IQBOARD QA 1310 Pro 75''

Features

• Large interactive display range designed for classrooms, meeting rooms, and collaborative spaces
• High‑performance system memory with 16GB RAM and 256GB ROM, ensuring fast operation, smooth multitasking, and ample storage for content and applications
• Advanced Android 13 with IQ OS, delivering smooth multitasking, customisable home screens, and powerful performance with 16GB RAM and 256GB storage
• Multi‑user interactive blackboard, supporting up to 9 users simultaneously with intuitive gesture‑based navigation
• AI‑powered 4K video conferencing, featuring a 48MP camera with auto framing, voice tracking, adaptive lighting, and noise cancellation
• Immersive audio system, with dual 20W speakers, a 20W subwoofer, and 8‑array microphones providing clear pickup across large rooms
• Seamless wireless collaboration, enabling screen sharing for up to 16 devices, 4K casting, real‑time annotation, and cross‑network sharing

Specifications

Display

• Diagonal Size: 65" / 75" / 86" / 98"
• Brightness: 350 cd/m²
• Contrast Ratio: 1200:1 (65", 75", 98"); 1600:1 (86")
• Panel Type: TFT
• Backlight: Direct LED (DLED)
• Resolution: 4K UHD (3840 × 2160)
• Display Ratio: 16:9
• Response Rate: 8 ms (typ.)
• Refreshing Frequency: 60 Hz
• Viewing Angle: 178° (H), 178° (V)
• Backlight Life Time: 50,000 hours
• Display Colors: 10bit (D), 1.07 billion colors
• Glass: 4 mm Tempered Glass with Anti-Glare coating (8H)
• Dynamic Contrast Ratio: 5000:1

Interactivity

• Touch Technology: Infrared
• Touch Point: 40 point touch. 40 point writing under Windows. 20 Point writing under Android.
• Touch Resolution: 32768 × 32768 (px)
• Response Rate: <4 ms (single touch); <6 ms (max touch inputs)
• Touch Accuracy: ≤1 mm
• Recognition: Finger or pen
• Writing Height: 3 mm
• Minimum Touch Object: 2 mm
• Supported O.S.: HID Support & Win10 / Win8 / Win7 / macOS / Android / Chrome OS / Linux

Front Buttons

• Front Buttons: POWER, HOME, BACK, SETTING, CUSTOM

Connectivity

• USB 3.0 (Android & PC): 3
• HDMI IN 2.0: 1
• Touch-USB: 1
• TYPE-C (USB 2.0, Video & Audio & Touch & 65W): 1

Input

• RJ45 (10/100/1000 Mbit/s): 1
• HDMI 2.0 (4K@60fps): 2
• TYPE-C (USB 2.0, Video & Audio & Touch & 65W): 1
• USB 2.0 (Android) Type-A: 2
• USB 3.0 (Android & PC) Type-A: 2
• USB 2.0 (for Touch) Type-B: 2
• USB 2.0 (OTG): 1
• TF Card: 1
• MIC IN: 1
• RS232: 1
• DP: 1

Output

• HDMI 2.0 (4K@60fps): 1
• COAX SPDIF OUT: 1
• EARPHONE (3.5 mm Line Out): 1
• RJ45 (10/100/1000 Mbit/s): 1

Built-in Features

• Built-in Camera: 48M (Built-in 4K AI Camera with Auto Framing & Voice Tracking)
• Array Microphone: YES (8 Array microphone)
• Built-in Speaker: 20W × 2 + 20W
• Light Sensitivity: YES
• Temperature Monitor: YES
• Proximity Sensor: YES

Environment

• Working Temperature: 0? ~ 40?
• Storage Temperature: −20? ~ 60?
• Working Humidity: 20% ~ 80% RH Non-Condensing
• Storage Humidity: 20% ~ 90% RH Non-Condensing

Android

• CPU Framework: Cortex-A73*4 + Cortex-A53*4
• CPU Processor Speed: 2.2GHz
• GPU: Arm Mali-G52 MP8 (BEE)
• RAM: 16G
• ROM: 256G
• Hotspot: IEEE 802.11 a/b/g/n/ac, IEEE 802.1x, WPA2, and station mode (2.4G/5G Dual-band)
• Bluetooth: 5.2
• NFC: YES
• WiFi: IEEE 802.11 a/b/g/n/ac/ax, IEEE 802.1x, WPA2, Wi-Fi 6 and station mode (2.4G/5G Dual-band)
• OS Version: Android 13.0
• Screensharing: EShare Pro
• Device Management: RDM
• Document Camera Software: IQView

OPS (Optional)

• Chipset: Intel
• CPU: Intel® Core i3 / i5 / i7
• Memory: 4GB / 8GB / 16GB
• HDD: 500GB / 1TB
• SSD (Optional): 128GB / 256GB / 512GB
• Pre-installed Software: IQCLASS ONE
• Interfaces (Subject to model):
  • USB 2.0 × 2
  • USB 3.0 × 2
  • LAN × 1
  • HDMI × 1
  • LINE-OUT × 1
  • MIC-IN × 1

Power

• Voltage: 100V ~ 240V AC 50 / 60Hz
• Maximum Power:
  • 65": ≤350W
  • 75": ≤400W
  • 86": ≤450W
  • 98": ≤750W
• Standby Power: ≤0.5W

Physical

• Screen Sizes: 65" / 75" / 86" / 98"
• Net Weight (kg):
  • 65": 40 ±1.5
  • 75": 56 ±1.5
  • 86": 66 ±1.5
  • 98": 106 ±1.5
• Gross Weight (kg):
  • 65": 46 ±1.5
  • 75": 70 ±1.5
  • 86": 81 ±1.5
  • 98": 121 ±1.5
• Product Size (mm) (W × H × D):
  • 65": 1501 × 930 × 116
  • 75": 1723 × 1055 × 116
  • 86": 1968 × 1194 × 116
  • 98": 2233 × 1346 × 105
• Packing Size (mm) (W × H × D):
  • 65": 1576 × 980 × 200
  • 75": 1800 × 1125 × 200
  • 86": 2044 × 1262 × 200
  • 98": 2306 × 1520 × 200
• VESA Hole Position (mm):
  • 65": 4-M8 screw hole 500×400
  • 75": 4-M8 screw hole 600×400
  • 86": 4-M8 screw hole 800×400
  • 98": 4-M8 screw hole 1000×400

Accessories

• Power Cord: 1 (1.5m)
• HDMI Cable: 1 (1.5m)
• USB Cable: 1 (1.5m)
• Remote Controller: 1
• NFC Card: 1
• Colorless Writing Pen: 2
• Wall Mounting Brackets: 1

Language

• OSD Languages: English, French, German, Russian, Japanese, Korean, Polish, Portuguese, Vietnamese, Spanish, Italian, Arabic, Simplified Chinese, Traditional Chinese, Ukrainian

Certificate

• CE, FCC, ROHS, BIS, IEC, WEEEE, Energy Star, CB, IECEE, TUV Low blue light, ERP

Warranty

• Warranty term and upgrade options vary by region. Contact your local reseller or distributor for information.

Downloads

• Product brochure

SHARP Commercial 75'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: ADS with Direct LED backlights
• Active Screen Area: 1,650.2 x 928.3 mm
• Screen Size: 75 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.430 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape, Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 3 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB Type-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 170 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 1,680 x 959 x 58.5 mm
• Weight: 24 kg
• Bezel Width: 12.9 mm
• VESA Mounting: 600 x 400 mm (M8)
• Packaging Dimensions (W x H x D): 1,875 x 1,130 x 186 mm
• Packaging Weight: 33 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity with a single cable connection between notebook and display. The native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity.
• Powerful System-on-Chip Design to fit your digital signage needs.
• Best readability even in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol.
• 450 cd/m2 brightness and HDR compatibility will capture the attention of audience in almost any situation.
• Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage.
• Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails.
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations.

Specifications

General Information

• Panel Technology: ADS with Direct LED backlights
• Screen Size: 55 inch
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Dimensions (W x D x H): 1233.0 x 703.5 x 62.0 millimetre
• Bezel Width: 9.9 (left, right); 9.9 (top, bottom) millimetre
• Weight: 13.2 kilogram
• VESA Mounting 4x M6 x 14mm (400 x 400)

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency 15 - 135
• Vertical Frequency 23-76
• Aspect Ratio: 16:9
• Supported Resolution: 4096x2160, 3840x2160, 1920x1200, 1920x1080, 1280x720, 640x480,

Connectivity

• Input Video Analogue: N/A
• Input Video Digital: 3 x HDMI, 1 x USB-C (DP-Alt Mode Supported)
• Input Audio Analogue: N/A
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: USB 3.0 x1 (5V/0.9A, Downstream), USB 2.0 x1 (5V/0.5A, Downstream), USB 3.0 x1 (Downstream for USB-C), USB-C x1 (Upstream)
• Output Audio Digital: 3.5mm Mini Jack, SPDIF Optical

Installation

• Landscape
• Portrait

Sensors

• Ambient Light Sensor: Integrated triggered actions programmable
• Temperature Sensor: Integrated Triggered actions programmable 1 sensor
• Human Sensor: Optional (KT-RC3)

Electrical

• Power Consumption: 120-220
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Operating Hours: 18/7

Environmental

• Operating Temperature: 0ºC to 50ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 80%

Other Features

• Safety and Ergonomics: Energy Star 8.0
• Audio (Speakers): Integrated 10W x 10W, Optional through SP-RM3a

Shipping Content

• AC Power Cord, 2.0m HDMI Cable, IR Remote Control & Batteries

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity – native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity, with a single cable connection between notebook and display.
• Best readability – aiding high productivity in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Quick input detection – removing potential frustration and smoothing the way to productive meeting outcomes, the display responds immediately when a device is connected.
• Third-party compatibility – a flexible signage platform that supports integration with a wide range of workplace and content management systems.
• New feature-ready – regular OTA Android OS updates ensure availability of the latest features and system security.

