The DGS-3130 Series switches are Lite Layer 3 Stackable Managed Switches designed to offer fast and secure connectivity on enterprise or metro Ethernet access network.
Features/Specifications:
802.1X Access Control: Yes
Guest VLAN: Yes
IP Interfaces: Yes
Layer 3 Switching: Yes
Redundant PSU: DPS-500
Routing Table Size: 512
Stacking: Physical and Virtual
Stacking Capacity: Physical (9) Virtual (32)
Number of Ports: 24 - 32
PoE Type Required: None
Type of Port Required: Gigabit Copper | Gigabit Fibre | 10 Gigabit Copper | 10 Gigabit Fibre
Redundant Power Supply Option: Yes
Stacking Bandwidth: 80 Gbps
Switch Type: Layer 3 Lite
Switch Series: DGS-3130 Series
10 Gig ports: Yes
10GBase-T ports: 2
Layer: Layer 3
SFP+ ports: 4
Cable Diagnostics: Yes
Command Line Interface: Yes
DHCP Server Screening: Yes
Dimensions (Size): 440 x 250 x 44 mm
Energy Saving Technology: EEE Compliant | D-Link Green
Fans: 1
IGMP Snooping: Yes
Jumbo Frame: 9K
Link Aggregation: Yes
QoS: Yes
19 Inch Rack Mountable: Yes
Warranty: Limited Lifetime
SNMP: Yes
Spanning Tree Protocol: Yes
Switching Capacity: 168 Gbps
1000Base-T ports: 24 Ports
VLAN: 4K Groups
Voice VLAN: Yes
Web-based GUI: Yes
24 1000Base-T ports with 2 10GBASE-T and 4 10G SFP+ ports
Six 10Gb ports: 2 copper and 4 SFP+ for stacking and uplinks
168 Gbps switching capacity
Stackable up to 9 switches with 80Gb stacking bandwidth
Layer 3 switch with essential Layer 3 included
6 kV surge protection on all copper ports
Comprehensive security
Redundant Power Supply support
