.5Gbps
1 x 3.5mm Audio Combo Jack

Power Delivery:

280W (supports HP ZBook and other Thunderbolt 4 laptops)

Video Support:

Dual 4K @ 60Hz (via DisplayPort/HDMI)
Single 8K @ 30Hz (Thunderbolt 4)

Data Transfer:

Thunderbolt 4: 40Gbps
USB 3.2 Gen 2: 10Gbps

Networking:

2.5Gbps Ethernet (RJ-45)

Compatibility:

Windows 11/10
macOS (limited functionality)
HP ZBook, EliteBook, and other Thunderbolt 4 laptops

Security:

Kensington lock slot

Dimensions:

200 x 100 x 30 mm

Weight:

1 kg

HP Dock - Thunderbolt 4 Ultra 180W G6 Dock

Features/Specifications:
Uninterrupted power with Thunderbolt ™ 4 and HP Quick Connect
Manage devices remotely via Poly Lens
HP Wolf Security, HP Sure Start and Zero Trust Framework
Thoughtfully designed for longevity and comes in plastic-free packaging

Connection and Communications:

Connectivity: Wired - Thunderbolt

Ports and Connectors:

Front: 1 USB Type-C ® 10Gbps (up to 15 W USB Power Delivery)
Right side: 1 USB Type-A 10Gbps (charging), 1 nano security lock slot, 1 USB Type-C ® 10Gbps (up to 15 W USB Power Delivery)
Rear:

1 Thunderbolt ™ 4 with USB Type-C ® 40Gbps
1 USB Type-C ® 10Gbps (USB Power Delivery, DisplayPort ™ 1.4)
2 USB Type-A 5Gbps (charging)
1 HDMI 2.1
2 DisplayPort ™ 1.4
1 RJ-45 (2.5 GbE)


Power Requirements:

230 W external power adapter

Dimensions and Weight:

Dimensions (W x D x H): 12.1 x 12.1 x 4.95 cm
Weight: 790 g

System Requirements:

Minimum Requirements: USB Type-C ® (USB Power Delivery, Alt Mode DisplayPort ™); Thunderbolt ™ 4 port

Box Contents:

HP Thunderbolt 4 Ultra 180W G6 Dock
230 W power adapter
Thunderbolt ™ 4 cable (1 m)
Power cord
Product notice
Warranty card

Warranty and Services:

HP three-year limited warranty

Security Management:

Country of Origin: Made in China or Thailand

Compatibility:

Tested and supported on select HP commercial PCs

HP Dock - Thunderbolt 4 100W G6 Dock

Features/Specifications:
Uninterrupted power with 100W Thunderbolt ™ 4 and HP Quick Connect
Manage devices remotely via Poly Lens
HP Wolf Security, HP Sure Start and Zero Trust Framework
Thoughtfully designed for longevity and comes in plastic-free packaging

Ports and Connectors:

Front: 1 USB Type-C ® 10Gbps (up to 15 W USB Power Delivery)
Right side: 1 USB Type-A 10Gbps (charging), 1 nano security lock slot, 1 USB Type-C ® 10Gbps (up to 15 W USB Power Delivery)
Rear:

1 Thunderbolt ™ 4 with USB Type-C ® 40Gbps
2 USB Type-A 5Gbps (charging)
1 HDMI 2.1
2 DisplayPort ™ 1.4
1 RJ-45 (2.5 GbE)


Power Requirements:

120 W external power adapter

Dimensions and Weight:

Dimensions (W x D x H): 12.1 x 12.1 x 4.95 cm
Weight: 740 g

Box Contents:

HP Thunderbolt 4 100W G6 Dock
120 W power adapter
Thunderbolt ™ 4 cable (1 m)
Power cord
Product notice
Warranty card

Warranty and Services:

HP three-year limited warranty

Security Management:

Country of Origin: Made in China or Thailand

Compatibility:

Tested and supported on select HP commercial PCs