Specifications

General Information

• Panel Technology: IPS with Direct LED backlights
• Screen Size: 98 inch
• Aspect Ratio: 16:9
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
• Colour Depth [bn]: 1.073 (8bit + FRC)
• Response Time: 8ms
• HDR: HDR10; HLG; PQ
• Panel Refresh Rate (Hz): 60Hz
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Supported Resolutions: 1024 x 768; 1024 x 768; 1280 x 1024; 1280 x 1024; 1280 x 720; 1280 x 800; 1360 x 768; 1366 x 768; 1400 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1080; 1920 x 1200; 1920 x 2160; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 480; 720 x 576 pixels

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency [kHz]: 15 - 135
• Vertical Frequency [Hz]: 23-76

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP 1.3/2.2); 3 x HDMI (with HDCP)
• Input Audio Digital: 1x USB-C; 3 x HDMI
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: 3 x USB 2.0 (Downstream)
• Output Audio Digital: 1 x 3.5 mm jack
• Input Detect: Custom; First; Last

Electrical

• Power Consumption: 206W shipping
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Power Supply: 100-240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: +0ºC to +40ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 90%

Mechanical

• Dimensions (W x D x H): 2,199 x 1,255 x 69 millimetre
• Weight: 54.5 kilogram
• Bezel Width: 18 millimetre
• VESA Mounting: 4 holes; 800 x 600 (FDMI); M8
• Ingress Protection: IP5x (front); IP5x (back)
• Packaging Dimensions (W x H x D): 2,360 x 1,425 x 280 millimetre
• Packaging Weight: 82 kilogram
• Colour Bezel: Pantone (Process Black M)
• Material: Metal

Media Player

• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MKV (Mpeg1/2/3 Layer1/2/3, max res 4096x2160@60fps); MP4 (Mpeg1/2 Layer1/2/3, H.264, HEVC/H.265, max res 4096x2160@60fps)
• Supported Audio Format: .mp3 max. Bit Rate 320 kbps

Embedded Computing

• System Version: Android 13
• System Memory: 4G RAM
• Internal Storage: 32GB ROM
• Built-in Applications: File Manager; Web Browser

Other Features

• Safety and Ergonomics: BSMI; CE; EMC Class B; Energy Star 8; FCC Class B; KC/KCC; PSB; RCM; RoHS; VCCI
• Audio (Speakers): Integrated Speakers (10W + 10W)
• Shipping Content (Accessories): 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual
• Security: Disable HW Buttons, Disable IR Functionality
• External Control: AMX NetLinx Support, ASCII Control Commands, Crestron Connected, HDMI CEC, Scheduled Timer,
• Remote Management: Automated Email Alerts, NEC NaViSet Administrator 2

Downloads

• Product brochure

SHARP Commercial 43'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: ADS with Direct LED backlights
• Active Screen Area: 941.2 x 529.4 mm
• Screen Size: 43 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.245 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape, Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 2 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 85 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 965 x 555 x 59.1 mm
• Weight: 7.5 kg
• Bezel Width: 10.7 mm
• VESA Mounting: 200 x 200 mm (M6)
• Packaging Dimensions (W x H x D): 1,075 x 683 x 127 mm
• Packaging Weight: 11 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity with a single cable connection between notebook and display. The native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity.
• Powerful System-on-Chip Design to fit your digital signage needs.
• Best readability even in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol.
• 400 cd/m2 brightness and HDR compatibility will capture the attention of audience in almost any situation.
• Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage.
• Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails.
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations.

Specifications

General Information

• Panel Technology: ADS with Direct LED backlights
• Screen Size: 43 inch
• Max. Brightness (average): 400 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Dimensions (W x D x H): 964.6 x 552.5 x 62.0 millimetre
• Bezel Width: 9.9 (left, right); 9.9 (top, bottom) millimetre
• Weight: 9.4 kilogram
• VESA Mounting [mm]: 4x M6 x 14mm (200 x 200)

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency [kHz]: 15 - 135
• Vertical Frequency [Hz]: 23-76
• Aspect Ratio: 16:9
• Supported Resolution: 4096x2160, 3840x2160, 1920x1200, 1920x1080, 1280x720, 640x480,

Connectivity

• Input Video Analogue: N/A
• Input Video Digital: 3 x HDMI, 1 x USB-C (DP-Alt Mode Supported)
• Input Audio Analogue: N/A
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: USB 3.0 x1 (5V/0.9A, Downstream), USB 2.0 x1 (5V/0.5A, Downstream), USB 3.0 x1 (Downstream for USB-C), USB-C x1 (Upstream)
• Output Audio Digital: 3.5mm Mini Jack, SPDIF Optical

Installation

• Installation: Landscape
• Installation: Portrait

Sensors

• Ambient Light Sensor: Integrated triggered actions programmable
• Temperature Sensor: Integrated Triggered actions programmable 1 sensor
• Human Sensor: Optional (KT-RC3)

Electrical

• Power Consumption: 90-175
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Operating Hours: 18/7

Environmental

• Operating Temperature: 0ºC to 50ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 80%

Other Features

• Safety and Ergonomics: Energy Star 8.0
• Audio (Speakers): Integrated 10W x 10W, Optional through SP-RM3a

Shipping Content

• Shipping Content (Accessories): AC Power Cord, 2.0m HDMI Cable, IR Remote Control & Batteries

Downloads

• Product brochure

SHARP Commercial 55'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: ADS with Direct LED backlights
• Active Screen Area: 1,209.6 x 680.4 mm
• Screen Size: 55 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.315 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape, Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 2 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB Type-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 100 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 1,234 x 707 x 58.9 mm
• Weight: 12 kg
• Bezel Width: 10.8 mm
• VESA Mounting: 400 x 200 mm (M6)
• Packaging Dimensions (W x H x D): 1,386 x 845 x 130 mm
• Packaging Weight: 17 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Commercial 50'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: VA with Direct LED backlights
• Screen Size: 50 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.315 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 4000:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Face Up; Landscape; Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 2 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB Type-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 99 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 1120 x 641 x 59.9 mm
• Weight: 9.2 kg
• Bezel Width: 10.8 mm
• VESA Mounting: 200 x 200 mm (M6)
• Packaging Dimensions (W x H x D): 1,253 x 761 x 128 mm
• Packaging Weight: 13 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity, with a single cable connection between notebook and display.
• Best readability aiding high productivity in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Quick input detection removing potential frustration and smoothing the way to productive meeting outcomes, the display responds immediately when a device is connected.
• Third-party compatibility a flexible signage platform that supports integration with a wide range of workplace and content management systems.
• New feature-ready regular OTA Android OS updates ensure availability of the latest features and system security.

Specifications

General Information

• Panel Technology: IPS with Direct LED backlights
• Screen Size: 75 inch
• Aspect Ratio: 16:9
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 (8bit + FRC)
• Response Time: 8ms
• HDR: HDR10; HLG; PQ
• Panel Refresh Rate: 60Hz
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Supported Resolutions: 1024 x 768; 1024 x 768; 1280 x 1024; 1280 x 1024; 1280 x 720; 1280 x 800; 1360 x 768; 1366 x 768; 1400 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1080; 1920 x 1200; 1920 x 2160; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 480; 720 x 576 pixels
• Weight: 34.3 kilogram

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency: 15 - 135
• Vertical Frequency: 23-76

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP 1.3/2.2); 3 x HDMI (with HDCP)
• Input Audio Digital: 1x USB-C; 3 x HDMI
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: 3 x USB 2.0 (Downstream)
• Output Audio Digital: 1 x 3.5 mm jack
• Input Detect: Custom; First; Last

Electrical

• Power Consumption: 132W shipping
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Power Supply: 100-240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: +0ºC to +40ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 90%

Mechanical

• Dimensions (W x D x H): 1,686 x 964 x 68 millimetre
• Weight: 34.3 kilogram
• Bezel Width: 15.9 millimetre
• VESA Mounting: 4 holes; 800 x 600 (FDMI); M8
• Ingress Protection: IP5x (front); IP5x (back)
• Packaging Dimensions (W x H x D): 1,863 x 1,090 x 225 millimetre
• Packaging Weight: 51 kilogram
• Colour Bezel: Pantone (Process Black M)
• Material: Metal

