Features/Specifications:
AV Interface: DisplayPort
Console Interfaces: USB
Interface Standard: DisplayPort 1.4 | USB 3.0
Maximum Resolution: 7680x4320@60Hz 4:2:0 8Bit
HDCP Support: 2.2
Supported Audio: Analogue Stereo
Separate Audio Ports: 3.5mm (Female)
Console Number: 1
Max Number PC/Server: 2
Switching Method: Push Button & Hotkey Switching
Console Interfaces: DisplayPort (Female) | 3 x USB HID Type A (Female) | 2 x USB 3.0 Type A (Female) | 3.5mm (Female)
PC/Server Interfaces: 2 x DisplayPort (Female) | 2 x USB 3.0 Type B (Female) | 2 x 3.5mm (Female)
Power: 5.5/2.1mm DC socket
Dimensions: 160 x 100 x 40mm
Weight: 0.617kg
Power Requirements: 12VDC 1.5A
Warranty (Years): 2
Certificated: CE | FCC | RoHS | REACH
Controls two DisplayPort equipped PCs from a single keyboard, mouse and monitor
Switch via the unit's push buttons or keyboard hotkeys
Supports DisplayPort 1.4 signals up to 8K 60Hz 4:2:0 8bit
Supports audio stereo and 2 ports USB 3.0 Hub for sharing additional USB peripherals
2 year warranty
