CyberPower Systems Online S 6000VA/5400W Rack UPS -12V/7AH*20 - Hardwire Terminal Block - USB & Serial Port & SNMP Slot (optional RMCARD205) - 2 Yrs Adv. Replacement WTY - Incl Rail kit
Features/Specifications:
Phase: Single Phase
Form Factor: Rackmount Tower
UPS Topology: Online Double Conversion
Energy Saving Technology: Online ECO Mode Efficiency > 96%
Active PFC Compatibility: Yes
Parallel Expansion (Max. Units): 4
Generator Compatibility: Yes
Nominal Input Voltage ( Vac ): 230
Input Voltage Range ( Vac ): 110 - 276
Adjustable Voltage Range ( Vac ): 0-80% Load for 110 - 276 Vac | 0-100% Load for 176 - 276 Vac
Input Frequency ( Hz ): 50 ± 5 | 60 ± 6
Input Frequency Detection: Auto-sensing
Rated Input Current ( A ): 27.3
Input Power Factor: 0.99
Input Connector Type: Hardwire Terminal Block
Output Capacity (VA): 6000
Output Capacity (Watts): 5400
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) ( Vac ): 208 ± 1% | 220 ± 1% | 230 ± 1% | 240 ± 1%
Output Voltage Setting: Configurable
On Battery Frequency ( Hz ): 50 ± 0.1% | 60 ± 0.1%
Output Frequency Setting: Configurable
Power Factor: 0.9
ECO Mode Voltage Tolerance: ± 10 %
Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse
Overload Protection (Line Mode): 105-125% Load for 10 min, 125-150% Load for 1 min, 150-170% Load for 10 sec, >170% Load for 1 sec
Overload Protection (Battery Mode): 105-125% Load for 2 min, 125-150% Load for 30 sec, >150% Load for 1 sec
Overload Protection (Bypass Mode): 125-150% Load for 1 min, 150-170% Load for 10 sec, >170% Load for 1 sec
Crest Factor: 3 : 1
Harmonic Distortion (Linear Load): THD?2%
Harmonic Distortion (Non-linear Load): THD?5%
Internal Bypass: Automatic Bypass, Manual Bypass
Typical Recharge Time ( Hours ): 7
Maximum Charging Current ( A ): 4
Start On Battery: Yes
Smart Battery Management (SBM): Yes
User-replaceable: No
Battery Type: Sealed Lead-acid
Compatible Extended Battery Module (EBM): BPSE240V75ART3U
Max. EBM Quantity ( pcs ): 15
Surge Suppression ( Joules ): 445
EMI/RFI Filtration: Yes
LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log
LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting
LED Indicators: Line Mode, Battery Mode, Bypass Mode, UPS Fault
HID Compliant USB Port(s): 1
Dry Contact (with Relay): Optional
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault
Power Management Software: PowerPanel Business (Recommended)
SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205
Enclosure Construction: Metal
Rackmount Rail: Yes
Rackmount Ears: Yes
Certification: CE
RoHS: Yes
Product Warranty: 2 Years
Online (Double Conversion) UPS Topology
UPS Parallel Expansion
Overload Protection
Smart Battery Management (SBM)
Surge and Spike Protection
LCD Status Display
PowerPanel Management Software
Rack/Tower Convertible Configurations
ECO Mode
Generator Compatible
Zero Transfer Time
Extended Battery Module (EBM)
EMI and RFI Filtration
Emergency Power Off (EPO) Port
SNMP/HTTP Remote Management Capability