Media Player

• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MKV (Mpeg1/2/3 Layer1/2/3, max res 4096x2160@60fps); MP4 (Mpeg1/2 Layer1/2/3, H.264, HEVC/H.265, max res 4096x2160@60fps)
• Supported Audio Format: .mp3 max. Bit Rate 320 kbps

Embedded Computing

• System Version: Android 13
• System Memory: 4G RAM
• Internal Storage: 32GB ROM
• Built-in Applications: File Manager; Web Browser

Other Features

• Safety and Ergonomics: BSMI; CE; EMC Class B; Energy Star 8; FCC Class B; KC/KCC; PSB; RCM; RoHS; VCCI
• Audio (Speakers): Integrated Speakers (10W + 10W)
• External Control: AMX NetLinx Support, ASCII Control Commands, Crestron Connected, HDMI CEC, Scheduled Timer
• Security: Disable HW Buttons, Disable IR Functionality
• Remote Management: Automated Email Alerts, NEC NaViSet Administrator 2

Shipping Content

• 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual

Downloads

• Product brochure

SHARP Commercial 86'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: ADS with Direct LED backlights
• Active Screen Area: 1,895.0 x 1,066.0 mm
• Screen Size: 86 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.4935 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape, Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 3 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB Type-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 245 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 1,927 x 1,098.6 x 60 mm
• Weight: 32.5 kg
• Bezel Width: 12.9 mm
• VESA Mounting: 600 x 400 mm (M8)
• Packaging Dimensions (W x H x D): 2,080 x 1,250 x 225 mm
• Packaging Weight: 44 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity with a single cable connection between notebook and display. The native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity.
• Powerful System-on-Chip Design to fit your digital signage needs.
• Best readability even in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol.
• 450 cd/m2 brightness and HDR compatibility will capture the attention of audience in almost any situation.
• Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage.
• Failover Capabilities with full Input Detect

Specifications

General Information

• Panel Technology: VA with Direct LED backlights
• Screen Size: 50 inch
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 5000:1
• Viewing Angle (H/V): 178
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Dimensions (W x D x H): 1118.6 x 639.2 x 62.0 millimetre
• Bezel Width: 9.9 (left, right); 9.9 (top, bottom) millimetre
• Weight: 11.7 kilogram
• VESA Mounting [mm]: 4x M6 x 14mm (400 x 400)

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency [kHz]: 15 - 135
• Vertical Frequency [Hz]: 23-76
• Aspect Ratio: 16:9
• Supported Resolution: 4096x2160, 3840x2160, 1920x1200, 1920x1080, 1280x720, 640x480,

Connectivity

• Input Video Analogue: N/A
• Input Video Digital: 3 x HDMI, 1 x USB-C (DP-Alt Mode Supported)
• Input Audio Analogue: N/A
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: USB 3.0 x1 (5V/0.9A, Downstream), USB 2.0 x1 (5V/0.5A, Downstream), USB 3.0 x1 (Downstream for USB-C), USB-C x1 (Upstream)
• Output Audio Digital: 3.5mm Mini Jack, SPDIF Optical

Installation

• Landscape
• Portrait

Sensors

• Ambient Light Sensor: Integrated triggered actions programmable
• Temperature Sensor: Integrated Triggered actions programmable 1 sensor
• Human Sensor: Optional (KT-RC3)

Electrical

• Power Consumption: 85-170
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Operating Hours: 18/7

Environmental

• Operating Temperature: 0ºC to 50ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 80%

Other Features

• Safety and Ergonomics: Energy Star 8.0
• Audio (Speakers): Integrated 10W x 10W, Optional through SP-RM3a

Shipping Content

• Shipping Content (Accessories): AC Power Cord, 2.0m HDMI Cable, IR Remote Control & Batteries

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity with a single cable connection between notebook and display. The native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity.
• Powerful System-on-Chip Design to fit your digital signage needs.
• Best readability even in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C while supporting both legacy NEC and Sharp protocol.
• 450 cd/m2 brightness and HDR compatibility will capture the attention of audience in almost any situation.
• Integrated Media Player allows for playlist creation and scheduled playback via USB or onboard storage.
• Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the primary source fails.
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations.

Specifications

General Information

• Panel Technology: ADS with Direct LED backlights
• Screen Size: 65 inch
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 8000:1
• Viewing Angle (H/V): 178
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Dimensions (W x D x H): 1463.3 x 838.3 x 68.0 millimetre
• Bezel Width: 15.9 (left, right); 15.9 (top, bottom) millimetre
• Weight: 23.9 kilogram
• VESA Mounting 4x M8 x 14mm (600 x 400)

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency 15 - 135
• Vertical Frequency 23-76
• Aspect Ratio: 16:9
• Supported Resolution: 4096x2160, 3840x2160, 1920x1200, 1920x1080, 1280x720, 640x480,

Connectivity

• Input Video Analogue: N/A
• Input Video Digital: 3 x HDMI, 1 x USB-C (DP-Alt Mode Supported)
• Input Audio Analogue: N/A
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: USB 3.0 x1 (5V/0.9A, Downstream), USB 2.0 x1 (5V/0.5A, Downstream), USB 3.0 x1 (Downstream for USB-C), USB-C x1 (Upstream)
• Output Audio Digital: 3.5mm Mini Jack, SPDIF Optical

Installation

• Landscape
• Portrait

Sensors

• Ambient Light Sensor: Integrated triggered actions programmable
• Temperature Sensor: Integrated Triggered actions programmable 1 sensor
• Human Sensor: Optional (KT-RC3)

Electrical

• Power Consumption: 140-240
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Operating Hours: 18/7

Environmental

• Operating Temperature: 0ºC to 50ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 80%

Other Features

• Safety and Ergonomics: Energy Star 8.0
• Audio (Speakers): Integrated 10W x 10W, Optional through SP-RM3a

Shipping Content

• AC Power Cord, 2.0m HDMI Cable, IR Remote Control & Batteries

Downloads

• Product brochure

SHARP Commercial 65'' Display, 4K UHD resolution, 350nits Brightness with High Haze. Recommended for up to 16hr/day use. Landscape and Portrait use with even bezel. USB-C & HDMI inputs. LAN control.

Features

• 4K UHD native resolution allows for high end visual acuity!
• Built-in, integrated 10W speakers enhance the experience with superior sound
• Industrial-strength, premium-grade panel with metal frame bezel, allows for hassle-free 16/7 operation
• Tilt back and forth installation (-20°?20°) to install it at desired angle
• Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
• 24-Hour On/Off timer maintains power schedules
• Integrated Media Player allows for audio, video or image playback via USB
• USB Type-C port for audio/video input
• NaViSet Administrator 2 Free software solution that greatly eases administration and management of larger display device installations

Specifications

• Panel Technology: ADS with Direct LED backlights
• Active Screen Area: 1,428.5 x 803.5 mm
• Screen Size: 65 inch
• Aspect Ratio: 16:9
• Pixel Pitch: 0.372 mm
• Brightness: 350 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
• Colour Depth: 1.073 bn (8-bit + FRC)
• Response Time: 8 ms
• Panel Refresh Rate: 60 Hz
• Haze Level: 25%
• Supported Orientation: Landscape, Portrait

Resolution

• Native Resolution: 3840 x 2160
• Supported Resolution: 1024 x 768; 1280 x 1024; 1280 x 720; 1280 x 800; 1280 x 960; 1360 x 768; 1400 x 1050; 1440 x 900; 1680 x 1050; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 400; 720 x 480; 720 x 576

Synchronisation Rate

• Horizontal Frequency: 15 – 136 kHz
• Vertical Frequency: 24 – 75 Hz

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP, 15 W); 2 x HDMI
• Input Audio Digital: 1 x USB-C; 3 x HDMI
• Input Control: 1 x LAN 100 Mbit; 1 x RS232
• Input Data: 1 x USB 2.0 (Media Player); 1 x USB Type-C (5V/3A, power for external devices)
• Output Audio Analogue: 1 x 3.5 mm jack
• Remote Control: IR Remote Control; RS‑232C (9‑pin D‑sub) input

Electrical

• Power Consumption: 125 W (shipping)
• Power Savings Mode: < 0.5 W; < 2 W (Networked Standby)
• Power Supply: 100–240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: 0 °C to 40 °C
• Operating Humidity: 20% to 80%
• Storage Temperature: −20 °C to 60 °C
• Storage Humidity: 10% to 80%

Mechanical

• Dimensions (W x H x D): 1,453 x 829 x 59.7 mm
• Weight: 16.5 kg
• Bezel Width: 12.9 mm
• VESA Mounting: 400 x 400 mm (M6)
• Packaging Dimensions (W x H x D): 1,635 x 987 x 160 mm
• Packaging Weight: 23 kg

Media Player

• Supported Image Formats: JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640
• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840x2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840x2160@60Hz); WMV (H.264, Windows Media Video 9, max res 1080p@30Hz); Audio: LPCM, MP3, AAC, WMA 9/10
• Supported Audio Format: MP3 (max. bit rate 320 kbps)

Other Features

• Safety and Ergonomics: CE; Energy Star 8; FCC Class B; RCM; UKCA; UL/C-UL or CSA; VCCI
• Ecological Standards: EnergyStar 8.0
• Special Characteristics: CEC Support; HDMI ARC; NaViSet Administrator 2; Powered USB-Port; Scheduler; USB Media Player
• Colour Versions: Black Front Bezel, Black Back Cabinet
• Audio: Integrated Speakers (10 W + 10 W)
• Operating Hours: 16/7
• Remote Management: NaViSet Administrator 2

Shipping Content

• Display
• Power Cable
• Remote Control
• 2 x AAA batteries
• Cable Clamps
• Setup Manual

Downloads

• Product brochure

SHARP Recommended for meeting rooms and signage applications. Native USB-C supports Bring Your Own Device workflows, with quick input detection. Comes with an integrated System on Chip (SoC) with Android 13 Operating System.

