Maximise the productivity of any creative by providing extended screen real estate with UHD quality as well as SuperSpeed data transfer for all your USB peripherals. Housed in a robust aluminium body, it is reliable and compact, perfect for travel.
Features/Specifications:
Interface: USB Type C to 2x HDMI / 2x USB Type A / 1x USB Type C / 1x RJ45 / 1x Audio 3.5mm
Interface Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0 | HDMI 1.4 + 2.0 | Gigabit LAN | Audio (combo)
Supported Bandwidth: 10.8Gbps (HDMI 1.4) | 18Gbps (HDMI 2.0) | 5Gbps (USB 3.0) | 10/100/100Mbps (LAN)
Maximum Input Resolution: 3840x2160@60Hz
Maximum Output Resolution: Single display: 4K 60Hz | Dual display: 1x 4K60Hz | 1x 4K30Hz
Chipset: SM768 | ANX7518 | 2xVL817 | AX88179A | HS-100B | IM2600
Compatibility: USB Type C or Thunderbolt 3 equipped computers
Power Delivery: PD 3.0 up to 100W (20V 5A)
HDCP Support: HDCP 2.2
Supported Audio: Supports 48/44.1kHz Audio sampling rate
Separate Audio Ports: 1x Audio combo port 3.5mm
Special : USB Type C Female port supports power and data | 2x Battery Charging 1.2 port | Software-based Silicon solution to connect any display to any computer that supports USB | compatible with Windows and MacOS; MST dual display for Apple M1
Inputs: 1 x USB Type C (Male)
Outputs: 2x HDMI (Female) | 1x RJ45 (Female) | 2x USB Type A (Female) | 1x USB Type C (Female) / 1x 3.5mm Audio (Female)
Power: 1 x USB Type C (Female) PD port
Dimensions WxDxH: 140 x 65 x 20mm
Housing Material: Aluminium | ABS (RJ45 port cover)
Net Weight: 0.2kg
Power Requirements: Bus-powered
Packaging Dimensions: 207 x 137 x 38mm
Gross Weight: 0.3kg
Warranty (Years): 2
Certificated: CE | UKCA | FCC | REACH ; RoHS | California Proposition 65
Adds Dual 4K 3840x2160 HDMI displays to Windows and Apple M1 PC's
Provides 2 USB Type A ports ; 1 USB Type C port (5Gbps) Gigabit Ethernet and an Audio combo port
Software-based Silicon solution to connect any display to any computer that supports USB
USB Power Delivery 3.0 (100W) allows charging the laptop while using the DST-Mx Duo
Extend your Displays
Added Connectivity
Easy Driver Installation
2-year warranty
Output Port: HDMI
Output Port: USB-C
Output Port: Network
Output Port: USB-A
Output Port: Audio