Features

• Seamless connectivity native USB-C supports Bring Your Own Device workflows, safeguarding inclusion and boosting productivity, with a single cable connection between notebook and display.
• Best readability aiding high productivity in well-lit meeting spaces, a high haze filter eliminates glare and reflections from windows and other light sources.
• Quick input detection removing potential frustration and smoothing the way to productive meeting outcomes, the display responds immediately when a device is connected.
• Third-party compatibility a flexible signage platform that supports integration with a wide range of workplace and content management systems.
• New feature-ready regular OTA Android OS updates ensure availability of the latest features and system security.

Specifications

General Information

• Panel Technology: IPS with Direct LED backlights
• Screen Size: 86 inch
• Aspect Ratio: 16:9
• Max. Brightness (average): 450 cd/m2
• Contrast Ratio: 1200:1
• Viewing Angle (H/V): 178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
• Colour Depth [bn]: 1.073 (8bit + FRC)
• Response Time: 8ms
• HDR: HDR10; HLG; PQ
• Panel Refresh Rate (Hz): 60Hz
• Haze Level (%): 25
• Supported Orientation: Landscape, Portrait
• Supported Resolutions: 1024 x 768; 1024 x 768; 1280 x 1024; 1280 x 1024; 1280 x 720; 1280 x 800; 1360 x 768; 1366 x 768; 1400 x 1050; 1440 x 900; 1600 x 1200; 1680 x 1050; 1920 x 1080; 1920 x 1200; 1920 x 2160; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 480; 720 x 576 pixels

Resolution

• Native Resolution: 3840 x 2160

Synchronisation Rate

• Horizontal Frequency [kHz]: 15 - 135
• Vertical Frequency [Hz]: 23-76

Connectivity

• Input Video Digital: 1 x USB-C (with HDCP 1.3/2.2); 3 x HDMI (with HDCP)
• Input Audio Digital: 1x USB-C; 3 x HDMI
• Input Control: LAN (1000Mbit), 3.5mm Mini Jack IR Remote, RS-232C
• Input Data: 3 x USB 2.0 (Downstream)
• Output Audio Digital: 1 x 3.5 mm jack
• Input Detect: Custom; First; Last

Electrical

• Power Consumption: 162W shipping
• Power Savings Mode: <0.5W (Normal Standby); 2W (Network Standby)
• Power Supply: 100-240 V AC; 50/60 Hz; internal

Environmental

• Operating Temperature: +0ºC to +40ºC
• Operating Humidity: 20% to 80%
• Storage Temperature: -20ºC to 60ºC
• Storage Humidity: 10% to 90%

Mechanical

• Dimensions (W x D x H): 1,931 x 1,102 x 68 millimetre
• Weight: 42 kilogram
• Bezel Width: 15.9 millimetre
• VESA Mounting: 4 holes; 800 x 600 (FDMI); M8
• Ingress Protection: IP5x (front); IP5x (back)
• Packaging Dimensions (W x H x D): 2,110 x 1,247 x 225 millimetre
• Packaging Weight: 63 kilogram
• Colour Bezel: Pantone (Process Black M)
• Material: Metal

Media Player

• Supported File Storage / File System: FAT16 / FAT32 @ USB 2.0
• Supported Video Formats: MKV (Mpeg1/2/3 Layer1/2/3, max res 4096x2160@60fps); MP4 (Mpeg1/2 Layer1/2/3, H.264, HEVC/H.265, max res 4096x2160@60fps)
• Supported Audio Format: .mp3 max. Bit Rate 320 kbps

Embedded Computing

• System Version: Android 13
• System Memory: 4G RAM
• Internal Storage: 32GB ROM
• Built-in Applications: File Manager; Web Browser

Other Features

• Safety and Ergonomics: BSMI; CE; EMC Class B; Energy Star 8; FCC Class B; KC/KCC; PSB; RCM; RoHS; VCCI
• Audio (Speakers): Integrated Speakers (10W + 10W)
• Shipping Content (Accessories): 2x AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual
• Security: Disable HW Buttons, Disable IR Functionality
• External Control: AMX NetLinx Support, ASCII Control Commands, Crestron Connected, HDMI CEC, Scheduled Timer,
• Remote Management: Automated Email Alerts, NEC NaViSet Administrator 2

Downloads

• Product brochure

DAHUA 21.5'' IPS Monitor, 1920*1080, 100Hz, 5ms, VGA+HDMI+Speaker

Features

• A wide 178° horizontal and 178° vertical viewing angle
• Supports both HDMI and VGA signal input
• Anti‑blue light technology helps protect your eyes from strain and injury
• Elegant thin‑frame design with a sturdy metal base

Specifications

• Model: DHI-LM22-B201S
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 21.45 inch
• Aspect Ratio: 16:9
• Viewing Size: 478.656 (H) × 478.656 (V) mm
• Screen-to-Body Ratio: ≥90%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.2493 mm × 0.241 mm
• Pixels Per Inch: 102.7
• Resolution: 1920 (H) × 1080 (V)
• Refresh Rate: 100 Hz
• Display Color: 16.7M colors
• Color Gamut: 72% NTSC
• Brightness: 250 cd/m² (max)
• Contrast Ratio: 1000:1
• Response Time: OD 5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Low Blue Light: Software blue light protection

Device Ports

• Input: 1 × HDMI 1.4 (1920 × 1080@100 Hz), 1 × VGA
• Output: 1 × Audio out
• Speaker: 2 × 1 W

Power & Environmental Conditions

• Power Supply: 12 VDC, 2 A
• Power Consumption: 15 W (basic), 17 W (typ.), 19 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–85% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° / 15°
• Product Dimensions (W × H × D): 492.7 mm × 284.0 mm × 39.5 mm (19.40" × 11.18" × 1.56"), without wall‑mount bracket
• Package Size (W × H × D): 598 mm × 366 mm × 99 mm (23.54" × 14.41" × 3.90")
• Unilateral Splicing (U/L/R/D): 2.2 mm / 2.2 mm / 2.2 mm / 15.2 mm
• Net Weight: 2.18 kg (4.81 lb)
• Gross Weight: 3.12 kg (6.88 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Status Indicator Light: Yes
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Power adapter
• Base
• HDMI cable
• User's manual (QR code)
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 24'' IPS Monitor, 1920*1080, 100Hz, 5ms, VGA+HDMI+Speaker

Features

• A wide 178° horizontal and 178° vertical viewing angle
• Supports HDMI and VGA signal input
• Anti‑blue light technology helps protect your eyes from strain and injury
• Elegant thin‑frame design with a sturdy metal base

Specifications

• Model: DHI-LM24-B201S
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 23.8 inch
• Aspect Ratio: 16:9
• Viewing Size: 527.04 (H) × 296.46 (V) mm
• Screen-to-Body Ratio: ≥90%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.2745 mm × 0.2745 mm
• Pixels Per Inch: 92.56
• Resolution: 1920 (H) × 1080 (V)
• Refresh Rate: 100 Hz
• Display Color: 16.7M colors
• Color Gamut: 72% NTSC
• Brightness: 250 cd/m² (max)
• Contrast Ratio: 1000:1
• Response Time: OD 5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Low Blue Light: Software blue light protection

Device Ports

• Input: 1 × HDMI 1.4 (1920 × 1080@100 Hz), 1 × VGA
• Output: 1 × Audio out
• Speaker: 2 × 1 W

Power & Environmental Conditions

• Power Supply: 12 VDC, 2.5 A
• Power Consumption: 17 W (basic), 19 W (typ.), 21 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–85% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° / 15°
• Product Dimensions (W × H × D): 539.2 mm × 320.4 mm × 39.1 mm (21.23" × 12.61" × 1.54"), without wall‑mount bracket
• Package Size (W × H × D): 612 mm × 405 mm × 101 mm (24.09" × 15.94" × 3.98")
• Unilateral Splicing (U/L/R/D): 2.1 mm / 2.1 mm / 2.1 mm / 15.9 mm
• Net Weight: 2.82 kg (6.22 lb)
• Gross Weight: 3.84 kg (8.47 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Status Indicator Light: Yes
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Power adapter
• Base
• HDMI cable
• User's manual (QR code)
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 24'' IPS Monitor, 2560*1440, 100Hz, 5ms, HDMI+DP+Audio out

Features

• 2560 × 1440 resolution delivers clearer, sharper, and more vivid images
• IPS panel with a 3‑sided frameless design for wide, immersive viewing
• 178° (H) / 178° (V) extra‑wide viewing angle for consistent image quality
• 5 ms fast response time reduces blurring and ghosting
• Low blue light technology supports a more comfortable viewing experience

Specifications

• Model: DHI-LM24-C301B
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 23.8 inch
• Aspect Ratio: 16:9
• Resolution: 2560 (H) × 1440 (V)
• Refresh Rate: 100 Hz
• Display Color: 8 bit
• Color Gamut: 85% NTSC
• Brightness: 300 cd/m² (max)
• Contrast Ratio: 1200:1
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Response Time: OD 5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%

Device Ports

• Input: 1 × HDMI 1.4 (1440P@75 Hz), 1 × DP 1.2 (1440P@100 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 12 VDC, 2.5 A
• Power Type: Power adapter
• Power Consumption: 21 W (basic), 24 W (typ.), 24 W (max)
• Standby Power Consumption: ≤0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–90% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° ± 2° / 15° ± 2°
• Product Dimensions (W × H × D): 539.2 mm × 320.4 mm × 41.3 mm (21.23" × 12.62" × 1.62"), without base
• Package Size (W × H × D): 612 mm × 405 mm × 111 mm (24.10" × 15.94" × 4.37")
• Frame Width (U/L/R/D): 3.1 mm / 3.1 mm / 3.1 mm / 15.9 mm
• Net Weight: 3.1 kg (6.83 lb)
• Gross Weight: 4 kg (8.82 lb)
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Power adapter
• Base
• HDMI cable
• User's manual (QR code)
• QSG
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 27'' IPS Monitor, 2560*1440, 100Hz, 5ms, HDMI+DP+Audio out

Features

• 2560 × 1440 resolution delivers clearer and more vivid image quality
• IPS panel with a 3‑sided frameless design for wide, immersive viewing
• 178° (H) / 178° (V) extra‑wide viewing angle for consistent performance from any direction
• 5 ms fast response time minimizes blurring and ghosting
• Low blue light technology supports a more comfortable viewing experience

Specifications

• Model: DHI-LM27-C301B
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 27 inch
• Aspect Ratio: 16:9
• Resolution: 2560 (H) × 1440 (V)
• Refresh Rate: 100 Hz
• Display Color: 8 bit
• Color Gamut: 85% NTSC
• Brightness: 300 cd/m² (max)
• Contrast Ratio: 1200:1
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Response Time: OD 5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%

Device Ports

• Input: 1 × HDMI 1.4 (1440P@75 Hz), 1 × DP 1.2 (1440P@100 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 12 VDC, 3 A
• Power Type: Power adapter
• Power Consumption: 25 W (basic), 30 W (typ.), 30 W (max)
• Standby Power Consumption: ≤0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–90% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° ± 2° / 15° ± 2°
• Product Dimensions (W × H × D): 614.1 mm × 363.0 mm × 51.1 mm (24.18" × 14.29" × 2.01"), without base
• Package Size (W × H × D): 694 mm × 458 mm × 126 mm (27.32" × 18.03" × 4.96")
• Frame Width (U/L/R/D): 1.9 mm / 1.9 mm / 1.9 mm / 16.1 mm
• Net Weight: 4.8 kg (10.58 lb)
• Gross Weight: 6.3 kg (13.89 lb)
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Power adapter
• Base
• HDMI cable
• User's manual (QR code)
• QSG
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 24'' IPS Monitor, 1920*1080, 240Hz, 0.5ms, DP+HDMI+Audio out

Features

• Wide color gamut with 85% NTSC coverage, meeting designers' needs for rich image texture
• 178°H / 178°V extra‑wide viewing angle for all‑round visual performance
• Adaptive Sync technology effectively reduces picture lagging and tearing
• Ultra‑fast 0.5 ms response time (with OD) to eliminate blurring and ghosting

Specifications

• Model: DHI-LM25-E241B
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 24.5 inch
• Aspect Ratio: 16:9
• Viewing Size: 543.744 (H) × 302.616 (V) mm
• Screen-to-Body Ratio: ≥85%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.0944 mm × 0.2802 mm
• Pixels Per Inch: 89.91
• Resolution: 1920 (H) × 1080 (V)
• Refresh Rate: 240 Hz
• Display Color: 8 bit, 16.7M colors
• Color Gamut: 85% NTSC
• Brightness: 350 cd/m² (typ.)
• Contrast Ratio: 1000:1
• Response Time: MPRT 1 ms, OD 0.5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Low Blue Light: Software blue light protection
• HDR: HDR10

Device Ports

• Input: 1 × DP 1.4 (1920 × 1080@240 Hz), 1 × HDMI 2.0 (1920 × 1080@240 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 12 VDC, 3 A
• Power Type: Power adapter
• Power Consumption: 18 W (basic), 19 W (typ.), 23.8 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–80% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° ± 2° / 20° ± 2°
• Product Dimensions (W × H × D): 557.7 mm × 330.6 mm × 58.0 mm (21.96" × 13.02" × 2.28"), without wall‑mount bracket
• Package Size (W × H × D): 620 mm × 431 mm × 134 mm (24.41" × 16.97" × 5.28")
• Unilateral Splicing (U/L/R/D): 6.98 mm / 6.98 mm / 6.98 mm / 19.61 mm (0.27" / 0.27" / 0.27" / 0.77")
• Net Weight: 2.93 kg (6.5 lb)
• Gross Weight: 4.0 kg (8.82 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Status Indicator Light: Yes
• Wall Mount VESA: 100 mm × 100 mm (3.94" × 3.94")

Accessory

• Power adapter
• DP cable
• User's manual
• Legal and regulatory information

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 34'' VA Monitor, 3440*1440, 200Hz, MPRT 1ms, 2*DP+2*HDMI+Audio out

Features

• 3440 × 1440 resolution delivers clearer and more vivid picture quality
• Comfortable 1500R curvature closely matches natural human vision for an immersive viewing experience
• Wide color gamut with 120% sRGB, 85% NTSC, 85% DCI‑P3, and 85% Adobe RGB, meeting designers' demands for rich image texture
• Adaptive Sync technology effectively reduces picture lagging and tearing
• 1 ms fast response time minimizes blurring and ghosting

Specifications

• Model: DHI-LM34-E330CA
• LCD Technology: VA
• Backlight: ELED
• Curved Screen: Yes
• Curvature: 1,500 R
• Screen Size: 34 inch
• Aspect Ratio: 21:9
• Viewing Size: 797.22 (H) × 333.72 (V) mm
• Screen-to-Body Ratio: ≥85%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.2318 mm × 0.2318 mm
• Pixels Per Inch: 109.7
• Resolution: 3440 (H) × 1440 (V)
• Refresh Rate: 200 Hz
• Display Color: 8 bit + FRC
• Color Gamut: 85% NTSC
• Brightness: 300 cd/m² (typ.)
• Contrast Ratio: 3500:1
• Response Time: MPRT 1 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Flicker-free Technology: Yes
• Low Blue Light: Software blue light protection
• HDR: HDR10

Device Ports

• Input: 2 × HDMI 2.0 (3440 × 1440@100 Hz), 2 × DP 1.4 (3440 × 1440@200 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 19 VDC, 3.42 A
• Power Type: Power adapter
• Power Consumption: 29 W (basic), 47 W (typ.), 70 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–85% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: –5° / 15°
• Left and Right Rotation Angle: -35° / +35°
• Height Adjustment: 100 mm
• Product Dimensions (W × H × D): 810.4 mm × 361.5 mm × 132.1 mm (31.91" × 14.37" × 5.2"), without base
• Package Size (W × H × D): 1124 mm × 468 mm × 193 mm (44.25" × 18.43" × 7.6")
• Frame Width (U/L/R/D): 4.3 mm / 4.3 mm / 4.3 mm / 18.1 mm
• Net Weight: 7.3 kg (16.09 lb)
• Gross Weight: 10.2 kg (22.49 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Status Indicator Light: Yes
• Wall Mount VESA: 100 mm × 100 mm (3.94" × 3.94")

Accessory

• Power adapter
• Wall‑mount bracket
• DP cable
• User's manual
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 27'' IPS Monitor, 1920*1080, 240Hz, 0.5ms, DP+HDMI+Audio out

Features

• Wide color gamut with 85% NTSC coverage, delivering rich image texture ideal for designers
• 178°H / 178°V extra‑wide viewing angle for all‑round visual performance
• Adaptive Sync technology effectively reduces picture lagging and tearing
• Ultra‑fast 0.5 ms response time (with OD) to eliminate blurring and ghosting

Specifications

• Model: DHI-LM27-E241B
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 27 inch
• Aspect Ratio: 16:9
• Viewing Size: 597.888 (H) × 336.312 (V) mm
• Screen-to-Body Ratio: ≥85%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.3114 mm × 0.3114 mm
• Pixels Per Inch: 81.59
• Resolution: 1920 (H) × 1080 (V)
• Refresh Rate: 240 Hz
• Display Color: 8 bit, 16.7M colors
• Color Gamut: 85% NTSC
• Brightness: 350 cd/m² (typ.)
• Contrast Ratio: 1000:1
• Response Time: MPRT 1 ms, OD 0.5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Low Blue Light: Software blue light protection
• HDR: HDR10

Device Ports

• Input: 1 × DP 1.4 (1920 × 1080@240 Hz), 1 × HDMI 2.0 (1920 × 1080@240 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 12 VDC, 4 A
• Power Type: Power adapter
• Power Consumption: 21 W (basic), 24.6 W (typ.), 32 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–80% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° ± 2° / 20° ± 2°
• Product Dimensions (W × H × D): 614.3 mm × 366.8 mm × 57.2 mm (24.19" × 14.44" × 2.25"), without wall‑mount bracket
• Package Size (W × H × D): 695 mm × 460 mm × 150 mm (27.36" × 18.11" × 5.91")
• Unilateral Splicing (U/L/R/D): 8.21 mm / 8.21 mm / 8.21 mm / 22.30 mm (0.32" / 0.32" / 0.32" / 0.88")
• Net Weight: 3.55 kg (7.83 lb)
• Gross Weight: 4.85 kg (10.69 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Status Indicator Light: Yes
• Wall Mount VESA: 100 mm × 100 mm (3.94" × 3.94")

Accessory

• Power adapter
• DP cable
• User's manual
• Legal and regulatory information

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 32'' IPS Monitor, 2560*1440, 75Hz, 5ms, HDMI+DP+Audio out

Features

• 2560 × 1440 resolution delivers clearer and more vivid images
• IPS panel with a 3‑sided frameless design for wide, immersive viewing
• 178° (H) / 178° (V) extra‑wide viewing angle for consistent performance from any direction
• 5 ms fast response time minimizes blurring and ghosting
• Low blue light technology supports a more comfortable viewing experience

Specifications

• Model: DHI-LM32-C301B
• LCD Technology: IPS
• Backlight: ELED
• Screen Size: 31.5 inch
• Aspect Ratio: 16:9
• Resolution: 2560 (H) × 1440 (V)
• Refresh Rate: 75 Hz
• Display Color: 8 bit
• Color Gamut: 85% NTSC
• Brightness: 300 cd/m² (max)
• Contrast Ratio: 1200:1
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Response Time: OD 5 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%

Device Ports

• Input: 2 × HDMI 1.4 (1440P@75 Hz), 1 × DP 1.2 (1440P@75 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 12 VDC, 4 A
• Power Type: Power adapter
• Power Consumption: 32 W (basic), 44 W (typ.), 44 W (max)
• Standby Power Consumption: ≤0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–90% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: -5° ± 2° / 15° ± 2°
• Product Dimensions (W × H × D): 715.1 mm × 422.8 mm × 47.3 mm (28.15" × 16.65" × 1.86"), without base
• Package Size (W × H × D): 796 mm × 515 mm × 128 mm (31.33" × 20.28" × 5.04")
• Frame Width (U/L/R/D): 1.4 mm / 1.4 mm / 1.4 mm / 18.1 mm
• Net Weight: 6.65 kg (14.66 lb)
• Gross Weight: 8.27 kg (18.23 lb)
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Power adapter
• Base
• HDMI cable
• User's manual (QR code)
• QSG
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 49'' VA Monitor, 5120*1440, 120Hz, 1ms, DP+HDMI+Type C 65W+USB HUB+Audio out+speaker

Features

• DQHD resolution with a 32:9 ultra‑wide screen provides a broader field of view, ideal for displaying game maps and business reports
• 1800R curvature delivers an immersive visual experience with enhanced depth
• Wide color gamut with 99% sRGB and 85% NTSC, plus ?E < 2 color accuracy for rich, accurate visuals
• USB‑C port enables easy connection to laptops, smartphones, and tablets, supporting seamless screen sharing and up to 65 W power delivery
• RJ‑45 port supports network signal transmission for devices without Ethernet ports
• Picture‑by‑Picture (PBP) allows two input signals to be displayed simultaneously for multitasking and entertainment
• Blue light mode helps reduce eye strain for a more comfortable viewing experience
• Ergonomic stand supports horizontal adjustment and forward/backward tilt for personalized comfort

Specifications

• Model: DHI-LM49-EW410CA
• LCD Technology: VA
• Backlight: ELED
• Curved Screen: Yes
• Curvature: 1,800 R
• Screen Size: 49 inch
• Aspect Ratio: 32:9
• Viewing Size: 1,191.936 (H) × 335.232 (V) mm
• Screen-to-Body Ratio: ≥90%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.2382 mm × 0.2382 mm (0.01" × 0.01")
• Pixels Per Inch: 108.54
• Resolution: 5120 (H) × 1440 (V)
• Refresh Rate: 120 Hz
• Display Color: 8 bit
• Color Gamut: 85% NTSC
• Brightness: 400 cd/m² (max)
• Contrast Ratio: 3000:1
• Response Time: MPRT 1 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 25%, 3H
• Flicker-free Technology: Yes
• Low Blue Light: Yes
• HDR: Yes

Device Ports

• Input: 1 × DP 1.4 (5120 × 1440@120 Hz), 1 × HDMI 2.1 TMDS (5120 × 1440@60 Hz), 1 × Type‑C (5120 × 1440@120 Hz)
• Output: 1 × Audio out
• External Control: 1 × RJ‑45, 1 × USB 2.0‑B (Upstream), 2 × USB 2.0‑A (Downstream)
• Speaker: 2 × 3 W

Power & Environmental Conditions

• Power Supply: 100–240 VAC (±10%), 50/60 Hz
• Power Type: Built‑in Power
• Power Consumption: 42 W (basic), 72 W (typ.), 180 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–85% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH, non‑condensing

General

• Inclined Angle: -5° ± 2° / 15° ± 2°
• Left and Right Rotation Angle: -15° / +15°
• Height Adjustment: 95 ± 5 mm (3.74" ± 0.20")
• Product Dimensions (W × H × D): 1,198.5 mm × 375.6 mm × 160.2 mm (47.19" × 14.79" × 6.31"), without wall‑mount bracket
• Package Size (W × H × D): 1,305 mm × 486 mm × 284 mm (51.38" × 19.13" × 11.18")
• Frame Width (U/L/R/D): 3.2 mm / 3.3 mm / 3.3 mm / 17.6 mm (0.13" / 0.13" / 0.13" / 0.69")
• Net Weight: 11.5 kg (25.35 lb)
• Gross Weight: 15.6 kg (34.39 lb)
• Casing Color: Black
• Control Mode: Five‑button
• Wall Mount VESA: 75 mm × 75 mm (2.95" × 2.95")

Accessory

• Base
• Power cord
• DP cable
• Type‑C cable
• User's manual (QR code)
• QSG
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

DAHUA 32'' VA Monitor, 2560*1440, 180Hz, MPRT 1ms, 2*DP+2*HDMI+Audio out

Features

• R1500 curved screen delivers a more immersive and impactful visual experience
• 180 Hz high refresh rate and 1 ms fast response time help capture every gaming moment and improve winning potential
• Adaptive Sync technology reduces image tearing and lag for smoother visuals
• Wide color gamut with 85% NTSC coverage, providing rich image texture suitable for designers
• 1 ms fast response time eliminates blurring and ghosting
• Adjustable angle design to meet different viewing needs

Specifications

• Model: DHI-LM32-E330CA
• LCD Technology: VA
• Backlight: ELED
• Curved Screen: Yes
• Curvature: 1,500 R
• Screen Size: 31.5 inch
• Aspect Ratio: 16:9
• Viewing Size: 697.344 (H) × 392.256 (V) mm
• Screen-to-Body Ratio: ≥85%
• Viewing Angle: 178° (H) / 178° (V)
• Display Mode: Horizontal
• Pixel Pitch: 0.2724 mm × 0.2724 mm
• Pixels Per Inch: 93.2
• Resolution: 2560 (H) × 1440 (V)
• Refresh Rate: 180 Hz
• Display Color: 8 bit
• Color Gamut: 85% NTSC
• Brightness: 300 cd/m² (typ.)
• Contrast Ratio: 3000:1
• Response Time: MPRT 1 ms
• Lifespan: 30,000 hrs
• Surface Treatment: Haze 40%, 3H
• Flicker-free Technology: Yes
• Low Blue Light: Software blue light protection
• HDR: HDR10

Device Ports

• Input: 2 × HDMI 2.0 (2560 × 1440@144 Hz), 2 × DP 1.4 (2560 × 1440@180 Hz)
• Output: 1 × Audio out

Power & Environmental Conditions

• Power Supply: 19 VDC, 3.42 A
• Power Type: Power adapter
• Power Consumption: 32 W (basic), 46.5 W (typ.), 72 W (max)
• Standby Power Consumption: <0.5 W
• Operating Temperature: 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity: 10%–85% RH
• Storage Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Storage Humidity: 5%–90% RH

General

• Inclined Angle: –5° / 15°
• Left and Right Rotation Angle: -35° / +35°
• Height Adjustment: 100 mm
• Product Dimensions (W × H × D): 717.7 mm × 422.4 mm × 118.3 mm (28.26" × 16.63" × 4.66"), without base
• Package Size (W × H × D): 954 mm × 523 mm × 183 mm (37.56" × 20.59" × 7.2")
• Unilateral Splicing (U/L/R/D): 3.8 mm / 3.8 mm / 3.8 mm / 17.2 mm
• Net Weight: 7.0 kg (15.43 lb)
• Gross Weight: 9.1 kg (20.06 lb)
• Casing Color: Black
• Control Mode: Five‑button
• RGB Light Effect: Back Cover – Seven colors
• Status Indicator Light: Yes
• Wall Mount VESA: 100 mm × 100 mm (3.94" × 3.94")

Accessory

• Power adapter
• Wall‑mount bracket
• DP cable
• User's manual
• Legal and regulatory information

Optional Accessory

• Wall mount

Certification

• CE EMC
• CE LVD
• CE ERP

Downloads

• Product brochure

LG 34'' UltraWide QHD IPS Monitor with USB-C PD90W & built in KVM Switch & RJ45 3800R

Features

• 34” WQHD (3440x1440) Curved IPS display
• sRGB 99% (Typ.) / HDR10
• Built-in power and speakers
• USB Type-C™ (PD 90W) / RJ45
• Reader Mode & Flicker Safe
• Tilt/Height/Swivel adjustable stand

Specifications

Accessory

• Display Port: YES
• HDMI: YES
• HDMI (Color/Length): Black / 1.8m
• Power Cord: YES
• USB-C: YES
• Display Port (Color/Length): Black / 1.8m
• Power Cord (Color/Length): Black / 1.8m
• USB-C (Color/Length): Black / 1.8m

Connectivity

• Built-in KVM: YES
• HDMI: YES (2ea)
• DisplayPort: YES (1ea)
• DP Version: 1.4
• USB-C: YES (1ea)
• Headphone Out: 3-pole (Sound Only)
• LAN (RJ-45): YES
• USB Downstream Ports: 4 × USB 3.2 Gen1
• USB Upstream Port: 1 × USB 3.2 Gen1
• USB-C (Data Transmission): YES
• USB-C Max Resolution: 3440 × 1440 @ 60Hz
• USB-C Power Delivery: 90W
• HDMI HDCP Version: 2.2
• HDMI (w/o VRR): 59–60Hz
• DP HDCP Version: 2.2
• DP (w/o VRR): 59–60Hz
• USB-C HDCP Version: 2.2
• USB-C V Frequency: 59–60Hz
• HDMI Version: 2.0
• Location: Rear / Side
• USB-C DP Version: 1.4

Dimensions / Weights

• Shipping Dimensions (W × H × D): 988 × 482 × 203 mm
• Dimensions with Stand (Up): 816.7 × 543.5 × 267.5 mm
• Dimensions with Stand (Down): 816.7 × 393.5 × 267.5 mm
• Dimensions without Stand: 816.7 × 364.4 × 83.6 mm
• Weight in Shipping: 13.7 kg
• Weight with Stand: 11 kg
• Weight without Stand: 7.5 kg
• Pallet Stuffing (20ft/40ft/40HC): 216 / 504 / 630

Display

• Aspect Ratio: 21:9
• Brightness (Typ.): 300 cd/m²
• Brightness (Min.): 240 cd/m²
• Color Bit: 10-bit (8-bit + FRC)
• Color Depth: 1.07B
• Color Gamut (Typ.): sRGB 99% (CIE1931)
• Color Gamut (Min.): sRGB 90% (CIE1931)
• Contrast Ratio (Typ.): 1000:1
• Contrast Ratio (Min.): 700:1
• Curvature: 3800R
• Panel Type: IPS
• Pixel Pitch: 0.2325 × 0.2325 mm
• Refresh Rate (Max.): 60Hz
• Resolution: 3440 × 1440
• Response Time: 5ms (GtG at Faster)
• Size (Inch): 34
• Size (cm): 86.72 cm
• Surface Treatment: Anti-Glare
• Viewing Angle: 178° (R/L), 178° (U/D)
• PPI: 109.68

Features

• Auto Input Switch: YES
• Black Stabilizer: YES
• Factory Color Calibrated: YES
• Color Weakness: YES
• Dynamic Action Sync: YES
• Flicker Safe: YES
• HDR 10: YES
• HDR Effect: YES
• Other Features: KVM, PBP, Ethernet
• PBP: YES (2PBP)
• Reader Mode: YES
• Smart Energy Saving: YES
• Super Resolution+: YES
• User Defined Key: YES
• OSD Language: 17 languages
• Picture Mode: (SDR) Custom, Vivid, HDR Effect, Reader, Cinema, FPS, RTS, Color Weakness / (HDR) Custom, Vivid, Cinema, FPS, RTS

Info

• Product Name: WQHD
• Year: Y24
• Category: UltraWide

Mechanical

• Borderless Design: 3-Side Virtually Borderless
• Adjustments: Tilt / Height / Swivel
• One-Click Stand: YES
• Wall Mount: 100 × 100 mm
• Tilt: 5° ~ +21°
• Swivel: ±45°
• Height Range: 150 mm
• Base Detachable: YES
• Color (Back Cover): Black Texture
• Color (Front Cabinet): Black Texture
• Color (Middle Cabinet): Black Texture
• Color (Stand Base): Black Texture
• Color (Stand Body): Black Texture
• Down Height: 13 mm

Power

• AC Input: 100–240V (50/60Hz)
• DC Output: 20.5V, 9A
• Power Consumption (DC Off): <0.3W
• Power Consumption (On-Mode, ErP): 29W
• Power Consumption (Sleep Mode): <0.5W
• Type: Built-in Power
• Power Consumption (On-Mode): 29W

Sound

• Speakers: 5W × 2
• Maxx Audio: YES

Standard

• CE: YES
• UL (cUL): YES
• EPA: YES
• FCC-B: YES
• EPEAT (USA): BRONZE
• CB: YES
• EPEAT (Germany): BRONZE
• ErP: YES
• Other Standards: CEC, PCF Report
• TCO: YES
• TUV-Ergo: YES
• TUV-GS: YES

Software Applications

• Dual Controller: YES
• OnScreen Control (LG Screen Manager): YES
• LG Switch: YES

MAXHUB CMB Series Commercial Display, Screen size 50''

Features

• 4K commercial‑grade display (43"–98") built for true 24/7 operation
• Ultra‑narrow bezel with durable, professional hardware for long‑term reliability
• Microsoft Teams Rooms–ready with seamless meeting‑room integration
• Instant BYOD sharing via USB‑C (65W) and wireless casting (AirPlay, Miracast, Chromecast)
• Professional color accuracy with 98% sRGB, HDR, and factory calibration
• Enterprise‑ready connectivity & control including triple HDMI, dual LAN, RS‑232, CEC, and Crestron/Extron/Q‑Sys certification

Specifications

Display

• Screen Size: 50"
• Aspect Ratio: 16:9
• Panel Type: VA
• Brightness: 500 nits
• Haze: 25%
• Resolution: 3840 × 2160
• Refresh Rate: 60 Hz
• Contrast Ratio: 5,000:1
• Viewing Angle: 178° / 178°
• Color Gamut: 98% sRGB
• Display Orientation: Landscape / Portrait
• Operation Hour: 24/7
• Display Color: 1.07B (10‑bit)

Built‑in System

• Operating System: Android 14.0
• RAM: 4 GB
• ROM: 32 GB

Connectivity

• HDMI IN: ×3
• USB 2.0: ×1
• USB 3.0: ×1
• USB Type‑C: ×1
• Audio In: ×1
• Audio Out: ×1
• RS232: ×1
• RJ45 IN: ×1
• RJ45 OUT: ×1
• HDMI OUT: ×1
• SPDIF: ×1
• Wi‑Fi Module Slot: ×1
• Wi‑Fi: Wi‑Fi 6 supported
• Bluetooth: 5.2

Audio

• Sound Channel: 2.0
• Speaker Power: 2×12W (16W max)

Feature

• System OS: MAXHUB Signage OS V2
• Screen Share: MAXHUB Share, BYOD, Miracast, AirPlay, Chromecast
• Device Management: MAXHUB Pivot
• Special Features: Screen rotation; Auto input change; Play via URL; Wake on LAN; Color Calibration

Physical Specification

• Bezel Width: 9.9 mm
• Dimensions (W×H×D): 1118.6 × 639.2 × 62 mm
• VESA: 400 × 400 mm

Power

• Energy Saving: 49 W
• Typical: 65 W
• Max: 110 W

Warranty

• 3 years

Downloads

• Product brochure

MAXHUB CMB Series Commercial Display, Screen size 43''

Features

• 4K commercial‑grade display (43"–98") built for true 24/7 operation
• Ultra‑narrow bezel with durable, professional hardware for long‑term reliability
• Microsoft Teams Rooms–ready with seamless meeting‑room integration
• Instant BYOD sharing via USB‑C (65W) and wireless casting (AirPlay, Miracast, Chromecast)
• Professional color accuracy with 98% sRGB, HDR, and factory calibration
• Enterprise‑ready connectivity & control including triple HDMI, dual LAN, RS‑232, CEC, and Crestron/Extron/Q‑Sys certification

Specifications

Display

• Screen Size: 43"
• Aspect Ratio: 16:9
• Panel Type: ADS
• Brightness: 500 nits
• Haze: 25%
• Resolution: 3840 × 2160
• Refresh Rate: 60 Hz
• Contrast Ratio: 1,200:1
• Viewing Angle: 178° / 178°
• Color Gamut: 98% sRGB
• Display Orientation: Landscape / Portrait
• Operation Hour: 24/7
• Display Color: 1.07B (10‑bit)

Built‑in System

• Operating System: Android 14.0
• RAM: 4 GB
• ROM: 32 GB

Connectivity

• HDMI IN: ×3
• USB 2.0: ×1
• USB 3.0: ×1
• USB Type‑C: ×1
• Audio In: ×1
• Audio Out: ×1
• RS232: ×1
• RJ45 IN: ×1
• RJ45 OUT: ×1
• HDMI OUT: ×1
• SPDIF: ×1
• Wi‑Fi Module Slot: ×1
• Wi‑Fi: Wi‑Fi 6 supported
• Bluetooth: 5.2

Audio

• Sound Channel: 2.0
• Speaker Power: 2×12W (16W max)

Feature

• System OS: MAXHUB Signage OS V2
• Screen Share: MAXHUB Share, BYOD, Miracast, AirPlay, Chromecast
• Device Management: MAXHUB Pivot
• Special Features: Screen rotation; Auto input change; Play via URL; Wake on LAN; Color Calibration

Physical Specification

• Bezel Width: 9.9 mm
• Dimensions (W×H×D): 964.6 × 552.5 × 62 mm
• VESA: 200 × 200 mm

Power

• Energy Saving: 39 W
• Typical: 40 W
• Max: 105 W

Warranty

• 3 years

Downloads

• Product brochure

MAXHUB CMB Series Commercial Display, Screen size 86''

Features

• 4K commercial‑grade display (43"–98") built for true 24/7 operation
• Ultra‑narrow bezel with durable, professional hardware for long‑term reliability
• Microsoft Teams Rooms–ready with seamless meeting‑room integration
• Instant BYOD sharing via USB‑C (65W) and wireless casting (AirPlay, Miracast, Chromecast)
• Professional color accuracy with 98% sRGB, HDR, and factory calibration
• Enterprise‑ready connectivity & control including triple HDMI, dual LAN, RS‑232, CEC, and Crestron/Extron/Q‑Sys certification

Specifications

Display

• Screen Size: 86"
• Aspect Ratio: 16:9
• Panel Type: ADS
• Brightness: 500 nits
• Haze: 25%
• Resolution: 3840 × 2160
• Refresh Rate: 60 Hz
• Contrast Ratio: 1,200:1
• Viewing Angle: 178° / 178°
• Color Gamut: 98% sRGB
• Display Orientation: Landscape / Portrait
• Operation Hour: 24/7
• Display Color: 1.07B (10‑bit)

Built‑in System

• Operating System: Android 14.0
• RAM: 4 GB
• ROM: 32 GB

Connectivity

• HDMI IN: ×3
• USB 2.0: ×2
• USB 3.0: ×1
• USB Type‑C: ×1
• Audio In: ×1
• Audio Out: ×1
• RS232: ×1
• RJ45 IN: ×1
• RJ45 OUT: ×1
• HDMI OUT: ×1
• SPDIF: ×1
• Wi‑Fi Module Slot: ×1
• Wi‑Fi: Wi‑Fi 6 supported
• Bluetooth: 5.2

Audio

• Sound Channel: 2.0
• Speaker Power: 2×12W (16W max)

Feature

• System OS: MAXHUB Signage OS V2
• Screen Share: MAXHUB Share, BYOD, Miracast, AirPlay, Chromecast
• Device Management: MAXHUB Pivot
• Special Features: Screen rotation; Auto input change; Play via URL; Wake on LAN; Color Calibration

Physical Specification

• Bezel Width: 15.9 mm
• Dimensions (W×H×D): 1930.8 × 1101.7 × 68 mm
• VESA: 600 × 400 mm

Power

• Energy Saving: 122 W
• Typical: 148 W
• Max: 247 W

Warranty

• 3 years

Downloads

• Product brochure

MAXHUB CMB Series Commercial Display, Screen size 65''

Features

• 4K commercial‑grade display (43"–98") built for true 24/7 operation
• Ultra‑narrow bezel with durable, professional hardware for long‑term reliability
• Microsoft Teams Rooms–ready with seamless meeting‑room integration
• Instant BYOD sharing via USB‑C (65W) and wireless casting (AirPlay, Miracast, Chromecast)
• Professional color accuracy with 98% sRGB, HDR, and factory calibration
• Enterprise‑ready connectivity & control including triple HDMI, dual LAN, RS‑232, CEC, and Crestron/Extron/Q‑Sys certification

Specifications

Display

• Screen Size: 65"
• Aspect Ratio: 16:9
• Panel Type: ADS
• Brightness: 500 nits
• Haze: 25%
• Resolution: 3840 × 2160
• Refresh Rate: 60 Hz
• Contrast Ratio: 1,200:1
• Viewing Angle: 178° / 178°
• Color Gamut: 98% sRGB
• Display Orientation: Landscape / Portrait
• Operation Hour: 24/7
• Display Color: 1.07B (10‑bit)

Built‑in System

• Operating System: Android 14.0
• RAM: 4 GB
• ROM: 32 GB

Connectivity

• HDMI IN: ×3
• USB 2.0: ×2
• USB 3.0: ×1
• USB Type‑C: ×1
• Audio In: ×1
• Audio Out: ×1
• RS232: ×1
• RJ45 IN: ×1
• RJ45 OUT: ×1
• HDMI OUT: ×1
• SPDIF: ×1
• Wi‑Fi Module Slot: ×1
• Wi‑Fi: Wi‑Fi 6 supported
• Bluetooth: 5.2

Audio

• Sound Channel: 2.0
• Speaker Power: 2×12W (16W max)

Feature

• System OS: MAXHUB Signage OS V2
• Screen Share: MAXHUB Share, BYOD, Miracast, AirPlay, Chromecast
• Device Management: MAXHUB Pivot
• Special Features: Screen rotation; Auto input change; Play via URL; Wake on LAN; Color Calibration

Physical Specification

• Bezel Width: 15.9 mm
• Dimensions (W×H×D): 1463.3 × 838.3 × 68 mm
• VESA: 600 × 400 mm

Power

• Energy Saving: 78 W
• Typical: 92 W
• Max: 133 W

Warranty

• 3 years

Downloads

• Product brochure

MAXHUB CMB Series Commercial Display, Screen size 55''

Features

• 4K commercial‑grade display (43"–98") built for true 24/7 operation
• Ultra‑narrow bezel with durable, professional hardware for long‑term reliability
• Microsoft Teams Rooms–ready with seamless meeting‑room integration
• Instant BYOD sharing via USB‑C (65W) and wireless casting (AirPlay, Miracast, Chromecast)
• Professional color accuracy with 98% sRGB, HDR, and factory calibration
• Enterprise‑ready connectivity & control including triple HDMI, dual LAN, RS‑232, CEC, and Crestron/Extron/Q‑Sys certification

Specifications

Display

• Screen Size: 55"
• Aspect Ratio: 16:9
• Panel Type: ADS
• Brightness: 500 nits
• Haze: 25%
• Resolution: 3840 × 2160
• Refresh Rate: 60 Hz
• Contrast Ratio: 1,200:1
• Viewing Angle: 178° / 178°
• Color Gamut: 98% sRGB
• Display Orientation: Landscape / Portrait
• Operation Hour: 24/7
• Display Color: 1.07B (10‑bit)

Built‑in System

• Operating System: Android 14.0
• RAM: 4 GB
• ROM: 32 GB

Connectivity

• HDMI IN: ×3
• USB 2.0: ×1
• USB 3.0: ×1
• USB Type‑C: ×1
• Audio In: ×1
• Audio Out: ×1
• RS232: ×1
• RJ45 IN: ×1
• RJ45 OUT: ×1
• HDMI OUT: ×1
• SPDIF: ×1
• Wi‑Fi Module Slot: ×1
• Wi‑Fi: Wi‑Fi 6 supported
• Bluetooth: 5.2

Audio

• Sound Channel: 2.0
• Speaker Power: 2×12W (16W max)

Feature

• System OS: MAXHUB Signage OS V2
• Screen Share: MAXHUB Share, BYOD, Miracast, AirPlay, Chromecast
• Device Management: MAXHUB Pivot
• Special Features: Screen rotation; Auto input change; Play via URL; Wake on LAN; Color Calibration

Physical Specification

• Bezel Width: 9.9 mm
• Dimensions (W×H×D): 1233 × 703.5 × 62 mm
• VESA: 400 × 400 mm

Power

• Energy Saving: 62 W
• Typical: 70 W
• Max: 126 W

Warranty

• 3 years

Downloads

• Product brochure
